Summary of Contents for Forever Redwood Forever Porch Pavilion
- Page 1 866.332.2403 (TOLL FREE); 7am – 7pm Pacific Time, Monday-Saturday ASSEMBLY INSTRUCTIONS FOR THE FOREVER PORCH PAVILION...
- Page 2 P| 1 FOREVER PORCH PAVILION www.ForeverRedwood.com...
- Page 3 P| 2 FOREVER PORCH PAVILION www.ForeverRedwood.com...
- Page 4 P| 3 FOREVER PORCH PAVILION www.ForeverRedwood.com...
- Page 5 P| 4 FOREVER PORCH PAVILION www.ForeverRedwood.com...
- Page 6 All options of posts (No posts decorative trim, vertical posts decorative trim and horizontal posts decorative trim) will be installed in the same way. Step 2: Attach the wall mounted anchors (18) to the wall with ½´´ X 3 ½´´ anchor bolts or lag bolts (A or C). P| 5 FOREVER PORCH PAVILION www.ForeverRedwood.com...
- Page 7 (E) used in step 3. Each part has a series of numbers that indicate where to attach the part with the corresponding number. P| 6 FOREVER PORCH PAVILION www.ForeverRedwood.com...
- Page 8 Step 6: Attach the main knee braces (8) to the supports with 3/8´´ x 7´´ bolts (E) and to the posts with 3/8´´ x 9´´ Bolts (F). Each part has a series of numbers that indicate where to attach the part with the corresponding number. 3/8´´ X 7´´ Bolts 3/8´´ X 9´´ Bolts P| 7 FOREVER PORCH PAVILION www.ForeverRedwood.com...
- Page 9 Step 8: Use 5/16´´ x 3´´ lag bolts (A) to attach the angles (17) to the in-between blockings. Each part has a series of numbers that indicate where to attach the part with the corresponding number. 5/16´´ X 3´´ Lag Bolts P| 8 FOREVER PORCH PAVILION www.ForeverRedwood.com...
- Page 10 Step 10: Attach the front triangle (6) to the posts with 3/8´´ x 6 ½´´ bolts (D) and to the supports with 3´´ deck screws (H). Each part has a series of numbers that indicate where to attach the part with the corresponding number. 3/8´´ X 6 ½´´ Bolts 3/8´´ X 6 ½´´ Bolts 3´´ Deck screws P| 9 FOREVER PORCH PAVILION www.ForeverRedwood.com...
- Page 11 Step 12: Use 5/16’’ x 3’’ lag bolts (A) to attach the ridge board (10) to the triangles. Each part has a series of numbers that indicate where to attach the part with the corresponding number. 5/16´´ X 3´´ Lag Bolts P| 10 FOREVER PORCH PAVILION www.ForeverRedwood.com...
- Page 12 Step 14: Attach the roof boards (12) to the triangles and the rafters with 6” x 1 5/8’’deck screws (I). Each part has a series of numbers that indicate where to attach the part with the corresponding number. 1 5/8´´ Deck Screw P| 11 FOREVER PORCH PAVILION www.ForeverRedwood.com...
- Page 13 Step 15: Attach the roof fascia’s (13) to the roof boards with 6’’ x 1 5/8’’ deck screws (I). Each part has a series of numbers that indicate where to attach the part with the corresponding number. Step 15: Finally, attach the boots (14) to each post with 3’’ deck screws (E). 3´´ Deck Screws P| 12 FOREVER PORCH PAVILION www.ForeverRedwood.com...
- Page 14 This completes the Pavilion assembly. Hope you enjoy your set for many decades. If you ever have a problem or a question, don't hesitate to call us (866 332 2403) or email us. We are here to support you. P| 13 FOREVER PORCH PAVILION www.ForeverRedwood.com...
