  • Page 1 HOT WATER PRESSURE WASHER HW3513HAD User Manual BEPOWEREQUIPMENT...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety 6    Safety Rules 7    Safety Warnings Features 12    Features Installation & Preparation 13  Attire 13  Set-Up 14  Engine/Burner Fuel Tank 15  Dual Lance Assembly With Adjustable  Pressure 15  Nozzle Review 16  Nozzle Connection 16  Water Supply 17  Unloader 18  Thermal Relief Valve 18  Pre-Start Inspection Procedures Operation 19  Priming The Pump 19  Start-Up/Cold Water Operation 21  Hot Water Operation 21 ...
  • Page 3 TABLE OF CONTENTS Parts List 30  Specifications 32  Flow Chart 32  EMF System 33  Operation Theory 34  Frame Assembly 36  Engine/Pump Assembly 38  High Pressure Pump 41  Unloader/Manifold Assembly 42  Unloader 43  Pressure Switch 44  Detergent Injector 45  Heat Exchanger/EMF System 47  Boiler Assembly 49  Gun/Wand/Hose Assembly 50  Dual Lance Assembly 51  Fuel Tank 52  Fuel Pump & Fuel Solenoid 53  EMF System 55 ...
  • Page 4 INTRODUCTION Attention: Read through the complete manual prior to the initial use of your Pressure Washer Using the Operator’s manual The operating manual is an important part of your Pressure Washer. It  should be read thoroughly before initial use, and referred to often to make  sure adequate safety and service concerns are being addressed. Reading the owner’s manual thoroughly will help avoid any personal injury  or damage to your pump. By knowing how best to operate this machine  you will be better positioned to show others who may also operate the  unit. You can refer back to the manual at any time to help troubleshoot any  specific operating functions, so store it with the machine at all times.
  • Page 5 PRODUCT IDENTIFICATION Record Identification Numbers Pressure Washer If you need to contact an Authorized Dealer or Customer Service line (1- 866-850-6662) for information on servicing, always provide the  product model and identification numbers. You will need to locate the model and serial number for the pump and  record the information in the places provided below.  Date of Purchase: Dealer Name: Dealer Phone: Product Identification Numbers Model Number: Serial Number:...

  • Page 6: Safety

    SAFETY Save these Instructions SAFETY RULES This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The safety alert symbol (      ) is used with a signal word (DANGER, CAU- TION, WARNING), a pictorial and/or a safety message to alert you to  hazards.  DANGER indicates a hazard which, if not avoided, will result in death or ...
  • Page 7 SAFETY WARNING Serious injury or death may occur from normal sparks in  the multiple ignition sources or engine/burner exhaust. Injury or death may occur as a result of improper fueling. Serious injury or death may occur from a ground fire  caused by a muffler spark. Serious injury or death may occur if system safety’s are  not properly maintained. • Always operate pressure washer in a well ventilated area free of  flammable vapors, combustible dust, gases or other combustible  materials. • Do not store the pressure washer near an open flame or any  equipment such as a stove, furnace, water heater, etc., which utilizes  a pilot light or sparking device. • Do not use this pressure washer to spray flammable material! • Do not smoke while filling burner fuel tank. • Never fill the fuel tanks while the pressure washer is running or hot.  Allow to cool two minutes before refueling. • Always refuel slowly to avoid the possibility of spilled fuel which may  cause a risk of fire. • Do not refuel indoors or in a poorly ventilated area. • Engine Fuel Tank: Refuel with gasoline only. Do not use diesel or fuel  oil. • Burner Fuel Tank (Black): When refueling the Burner Fuel Tank, use  No. 1 or No. 2 fuel oil/diesel or kerosene. Do not use gasoline. • Do not operate the unit if diesel fuel is spilled. Wipe the pressure  washer clean and move it away from the spill. Avoid creating any  ignition until the diesel fuel has evaporated. • A spark arrester must be added to the muffler of this engine if it is  to be used on any forest covered, brush covered or grass covered  unimproved land. The arrester must be maintained in effective working  order by the operator. In the state of California, the above is required  by law. (Section 4442 of the California Public Resources Code.)  Other states may have similar laws. Federal laws apply on Federal  lands. • This pressure washer has a Safety Relief device which should never  be altered, modified, removed or made inoperative. If the device fails,  replace immediately with only genuine manufacturer replacement part.
  • Page 8 SAFETY WARNING Serious injury or death may occur from inhaling engine/ burner exhaust or dangerous vapors. The engine  exhaust from this product contains chemicals known to  the State of California to cause cancer, birth defects, or  other reproductive harm. • Never operate this pressure washer in an enclosed area. Always make  certain there is adequate ventilation (fresh outside air) for breathing  and combustion. This will prevent the buildup of dangerous carbon  monoxide gases. Beware of poorly ventilated areas, or areas with  exhaust fans which can cause poor air exchange. • Follow all safety instructions provided with the materials you are  spraying. Use of a respirator may be required when working with  some materials. Do not use this pressure washer to dispense  hazardous detergents. WARNING Serious injury or death could occur from high pressure  spray penetrating the skin. • Keep clear of nozzle and spray! Never put your hand, fingers or body  directly over the spray nozzle. • Do not direct discharge stream at persons or self. • This product is to be used only by trained operators. • Always keep operating area clear of all persons. • Close supervision is necessary when used near children. DO NOT  allow children to operate this unit! • SEEK EMERGENCY MEDICAL CARE if the spray appears to have  penetrated the skin! DO NOT TREAT AS A SIMPLE CUT!! • High pressure hoses and fuel lines should be inspected daily for signs  of wear. If evidence of failure exists, promptly replace all suspect  hoses and fuel lines to prevent the possibility of injury from the high  pressure spray. If a hose or fitting is leaking, NEVER PLACE YOUR  HAND DIRECTLY ON THE LEAK. • NEVER operate the gun with the trigger wired in the open position.  To prevent accidental discharge, the trigger gun should be securely  locked when not in use. • Before removing the spray nozzle or servicing the unit, ALWAYS shut  off the unit and trigger the gun to release trapped pressure. (Even af- ter you shut off the unit, there is high pressure water left in the pump,  hose and gun until you release it by triggering the gun.)
  • Page 9 SAFETY WARNING Serious injury or death may occur from contact with  electricity. • DO NOT direct spray on or into electrical installations of any kind!  This includes electrical outlets, light bulbs, fuse boxes, transformers,  the unit itself, etc. • DO NOT allow metal components of the pressure washer to come in  contact with live electrical components. WARNING Serious injury may occur from touching the gasoline  engine, muffler or heat exchanger. These areas can  remain hot for some time after the pressure washer is  shutdown. • Never allow any part of your body to contact the gasoline engine,  muffler or  heat exchanger. WARNING Serious injury may occur from a pressure washer  malfunction or exploding accessories if incorrect system components, attachments or accessories are  used.  Serious injury or death may occur if attempting to start  the pressure washer when the pumping system is  frozen. • Never make adjustments to the factory set pressures. • Never exceed manufacturers maximum allowable pressure rating of  attachments. • Do not allow any hoses to make contact with heat exchanger to  prevent the possibility of bursting. Avoid dragging the hoses over  abrasive surfaces such as cement. • Use only manufacturer recommended repair parts for your pressure  washer. • In freezing temperatures, the unit must always be warm enough to  ensure there is no ice formation in the pump. Do not start the pressure  washer if it has been transported in an open or under heated vehicle  without first allowing the pump to thaw.
  • Page 10 SAFETY WARNING Serious injury may occur to the operator from moving  parts on the pressure washer. • Before making any adjustments, be certain the engine is turned off  and the ignition cable(s) is removed from the spark plug(s). Turning  the machinery over by hand during adjustment or cleaning might start  the engine and machinery with it. • Do not operate the unit without all protective covers in place. WARNING Serious injury or death may occur from detergents con- tacting the skin. Serious injury can occur from loose debris being pro- pelled at a high speed from the spray gun. Injury may occur if the operator loses his balance  caused by the thrust of water traveling through the  spray nozzle. Injury may occur from the pressure washer. • SEEK EMERGENCY MEDICAL CARE if you are using cleaning  agents and the spray appears to have penetrated the skin! DO NOT  TREAT AS A SIMPLE CUT! Be prepared to tell a physician exactly  what kind of detergents you were using by reading the Material Safety  Data Sheet (MSDS) provided with your detergent. • Never use any solvents or highly corrosive detergents or acid type  cleaners with this pressure washer. • Protective equipment such as rubber suits, gloves and respirators are  advisable, especially when using cleaning detergents. • Keep all detergents out of the reach of children! • ALWAYS wear protective goggles when operating the unit to shield  the eyes from flying debris and detergents. • DO NOT direct spray toward fragile materials such as glass for shat- tering could occur. • Stay alert-watch what you are doing. Do not operate the unit when  fatigued or under the influence of alcohol or drugs. • NEVER squeeze the trigger unless securely braced. • DO NOT overreach or stand on unstable support. • Wet surfaces can be slippery, wear protective foot gear and keep  good footing and balance at all times.
  • Page 11 SAFETY • NEVER trigger the gun while on a ladder or roof. • ALWAYS hold on firmly to the gun/lance assembly when starting and  operating the unit. Failure to do so can cause the lance to fall and  whip dangerously. • Know how to stop the pressure washer and bleed pressures quickly.  Be thoroughly familiar with controls. • DO NOT leave pressurized unit unattended. Shut off the pressure  washer and release trapped pressure before leaving. • DO NOT operate the unit if you see any fuel, oil or water leaks from  the machine. DO NOT resume operation until the unit has been in- spected and repaired by a qualified service person. • NEVER run the engine with the governor disconnected or operate at  excessive speeds. • Place unit in a clean, dry, flat area for servicing. Before servicing the  unit: turn the unit off, relieve the water pressure from the trigger gun,  and allow the unit to cool down. Service in clean, dry, flat area. If ap- plicable, block wheels to prevent unit from moving. • Do not move the unit by pulling on the hose. WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm.

  • Page 12: Features

    FEATURES Features REC'D: ITEM DESCRIPTIO CONVENIENT PUSH/PULL HA BELTGUARD FLAT FREE WHEELS GASOLINE ENGINE TANK BURNER ON/OFF SWITCH AIR SHUTTER ADJUSTING AR BURNER FUEL TANK HEAT EXCHANGER EXHAUST HIGH PRESSURE HOSE TRIGGER SAFETY LOCK TRIGGER GUN DUAL LANCE QUICK CONNECT NOZZLE Mi-T-M Corporati SCALE: DATE:...

  • Page 13: Installation & Preparation

    INSTALLATION & PREPARATION Installation & Preparation ATTIRE Proper attire is essential to your safety. It is advised to utilize whatever  means necessary to protect eyes, ears, and skin. Additional safety  attire (such as respiratory mask) may be required when using detergent  cleaning agents with this washer. SET-UP 1. This unit should only be placed on a level surface to ensure proper  lubrication for the water pump while operating. NEVER spray water  directly on the unit. 2. Do not use unit in an area: a. with insufficient ventilation. b. where there is evidence of oil or fuel leaks. c. where flammable gas vapors may be present. This unit has multiple ignition sources that could cause an explosion or  fire. 3. Do not allow the unit to be exposed to rain, snow or freezing  temperatures. If any part of the unit becomes frozen, excessive  pressure may build up in the unit which could cause it to burst  resulting in possible serious injury to the operator or bystanders. 4. Be certain to block the wheels to prevent the unit from moving while  operating. 5. Pump oil level should be checked before each use. Make certain the  oil is on the “Full” mark on the dipstick or in the center of the oil sight  glass. If the level appears to be low, fill with SAE30W non-detergent  pump oil. DANGER DO NOT PLACE UNIT IN AN AREA WHERE  FLAMMABLE GAS VAPORS MAY BE PRESENT. A SPARK COULD CAUSE AN EXPLOSION OR FIRE! DO NOT STORE/OPERATE UNIT IN FREEZING  ENVIRONMENTS!

  • Page 14: Engine/Burner Fuel Tank

    INSTALLATION & PREPARATION WARNING DO NOT OPERATE IN AN ENCLOSED AREA. USE  THIS PRODUCT ONLY IN WELL VENTILATED  AREAS! THE EXHAUST CONTAINS CARBON MONOXIDE, A POISONOUS, ODORLESS AND INVISIBLE GAS.  BREATHING THIS GAS CAN CAUSE SERIOUS INJURY, ILLNESS & POSSIBLE DEATH. ENGINE/BURNER FUEL TANK DANGER DO NOT SMOKE WHILE FUELING!  DO NOT FILL THE FUEL TANK WHILE UNIT IS  RUNNING OR HOT. ALLOW UNIT TO COOL FOR  TWO MINUTES BEFORE RE-FUELING.  DO NOT FILL FUEL TANK TO POINT OF  OVERFLOWING. ALLOW APPROXIMATELY 1/4” OF  TANK SPACE FOR FUEL EXPANSION. ALWAYS STORE FUEL AWAY FROM THE WASHER  WHILE THE UNIT IS RUNNING OR HOT. 1. Review “Risk of Explosion or Fire” Warnings pg. 7, before fueling. 2. Locate the Safety Decals on your unit and heed their warnings. 3. Gasoline Engines: A minimum of 85 octane fuel is recommended for  use with this unit. DO NOT MIX OIL WITH GASOLINE.     Burner Fuel: Use No. 1 or No 2 fuel oil/diesel or kerosene. 4. Purchase gasoline fuel in quantities that may be used within 30 days.  Use of clean, fresh lead-free gasoline is recommended. Leaded  gasoline may be used if lead-free is unavailable. DO NOT use gasoline  containing methanol or alcohol. 5. Check the engine oil level before starting the engine. (See Engine  manual.) 6. Fill fuel tanks according to accompanying manufacturer’s instruction  manual. 7. Refer to the Engine Manual supplied with this unit for proper engine  adjustment procedures. 8. Review the engine manual accompanying this pressure washer for  correct engine start-up and maintenance procedures.

  • Page 15: Dual Lance Assembly With Adjustable Pressure

    The 15° nozzle (YELLOW): This is a chiseling nozzle. The spray should or items attached with adhesive backings. Uses: Removing weeds  be directed at a 45° angle to the surface and used like a scraper to remove from sidewalk cracks, stubborn stains from concrete, masonry, alumi- paint, grease and dirt. Uses: Surface preparation (removing mildew stains and paint chips).

  • Page 16: Nozzle Connection

    3. The 40° nozzle (WHITE): NOZZLE CONNECTION: 0° WATER SUPPLY: 1. Be certain the trigger gun is locked in the “OFF” position.  1. Be certain the trigger gun is locked in the “OF 40° This is a wash nozzle. This wide spray patter 1. Select a water sup 2. The nozzle assembly should be disconnected from the gun/wand  2. The nozzle assembly should be disconnec over a large area and is recommended for mod at least 3/4"...

  • Page 17: Unloader

    WATER INLET STRAINER must be a minimum of 20 pounds per square inch (PSI) m of 125 PSI. (A typical outdoor faucet will generally if turned completely "ON".) must be approximately one gallon more than the outgoing the pressure washer nameplate.

  • Page 18: Thermal Relief Valve

    INSTALLATION & PREPARATION THERMAL RELIEF VALVE To ensure the water temperature does not exceed acceptable levels,  never allow the pressure washer to operate in the bypass mode (with the  unit running and the trigger closed) for more than three minutes. A “thermal relief valve” has been added to this unit to protect the pump.  It may begin to open and release water if the water temperature in the  pump has exceeded 140° F. This will allow fresh, cool water to enter the  system. PRE-START INSPECTION PROCEDURES Before starting the unit, perform the following procedures: 1. Check the oil level in the pump and engine. 2. Inspect the water inlet strainer. Clean or replace if necessary. See  “Water Supply”, #2, pg 16. 3. Check all hose connections to ensure they are securely tightened. See  “Water Supply”, #3, pg. 16. 4. Inspect for system water leaks, oil leaks and fuel leaks. If a fuel leak is  found, DO NOT START UNIT! See “Risk of Explosion or Fire”, pg. 7.  Be sure that all damaged parts are replaced and that the mechanical  problems are corrected prior to operation of the unit. If you require  service, contact Customer Service. 5. Inspect high pressure hoses for kinking, cuts and leaks. If a cut or leak  is found, DO NOT USE HOSE! Replace hose before starting unit. See  “Risk of Injection” pg. 8. Be sure that all damaged parts are replaced  and that the mechanical problems are corrected prior to operation of  the unit. If you require service, contact Customer Service.

  • Page 19: Operation

    OPERATION Operating Instructions PRIMING THE PUMP It is essential to prime the pump and flush the unit each time the water  supply has been disconnected from the unit OR whenever the unit has  set for any period of time. This unit has a steel coil which, after setting,  will cause the water remaining in the coil from the previous usage to  turn brown or black. This contaminated water must be flushed from the  system before start-up. This procedure should be performed without the  high pressure hose, gun and nozzle assembly installed. 1. Turn on the water supply. 2. Low pressure water will begin flowing from the water outlet. This al- lows the unit to prime and purge any air from the system. The unit is  primed when water flow is uninterrupted by air. 3. Once the system is flushed, turn off the water supply and connect the  high pressure discharge hose/gun to the water outlet of the unit. 4. Turn on the water supply. CAUTION BE CERTAIN THE HOSE, GUN & LANCE ASSY. ARE NOT  CONNECTED TO THE UNIT WHILE PRIMING THE PUMP. PRIMING  ALLOWS MINERAL DEPOSITS TO BE RELEASED FROM THE  SYSTEM WHICH WOULD OBSTRUCT OR DAMAGE THE GUN  AND NOZZLE ASSEMBLY RESULTING IN COSTLY REPAIRS. START-UP/COLD WATER OPERATION WARNING KEEP CLEAR OF NOZZLE! NEVER PLACE HAND OR FINGERS IN  FRONT OF NOZZLE! DO NOT DIRECT DISCHARGE STREAM AT PEOPLE OR PETS! CAUTION DO NOT ALLOW SPRAY PATTERN TO REMAIN ON A FIXED AREA FOR AN EXTENDED PERIOD OF TIME. POSSIBLE DAMAGE MAY OCCUR TO THE AREA.
  • Page 20 OPERATION 1. Refer to the “Safety Precautions” pgs. 7-11 before starting the unit. 2. Locate the Safety Decals on your unit and heed their warnings. 3. Ensure that the switch is in the “OFF” position. 4. Perform the following engine start-up procedures. a. Point the trigger gun in a safe direction, disengage the safety lock  on the gun and squeeze the trigger. b. Brace yourself for kickback from the high pressure created by the  pump once the engine has started. c. Hold the trigger gun open while starting the engine according to the  manufacturer’s instructions in the engine manual accompanying this  unit. 5. Once the unit has started, perform the following procedures with the  gun open: a. Inspect for system water leaks, oil leaks and fuel leaks. If a fuel leak  is found, TURN UNIT OFF IMMEDIATELY! See “Risk of Explosion  or Fire”, pg. 7. Be sure that all damaged parts are replaced and that  the mechanical problems are corrected prior to operation of the  unit. If you require service, contact Customer Service. b. Inspect high pressure hoses for kinking, cuts and leaks. If a cut or  leak is found, DO NOT TOUCH HOSE AT LEAK!!! TURN UNIT OFF  IMMEDIATELY! Replace hose before starting the unit. See “Risk of  Injection or Severe Cutting Injury” pg. 8. Be sure that all damaged  parts are replaced and that the mechanical problems are corrected  prior to operation of the unit. If you require service, contact Cus- tomer Service. 6. Trigger the gun several times and try adjusting the water pressure by  rotating the grip on the lance. NEVER place hand or fingers in front of  the nozzle or look directly into the nozzle! High pressure water creates  a risk of severe injury! 7. Do not allow unit to operate in bypass mode (with trigger closed) for  more than three minutes without triggering the gun. Failure to follow  this simple rule can cause premature failure of pump packings, result- ing in costly pump repair. 8. Your pressure washer can deliver high pressure spray and a variety  of spray patterns using cold water. If you wish to use the Hot Water,  Steam application or Cleaning with Detergents, for the correct proce- dures.

  • Page 21: Hot Water Operation

    OPERATION HOT WATER OPERATION WARNING THE WATER TEMPERATURE COULD BECOME VERY HOT DURING  HOT WATER OPERATION. BE CAUTIOUS WHEN ADJUSTING  PRESSURE OR CONTROLLING THE TRIGGER GUN/ LANCE  ASSEMBLY. 1. Follow the steps outlined for “START-UP/COLD WATER  OPERATION”. 2. Move the Burner Switch to the ON position. On initial start-up, water  will begin turning hot in approximately 20 seconds and will reach  maximum temperature in approximately 2-1/2 minutes, provided the  trigger remains squeezed. The burner will stop firing when the trigger  is released. At this point, the unit is operating as a hot water pressure washer. Be  extremely cautious when adjusting the pressure and controlling the  trigger gun/ lance assembly to avoid the possibility of burns. NOTICE While spraying, it is normal for the burner to fire intermittently. The high  limit switch will cause combustion to cease when the temperature of  the discharged water exceeds the temperature setting of the switch.  Combustion will begin again when the water temperature drops below  the minimum setting . CLEANING WITH DETERGENTS UNDER LOW PRESSURE NOTICE This feature is designed for use with mild detergents only. Since the cleaning solution travels through the heat exchanger coil, DO NOT use corrosives as they will cause extensive damage as well as pose a considerable safety hazard. NOTICE This injection system is designed to apply detergents under low pres- sure only. It will not allow detergent solutions to be introduced into the  system unless the adjustable nozzle is set in the low pressure mode.

  • Page 22: Shutdown

    Combustion will begin again when the temperature drops below the minimum setting. connect the desired high pressure nozzle into the end of the wand.  point, the unit is operating as a hot water pressure washer. Be certain to remely cautious when adjusting the pressure and controlling the trigger Unlock the trigger gun and spray. It will take about 30 seconds to ...

  • Page 23: Maintenance

    MAINTENANCE Storage & Maintenance Instructions SPECIFIC MAINTENANCE ENGINE: The engine instructions that accompany your unit detail specific  procedures for maintenance of the engine. Following the engine  manufacturer’s recommendations will extend engine work life. PUMP: Change the pump oil after the first 50 hours of operation. After  initial change, every 3 months or 250 hour intervals are recommended.  If oil appears dirty or milky, changes may be required in greater  frequency. Use pump oil SAE30W non-detergent and fill only to the  center of the oil sight glass. DO NOT overfill. QUICK COUPLERS: There is an o-ring seal inside the female quick  coupler. This o-ring will deteriorate or, if the unit is allowed to pump  without the high pressure hose or nozzle attached, the o-ring may be  blown out occasionally. Simply insert a replacement o-ring to correct  the leak. (Additional o-rings can be purchased from your dealer.) NOZZLE: Water flow through the spray nozzle will erode the orifice,  making it larger, resulting in a pressure loss. Nozzles should be  replaced whenever pressure is less than 85% of the maximum. The  frequency of replacement will depend upon such variables as mineral  content in the water and number of hours the nozzle is used. BURNER AIR ADJUSTMENT: The air shutter has been factory preset  for proper operation between sea level and 2000 feet elevation at  standard conditions (60°F ambient water and air temperatures). To  assure maximum combustion efficiency at colder temperatures and  higher altitudes, it will be necessary to adjust the air supply to the  combustion chamber. A smoke spot test is recommended during any  air shutter adjustment. This will aid in maximizing the burner efficiency  and avoid the inefficient operation and excessive sooting of the  combustion chamber. 1. The machine must be running and the burner on. 2. Take a smoke spot test to determine if more or less air is required for  proper combustion. a. If the test is greater than a #3 smoke, turn the shutter arm  counterclockwise to increase the air flow into the combustion  chamber.

  • Page 24: Winterizing

    MAINTENANCE 5. Repeat steps 2 and 3 until step 4 is attained. LEAKS: Promptly eliminate any leaks found in the pumping system by  removing suspect parts, applying thread sealant to the threads and  reinstalling. NOTICE If using Teflon tape, be certain no tape gets inside any plumbing to  prevent the possibility of a plugged spray nozzle. WINTERIZING 1. For storage and transportation purposes in subfreezing ambient tem- peratures, it will be necessary to winterize this unit. This unit must be  protected to the lowest incurred temperature for the following reasons: a. If any part of the pumping system becomes frozen; excessive  pressure may build up in the unit which could cause the unit to burst  resulting in possible serious injury to the operator or bystanders. b. The pumping system in this unit may be permanently damaged if  frozen. FREEZE DAMAGE IS NOT COVERED BY WARRANTY.  If you must store your unit in an area where the temperature may fall  below 32°F, you can protect your unit by following the procedure outlined  below. 1. Gather the following items: a. Two 5 gallon containers. b. One gallon of antifreeze. (Use an environmentally safe antifreeze.) c. Water supply. d. Three foot hose, 1/2-3/4 I.D. with a 3/4 inch male garden hose fit- ting. 2. Procedure: a. To start winterizing, unit must be run according to the “Start-up  Cold Water Operation”. b. After running, shut off the unit and water supply. c. Relieve system pressure by pointing the trigger gun in a safe direc- tion and squeezing the trigger until water flow ceases to exit the Lance  Assy.  d. Lock the trigger gun in the OFF position and adjust the Lance to the  low pressure mode. e. Remove the water supply hose from the unit and attach the 3 foot  hose securely to the inlet connection. f. Shut off the detergent injector (if applicable). g. Fill one 5 gallon container with water.
  • Page 25 MAINTENANCE h. Holding the 3 foot hose in an upright position, completely fill the  hose with water. Then plug the open end of the hose with your thumb  or finger. Place the plugged end into the 5 gallon container of water. i. Start the unit. Trigger the gun several times until all the air is worked  out of the system (unit is primed). j. With the trigger gun held open, siphon enough water out of the 5  gallon container until there is just enough water left to mix with the  antifreeze. k. Point the trigger gun into the empty container. (Be certain to wear  safety attire for protection from splashing.) l. Trigger the gun until the antifreeze begins to exit the trigger gun.  Release the trigger for 3 seconds, then trigger the gun for 3 seconds.  Continue cycling the trigger gun several times until all the antifreeze  mixture is siphoned from the container. m. Stop the unit. n. Detach the 3 foot hose from the unit and drain any excess antifreeze  back into the 5 gallon container storage & maintenance o. Disconnect the hose and trigger gun from the unit and drain any  excess antifreeze back into the 5 gallon container. p. Drain hose, trigger gun and lance assembly and store with the unit  in a safe non-freezing area. q. Store antifreeze solution for next use or dispose of according to  state EPA laws. NOTICE Proper winterizing is based on the recommended manufacturer’s  instructions listed on the “Protection Chart” shown on the back label of  most antifreeze containers. 3. OPTIONAL PROCEDURE: a. Shut the unit and water supply off. b. Relieve system pressure by pointing the trigger gun in a safe  direction and squeezing the trigger until water flow ceases to exit the  nozzle. c. Disconnect and drain the hose, trigger gun and lance assembly. d. Remove the coil drain plug from the heat exchanger inlet. e. Start the unit and allow it to run until all the water exits the unit.  Once the water has stopped flowing from the unit, turn off. NOTICE When using this procedure, use caution as ice chips can form from drops of water which could cause the unit to burst if starting before...

  • Page 26: Maintenance Chart

    9  12  MONTHS MONTHS MONTHS MONTHS Check engine oil level Change engine oil***** Check water pump oil level Change water pump oil ** Oil leak inspection Fuel leak inspection Water leak inspection Hose inspection Water inlet filter inspection Inspect belt Replace high pressure  nozzle*** Replace fuel filter Inspect fuel pump filter* Replace fuel nozzle* Check burner air adjust- ment Check burner electrodes* Test water pressure* Test fuel pressure* Test water temperature* Descale coil**** *       Must be performed by an authorized service technician. **     The pump oil must be changed after the first 50 hours of operation  and every 250 hours or 3 months, whichever comes first. ***       High pressure nozzle should be replaced whenever pressure is less  than 85%. ****   Scale build-up will vary with mineral content in the water and  amount of usage. Descaling can range from weekly to yearly  maintenance. ***** The engine oil must be changed after the first 8 hours of operation  and every 50 hours or 3 months, whichever comes first.

  • Page 27: Troubleshooting

    TROUBLESHOOTING Troubleshooting TROUBLESHOOTING CHART SYMPTOM PROBABLE CAUSE REMEDY Engine will not start Various engine problems Refer to the Engine Manual accompanying your unit. Unit components are frozen. Allow to thaw. If any part of the  unit becomes frozen; excessive  pressure may build up in the  unit which could cause the unit  to burst resulting in possible  serious injury to the operator or  bystanders. No discharge at  Inadequate water supply. Ensure hose is 3/4” diameter  nozzle when trigger  and incoming water supply is  mechanism is  turned on. squeezed. Low or fluctuating  Kink in water inlet hose. Remove kink. pressure. Kink in high pressure  Replace kinked high pressure  discharge hose. hose. Water inlet screen  Remove screen, clean or  obstructed. replace. Pump sucking air. (Prime  Tighten all water intake ...
  • Page 28 TROUBLESHOOTING SYMPTOM PROBABLE CAUSE REMEDY Detergent will not  Detergent strainer is not  Check, submerge if necessary. siphon into Low  completely submerged in  Pressure Detergent  detergent solution. mode. Detergent strainer  Inspect, clean or replace. obstructed. Detergent hose cut,  Inspect, clean or replace. obstructed or kinked. Detergent adjusting knob  Open adjusting knob. Refer to  turned to closed position. “Cleaning with Detergents”. Too many high pressure  Use one extension maximum. hose extensions attached to  the water outlet. Nozzle assembly is plugged. Clean or replace. Ball & Spring in Venturi  Remove, clean or replace. stuck. Water flows back into  Ball & Spring in Venturi  Remove, clean or replace. detergent container. reversed, missing or  corroded. Water flows from the  Trigger gun is  Repair or replace. nozzle when the trigger ...
  • Page 29 TROUBLESHOOTING SYMPTOM PROBABLE CAUSE REMEDY Burner will not ignite Ignition module Consult your Customer Service Ignition electrodes  With unit running and trigger  damaged or worn. gun closed, look through burner  sight glass to ensure there is  sparking across electrodes. No voltage Consult your Customer Service. Pressure switch override. Pressure should be over 250  PSI/18 Bar to allow burner to  come on. High limit switch override. Unit will automatically reignite  when cool. Improper burner air  Adjust as explained on page 26. adjustment. Fuel solenoid valve failure. Replace. Burner runs erratically. Water in the fuel oil. Drain fuel filter/water separator.  Drain fuel tank, and replace with  clean fuel. Dirty fuel filter Replace. Dirty fuel nozzle. Replace. Improper air adjustment  Adjust as explained on page 26. setting. Fuel pump malfunctioning.

  • Page 30: Parts List

    PARTS LIST Parts List SPECIFICATIONS MODEL NUMBER HW3513HAD Operating Pressure (PSI/Bar) 3500 / 241 (+/- 5%) Water Volume (GPM/lpm) 3.27 / 12.38 (+/- 5%) Outlet Water Temperature (F/C) 140°F/78°C (+/- 20°F) rise above inlet ambient  (210°F/ 99°C maximum) Engine: Honda Model GX390 Engine Type Four Stroke, Overhead Cam, Single Cylinder Oil Type SAE10W-30 Oil Capacity (oz./liter) 37 / 1.1 Low Oil Protection Oil Alert Fuel Type Unleaded Gasoline 86 Octane Minimum Fuel Capacity (Qt./liter) 1.6/6.0 Starting Recoil Rope Max No Load RPM 3600 (+/- 100) High Pressure Pump: Direct Driven, Oil Bath, Triplex Piston Oil Type SAE30W Non-Detergent Oil Capacity (oz./lter) 15.0 / 0.44...
  • Page 31 PARTS LIST SPECIFICATIONS CONT. MODEL NUMBER HW3513HAD Fuel Consumption (GPH/LPH) 2.1 GPH Continous Burning Electro Magnetic Firing (EMF) System: Belt Driven (Patent #5,954,494) Ignition Transistorized Magneto Control Voltage 12 Volt DC Blower Forced Air Heat Exchanger: Vertical, Top fi red, Dual Spiral Coil BTU Input 294,000 Effi ciency 86% with #2 Fuel Oil/ Diesel Smoke Density 0-3 per ASTM D2156 Controls: On/Off Switch Industrial grade rocker switch Pressure Switch Shuts off burner fuel supply upon trigger  release High Limit Switch Shuts off burner fuel supply when outlet water  temp. exceeds 210°F / 99°C Fuel Solenoid: 12 Volt Safety Relief: Relieves excess system pressure Unit Net Weight (Lbs/Kg) 428 / 194 Unit Shipping Weight (Lbs/Kg) 551 / 250...

  • Page 32: Flow Chart

    PARTS LIST FLOW CHART FLOW CHART EMF SYSTEM FLOW CHART EMF SYSTEM...
  • Page 33 PARTS LIST GENERAL THEORY OF OPERATION WATER FLOW: Connect a pressurized water source to the INLET GAR- DEN HOSE CONNECTION (1) and turn on the water supply. The water then travels into the TRIPLEX HIGH PRESSURE PUMP (2)  which has an UNLOADER (6) that bypasses the water when the trigger  gun is closed. To protect the pump from heated water during this bypass  stage, a HEAT DUMP VALVE (5) will open at 140°F/60°C allowing the  heated water to escape. The Heat Dump Valve automatically resets when  the water cools. The PRESSURE SWITCH (7) controls the fuel supply to  the burner. From there, the water will flow into the HEAT EXCHANGER INLET (10)  where it is heated when the burner is on. As the water exits the HEAT  EXCHANGER OUTLET (11), it enters a safety system which protects the  operator from danger. The safety system contains a HIGH TEMPERA- TURE LIMIT SWITCH (12) which senses the water temperature and  shuts off the fuel supply to the burner if it gets too hot. If the unloader  fails to bypass the water or the burner remains on when the trigger gun  is closed, the SAFETY RELIEF (13) will relieve and allow water to exit  safely. The heated water then flows through the HIGH PRESSURE HOSE (14)  and to the TRIGGER GUN ASSEMBLY (15) which allows the operator  to control the water spray. When the trigger gun is open, the water flows  through the LANCE (16) and exits the NOZZLE (17). FUEL FLOW: The Fuel Pump draws fuel from the FUEL TANK (18)  through a replaceable FUEL FILTER (4) and into the FUEL PUMP (3).  Fuel exits the fuel pump, into a FUEL SOLENOID VALVE (8) which con- trols fuel flow to the FUEL NOZZLE (9) where it ignites and burns in the  heat exchanger. EMF SYSTEM: The patented Electro Magnetic Firing (EMF) System is an  integrated system which gives all the requirements for combustion. The BELT (1) from the power source turns the HUB (2) which has two  EXTERIOR MAGNETS (3) attached. As these magnets spin past the IG- NITION MODULE (4), a magnetic flux is created from which the ignition  module produces a high voltage. This voltage arcs across the electrodes  giving the spark that is needed for ignition.

  • Page 34: Frame Assembly

    PARTS LIST FRAME ASSEMBLY 29 28 13 12 11 10 Mi-T-M SCALE: DATE: 10/27/14 HSP-35 DRAWING/PART NO: HSP-3500 ASSEMBLY...
  • Page 35 PARTS LIST FRAME ASSEMBLY SPECS ITEM DESCRIPTION PART # Hose Reel Mounting Bracket 20-1395A42 Washer 28-0003 Bolt 27-0072 Heat Exchanger / Emf Assy Bolt 27-9524 Locknut 30-0155 Bolt 27-1201 Brake Bracket 20-1393A01 Bolt 27-0015 Bolt 27-9550 Push/Pull Toggle Clamp 33-0400 Engine Shim 33-0169 Bolt 27-9529 30-3023 Engine/Pump Assembly Fuel Tank Assembly 850-0193 Fuel Hose 15-0147 Electric Box Assembly Frame 5-0342A42 Nozzle Holder...
  • Page 36 PARTS LIST ENGINE/ PUMP ASSEMBLY ENGINE/PUMP ASSEMBLY...

  • Page 37: Engine/Pump Assembly

    PARTS LIST ENGINE/PUMP ASSEMBLY ITEM DESCRIPTION PART # Engine - Honda GX390 Recoil 1-0205 Washer 28-0605 Oil Drain 24-0143 Adapter Flange 38-0049 Bolt 27-0418 Sheave 10-0077 Belt 11-0037 43-0088 Bolt 27-8434 Adapter Plate 38-0051 High Pressure Hose 15-0194 Elbow 23-0034 Relief Valve 22-0005 Pressure Switch 22-0171 Plug 23-0244 Filter - Water 19-0096 Elbow 23-0119 Hose Clamp 42-0011 Hose* (Two Feet Required)

  • Page 38: High Pressure Pump

    PARTS LIST HIGH PRESSURE PUMP (3-0194) HIGH PRESSURE PUMP ITEM DESCRIPTION PART # Bolt 27-8884 Shaft Cover 46-0713 Oil Seal (see kit 70-0337) 26-0194 O-Ring (see kit 70-0337) 25-0397 Bearing 48-0062 Set Screw 27-8886 Crankshaft (after serial #28511) 46-0959 Crankshaft (before serial #28511) 46-0734 Plug 39-0102 O-Ring 25-0325 Plug 39-0086 Bolt 27-8885 Crankcase Cover 46-0719 O-Ring 25-0370 Oil Sight Glass 46-0670 Reflector...
  • Page 39 PARTS LIST ITEM DESCRIPTION PART # Connecting Rod (after serial #28511) 46-0922 Connecting Rod (before serial #28511) 46-0697 Piston Pin 46-0698 Plunger Rod 46-0699 Slinger Washer (see kit 70-0352) 46-0700 Back-up Ring (see kit 70-0352) 25-0404 O-Ring (see kit 70-0352) 25-0382 Piston (see kit 70-0352) 46-0701 Washer (see kit 70-0352) 26-0191 30-6020 Oil Dipstick 39-0090 Bearing Cap 46-0703 Shim - 0.1mm (qty. varies 1-3) 46-0704 Shim - 0.2mm (qty. varies 1-3) 46-0705 O-Ring (see kit 70-0337) 25-0380 Bearing (after serial #28511) 48-0072 Bearing (before serial #28511) 48-0061 Crankcase 46-0811 Oil Seal (see kit 70-0337) 46-0931 O-Ring (see kit 70-0177)
  • Page 40 PARTS LIST ITEM DESCRIPTION PART # Valve Spring (see kit 70-0179) N/A Sep. Valve Cage (see kit 70-0179) N/A Sep. Plug 39-0096 O-Ring 25-0387 Bolt 27-8440 Lockwasher 29-0154 REPLACEMENT KITS KIT # DESCRIPTION ITEMS # OF  # OF  ASSEBLIES CYLINDERS 70-0177 Kit - High Pressure  34, 35, 37 Seals 70-0178 Kit - Support Rings 70-0179 Kit - Valve Kit 46-50 70-0337 Kit - Oil Seals Kit 3, 4, 17,  1, 1, 1, 1, 3 30, 33 70-0352 Kit - Piston Kit 21-26...

  • Page 41: Unloader/Manifold Assembly

    PARTS LIST UNLOADER/MANIFOLD ASSEMBLY UNLOADER/MANIFOLD ASSEMBLY REF. # DESCRIPTION PART # Hose* (two feet required) 15-0007 Hose Clamp 42-0011 Elbow 23-0119 High Pressure Hose 15-0194 Plug 23-0238 Unloader 850-0252 Chemical Injector 50-0052 Manifold Block 51-0025 HP Hose 15-0202 Strainer 19-0050 Chemical Hose* (six feet required) 15-0021 *MUST ORDER IN ONE FOOT LENGTHS)

  • Page 42: Unloader

    PARTS LIST UNLOADER ITEM DESCRIPTION PART # VENDOR PFHMS - M6-1.00 x 8mm (SEE KIT 70-0647) 27-2772 B13001 SEE KIT ITEM KNOB - UNLOADER BLACK (SEE KIT 70-0647) DESCRIPTION PART # 7-0250 B13002 SEE KIT KNOB - M20-1.00P (SEE KIT 70-0647) B13003 SEE KIT SPRING - 14mm O.D.

  • Page 43: Pressure Switch

    PARTS LIST PRESSURE SWITCH (22-0171) PRESSURE SWITCH REF. # DESCRIPTION PART # Pressure Switch 22-0243 Screw Cover O-Ring (See 70-0306) N/A Sep. Micro Switch Retainer Clip Body O-Ring (See 70-0306) N/A Sep. Back-Up Ring (See 70-0306) N/A Sep. Piston Washer Spring 49-0145 Washer Plastic Housing O-Ring (See 70-0306) N/A Sep. Wire Assembly O-Ring Repair Kit (inc. 4, 8-9, 15) 70-0306...

  • Page 44: Detergent Injector

    PARTS LIST DETERGENT INJECTOR (50-0052) DETERGENT INJECTOR ITEM DESCRIPTION PART # Detergent Injector (inc. 2-11) 50-0052 Orifice (2.1mm) 50-0057 Injector Body Spring (see 852-0056) N/A Sep. Ball (see 852-0056) N/A Sep. O-Ring (see 852-0056) N/A Sep. Piston Retainer 50-0156 Spring 49-0056 O-Ring (see 852-0056) N/A Sep. Adjustable Shutter Barb 50-0157 Adjustment Knob 50-0158 Injector Repair Kit (inc. 4-6, 8 852-0056...

  • Page 45: Heat Exchanger/Emf System

    PARTS LIST HEAT EXCHANGER/EMF SYSTEM HEAT EXCHANGER/EMF SYSTEM ITEM DESCRIPTION PART # Pressure Relief Valve 22-0273 QC Socket 17-0004 Pipe Nipple 24-*0165 Outlet Connector 24-0138 HI Limit Switch 32-0798 Drain Plug Assembly 850-0218 Adapter 23-0279 Elbow 23-0034 Street Tee 23-0058 HP Hose 15-0202 30-3023 Bracket 20-0360A01 Fuel Pump Bracket 20-0381A01 Fuel Pump Plate 20-0363A01...
  • Page 46 PARTS LIST ITEM DESCRIPTION PART # HP Fuel Hose 15-0165 Elbow 23-0288 Fuel Solenoid 44-0100 Bolt 27-9524 Elbow 23-0237 Fuel Hose 15-0147 Fuel Filter/Water Separator 19-0070 Nipple 24-0145 Fuel Pump 3-0020 Idler Pin 33-0211 Tensioner Sheave Shaft Assembly 850-0166 Locknut 30-0159 Sheave Assembly 850-0177 Idler Shaft 33-0212 Tensioner 10-0071 Washer 28-0003 Coupling 33-0225 30-3022 EMF Assembly 850-0403 Access Panel...

  • Page 47: Boiler Assembly

    PARTS LIST BOILER ASSEMBLY BOILER ASSEMBLY (850-0226) ELECTRODE GAP SETTINGS...
  • Page 48 PARTS LIST ITEM DESCRIPTION PART # Bolt 27-8879 Air Diverter 20-0378A01 30-0137 Star Washer 28-1009 Air Diverter Stem 20-0377A01 Plug 24-0034 30-0121 Washer 28-0521 Outer Wrap 20-0376A42 Insulation 33-0250 Heat Exchanger Coil 66-0011 Inner Pan Assembly 20-0372 Top Pan 20-0371A01 Lockwasher 28-1028 Acorn Nut 30-6002 Fuel Nozzle 18-0308 Fuel Nozzle Holder 23-0292 Bolt 27-8878 Electrode Assembly Kit (inc. 4, 18, 20-29) 850-0351 Bolt 27-8807...

  • Page 49: Gun/Wand/Hose Assembly

    PARTS LIST GUN /WAND/HOSE ASSEMBLY GUN/WAND/HOSE ASSEMBLY ITEM DESCRIPTION PART # 16-0001 Quick Connect 17-0005 QC Socket 17-0004 Hose 15-0166 Quick Connect 17-0006 Duel Lance 16-0417 QC Socket 17-0028 Nozzle 00035 18-0392 Nozzle 15035 18-0393 Nozzle 40035 18-0396...

  • Page 50: Dual Lance Assembly

    PARTS LIST DUAL LANCE ASSEMBLY (16-0416) DUAL LANCE ASSEMBLY ITEM DESCRIPTION PART # Dual Lance Assembly - 36” (inc. 2-11) 16-0417 Detergent Nozzle 18-0110 30-6001 Clamp 16-0420 Lower Valve Cover (see 16-0416) N/A Sep. Housing (see 16-0416) N/A Sep. Lance 16-0419 Handle Repair Kit 70-0419 Lance (see 16-0416) N/A Sep. Screw 27-8196 Nozzle Adapter 24-0280...

  • Page 51: Fuel Tank

    PARTS LIST FUEL TANK (850-0193) FUEL TANK FUEL TANK (850-0193) FUEL TANK ITEM DESCRIPTION FUEL CAP FUEL GAUGE ITEM DESCRIPTION PART # FUEL GAUGE GROMMET FUEL PICK UP Fuel Cap 12-0033 NIPPLE DECAL - CAUTION: RISK OF FIRE (SEE 71 Fuel Gauge 22-0475 ELBOW 850-0193 070113 CH FUEL TANK...

  • Page 52: Fuel Pump & Fuel Solenoid

    PARTS LIST FUEL PUMP (3-0020) & FUEL SOLENOID (44-0100) FUEL PUMP (3-0020) & FUEL SOLENOID (44-0100 FUEL PUMP & FUEL SOLENOID FUEL PUMP (3-0020) & FUEL SOLENO REF. # DESCRIPTION FUEL Cord-Din Connector 20) & FUEL SOLENOID (44-0100) REF. # DESCR Base Plate Cord-D...

  • Page 53: Emf System

    PARTS LIST EMF SYSTEM (850-0403) EMF SYSTEM...
  • Page 54 PARTS LIST ITEM DESCRIPTION PART # EMF Assembly 850-0403 Blower Fan 44-0099 Set Screw Locknut 30-0177 Blower Flange Assembly 850-0402 Sealed Bearing 48-0041 Blower Flange 38-0066 Spacer 33-0206 Blower Shaft 20-0347 Woodruff Key 43-0080 Clamp 32-0403 Screw 27-2070 Stator Assembly 850-0401 Bolt 27-0740 38-0041 Washer 28-0001 Ignition Assembly 850-0413...

  • Page 55: Electric Box Assembly

    PARTS LIST ELECTRIC BOX ELECTRIC BOX ASSEMBLY ITEM DESCRIPTION PART # Electric Box Hardware Kit 70-0169 Screw 27-3350 Rocker Switch 32-0422 Electric Box Lid 32-0430A01 Capacitor 32-1113 Terminal Strip 32-0394 Connector 32-0085 Bolt 27-8497 Electric Box 32-0429A01 Electric Box Bracket 20-0380A01 Locknut 30-0152...
  • Page 56 WIRING SCHEMATIC PARTS LIST WIRING SCHEMATIC WIRING DIAGRAM WIRING DIAGRAM...

  • Page 57: Statement Of Warranty

    WARRANTY STATEMENT OF WARRANTY The manufacturer warrants all parts, (except those referred to below), of  your new pressure washer to be free from defects in materials and work- manship during the following periods: For Lifetime against freezing and cracking: Pump Manifold For Seven (7) Years from the date of original purchase: High Pressure Pump For Three (3) Years from the date of original purchase: Heat Exchanger Coil For Two (2) Years from the date of original purchase: Frame                              Plumbing Guard or Shields             Pulleys For One (1) Year from the date of original purchase: Adjustable Thermostat    GFCI Cord Selector switch               Starter Contactor Overload For Six (6) months from the date of original purchase: Ignition Transformer         Burner Motor For Ninety (90) days from the date of original purchase: Unloader Valve                Electrodes Fuel solenoid                   High Limit thermostat Fuel Pump                       Pressure Switch Safety Relief Valve For Thirty (30) days from the date of original purchase: High Pressure Hose        Trigger Gun Strainers / Filters             Wand Defective parts not subject to normal wear and tear will be repaired  or replaced at our option during the warranty period. In any event,  reimbursement is limited to the purchase price paid.

  • Page 58: Warranty Exclusions

    WARRANTY WARRANTY EXCLUSIONS 1. The motor is covered under separate warranty by its respective  manufacturer and is subject to the terms set forth therein. 2. Normal wear parts: Pump Packings       Spray Nozzles Pump Valves           Detergent Valves Fuel Filters              Quick Couplers/screw connects O-rings                   Belts 3. This warranty does not cover parts damaged due to normal wear,  misapplication, misuse, operation at other than recommended speeds,  pressures or temperature. Parts damaged or worn because of the use  of caustic liquids or by operation in abrasive or corrosive environments  or under conditions causing pump cavitation are not warranted. Failure  to follow recommended operating and maintenance procedures also  voids warranty. 4. The use of other than Genuine Repair Parts will void warranty. Parts  returned, prepaid to our factory or to an Authorized Service Center  will be inspected and replaced free of charge if found to be defective  and subject to warranty. There are no warranties which extend beyond  the description of the face hereof. Under no circumstances shall the  manufacturer bear any responsibility for loss of use of the unit, loss  of time or rental, inconvenience, commercial loss or consequential  damages.
