- Page 1 PRESSURE WASHERS' B275HA - B389HA - B2565HA/HAS/HG/HGS B4013HGS - B4015RA CD-3513HWBSGEN - PE-4013HWPSGEN PE-5024HWEBGEN - X-3513HWBGEBCD USER MANUAL Model shown PE-5024HWEBGEN BEFORE USE YOU MUST READ THIS MANUAL COMPLETELY – RETAIN FOR FUTURE Licensed by BE Pressure Supply Inc, Canada...
-
Page 2: Operation Notes & Record Of Identification Numbers
OPERATION NOTES Do not leave Warranty is void if High pressure machine running you exceed pre- sprays can cause longer than 1 Do not let Always wear eye set pressure serious bodily the machine minute without protection. PSI causing severe injury. -
Page 3: Table Of Contents
CONTENTS o’s Section Description Page N OPERATION NOTES & RECORD of IDENTIFICATION NUMBERS 1. SAFETY 4 - 6 2. SAFE OPERATION 7 - 10 3. MACHINE PARTS 4. MODELS 5. ASSEMBLY 6. PRE-OPERATION CHECKLIST 7. STARTING YOUR MACHINE 15 - 17 8. -
Page 4: Safety
1.1.2. The machine should never be left it in a condition which would allow an untrained or unauthorised person/s to operate this machine. 1.1.3. All due care and diligence should be taken by the operator for the safety of and with regard to those around whilst using the machine 1.2. - Page 5 See your doctor immediately or go to hospital - let them know that you suspect carbon monoxide poisoning. 1.4. General fuel safety. 1.4.1. Fuel Safety additional information can be obtained from the Health and Safety Executive. 1.4.2. All fuels are Flammable.
- Page 6 1.5.1.3. Hand protection. 1.5.1.4. Protective clothing. 1.5.1.5. If item 1.5.1.1. Cannot be fulfilled then - Respiratory protective equipment should be used. 1.5.1.6. When defueling always use a propriety fuel retriever. 1.5.1.7. Always carry fuel in the correct and clearly marked container.
-
Page 7: Safe Operation
2. SAFE OPERATION A running engine gives off carbon monoxide, an odourless, colourless, poison gas. Inhaling carbon monoxide can cause headache, fatigue, dizziness, vomiting, confusion, seizures, nausea, fainting or death. 2.1. Only operate the pressure washer outdoors in a well-ventilated area. 2.2. - Page 8 2.7. When operating machine. 2.7.1. Tipping the machine at an angle may cause fuel to spill. 2.7.2. DO NOT spray flammable liquids. 2.8. When transporting or repairing machine. 2.8.1. Transport/repair with fuel tank EMPTY or with fuel shut off valve OFF.
- Page 9 2.13. Unintentional sparking. Unintentional sparking can result in fire or electric shock. 2.13.1. When adjusting or making repairs to your pressure washer 2.13.1.1. You must disconnect the spark plug wire from the spark plug and place the wire where it cannot contact spark plug.
- Page 10 2.15.1. NEVER operate the pressure washer without protective guards, housing or covers. 2.15.2. DO NOT wear loose clothing, jewellery or anything that may be caught in any rotating parts . 2.15.3. Tie up long hair and remove jewellery. 2.16. Eye protection.
-
Page 11: Machine Parts
Not fitted on model B275. Pressure Control Knob - Oil Level Indicator - Recoil Starter - Used for Varies pressure of high Level should be at Fuel Tank - Fill tank with starting the engine pressure spray. halfway. regular unleaded fuel. -
Page 12: Models
4. MODELS. B275HA B389HA B2565HA B2565HAS B2565HG B2565HGS B4013HGS CD-3513HWBSGEN PE-4013HWPSGEN PE-5024HWEBGEN X-3513HWBGENCD B4015RA Page 12... -
Page 13: Assembly
5.2.2. Make sure holes (C) in handle align with holes on handle supports. It may be necessary to move the handle supports from side to side in order to align the handle so it will slide over the handle supports. -
Page 14: Pre-Operation Checklist
6.1.5. Connect and tighten the garden hose to the water supply inlet connection, you will need a hose adaptor (supplied). 6.1.6. Water MUST be turned on prior to starting the washer, pull the spray trigger to make sure that water is moving the through the lines and out the nozzle without any leaks before starting the machine. -
Page 15: Starting Your Machine
7.4.1. Pull down on collar of quick connect, slide onto spray gun and let go of collar. 7.4.2. Tug on hose to be sure of tight connection. The high pressure stream of water that this equipment produces can cut through skin and its underlying tissues, leading to serious injury and possible amputation. - Page 16 OFF position. The engine must be connected to the battery to energize the fuel-cut off solenoid, allowing the engine to run. If the battery is disconnected, fuel flow to the carburetor will stop.
-
Page 17: Spray Tips
8.1.1. The quick–connect on the nozzle extension allows you to switch between four different quick connect spray tips. 8.1.2. The spray tips can be changed while pressure washer is running once spray gun safety lock is engaged. 8.1.3. The spray tips vary the spray pattern angle as shown above. -
Page 18: Spray Tips
8.2. Follow these instructions to change spray tips: 8.2.1. Pull back collar on quick–connect and pull current spray tip off. 8.2.2. Store spray tips in holder provided on the handle. Storing nozzles in the designated holder will help prevent debris clogging the tip. 8.2.3. -
Page 19: Shutting Down Your Machine
IMPORTANT You must flush the detergent siphoning system after each use by placing the filter into a bucket of clean water, then run the pressure washer in low pressure for 1-2 minutes. Contact with chemicals can cause bodily injury and/or property damage. NEVER use caustic liquid with the pressure washer. -
Page 20: Maintenance
10. MAINTENANCE Service and maintenance must be performed by an authorised agent. DO NOT tamper with, or attempt to adjust, the pressure switch or safety valve. Before moving, or carrying out any maintenance on the machine, make sure the ignition switch is OFF, and that the tank pressure has been vented. - Page 21 1. Replace air filter 1. Move choke to halfway position until engine runs smoothly. Engine “putts” or falters 1. Choke is opened too soon * All engine servicing to be taken to Manufacturer’s authorized service outlet. 11.2.2. Pump. Problem Cause...
-
Page 22: Winter Storage
12. WINTER STORAGE Anti-Freeze is poisonous and can be harmful or fatal if swallowed or inhaled. Do not drink antifreeze or solution. Avoid inhaling mist or hot vapours. If inhaled, remove affected person/s to fresh air. - Page 23 12.4.2. Fuel will become stale when stored over 30 days. Stale fuel causes acids and gum deposits to form in the fuel system or on essential carburetor parts. 12.4.3. Prior to storage, if the petrol has not been treated with a fuel stabilizer, it must be drained from the engine into an apporved container.
-
Page 24: Environmental Disposal
13. EVIROMENTAL DISPOSAL 13.1. Never pour remainders of oils, fuel mixtures into any drain, sewerage system or soil. Dispose of it in a proper, environmentally friendly way, e.g., at a special collecting point or re- cycling facility. 13.2. At the end of your pressure washers’ life, dispose of it in an environmentally friendly manner. -
Page 25: Specifications
14. SPECIFICATIONS 14.1.1. See engine manual supplied with machine. Model HONDA HONDA HONDA HONDA HONDA HONDA HONDA HONDA HONDA HONDA HONDA Powerease GC160 4 - GX270 4 - GX200 4- GX200 4- GX200 4 - GX200 4 - GX390 4 - GX390 4 - GX390 4 - GX390 4-... -
Page 26: Declarations
16. DECLARATIONS 16.1. Genpower Ltd confirms that this BE Pressure Washer conforms to the following CE directives: 2006/42/EC Machinery directive 2004/108/EC EMC directive 2000/14/EC Noise emissions directive 97/68/EC NRMM Emissions directive Page 26... - Page 27 NOTES Page 27...
- Page 28 GENPOWER LTD Isaac Way, London Road Pembroke Dock, UNITED KINGDOM, SA72 4RW T: +44 (0) 1646 687 880 F: +44 (0) 1646 686 198 E: sales@genpower.co.uk www.bepressure.co.uk...
