19. Switch Lever
18. Mower-Status Indicator
17. Side Rail
16. Rear Discharge Door
15. Rear Handle
14. Battery Cover
13. LED Headlights
12. Front Handle
11. Mower Deck
23. Battery-Release Button
B
20. Handle
10. Front Wheel
23. Support for
Upright Storage
24. Safety Key
1. Self-propel Switch
8. Cutting-height Adjustment Lever
9. Rear Wheel
21. Support for Upright Storage
C
2. Self-Propel Speed-Control Knob
3. Safety Button
4. Switch Button for LED
Headlights
5. Handle-Locking Clamp
6. Grass Bag
7. Quick-Adjust Lever
22. Trailing
Shield
25. Mulching Insert
