Liquid Propane Gas (LPG) Grill
Models BTH2616(A,B) LP, BTH3216(A,B) LP
Natural Gas (NG) Grill
Models BTH2616(A,B) NG, BTH3216(A,B) NG
BTH2616BLP/NG
FREE HELP
Grill Information Center:
FROM THE GRILL EXPERTS
Grand Hall is the expert on this product
and trained to help you with:
Ÿ
Assembly Questions
Ÿ
Grill Operation
Ÿ
Replacement of Damaged or Missing parts
visit www.grandhall.com or call:
1-800-474-5587
Monday - Friday 8:00am-4:30pm PST
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL #
__________________
(see silver CSA label on main body of grill)
BTH3216BLP/NG
BTH2616ALP/NG
(BTH2616B+UN2616ACT)
WARNING
!
Ÿ
Failure to comply with these instructions could
result in a fire or explosion that could cause
serious bodily injury, death or property damage.
Ÿ
Whether this grill was assembled by you or
someone else, you must read this entire manual
before using your grill to ensure the grill is
properly assembled, installed and maintained.
Ÿ
Use your grill at least 3 feet away from any
wall or surface. Use your grill at least 3 feet
away from combustible objects that can melt or
catch fire such as vinyl or wood siding, fences
and overhangs or sources of ignition including
pilot lights on water heaters and live electrical
appliances.
Ÿ
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
Ÿ
Never use your gas grill in a building, garage,
porch, shed, breezeway or any other enclosed
area.
Ÿ
Never obstruct the flow of ventilation air
around your gas grill housing.
Ÿ
Never disconnect the gas regulator or any gas
fitting while your grill is lit. A lit grill can ignite
leaking gas and cause a fire or explosion which
could result in property damage, personal injury
or death.
Operator's Manual
BTH3216ALP/NG
(BTH3216B+UN3216ACT)
Manual #
P80151148A - Date:2015/11/16
!
Advertisement
Related Manuals for Barbeques Galore Turbo BTH2616ALP
Summary of Contents for Barbeques Galore Turbo BTH2616ALP
- Page 1 Operator's Manual Liquid Propane Gas (LPG) Grill Models BTH2616(A,B) LP, BTH3216(A,B) LP Natural Gas (NG) Grill Models BTH2616(A,B) NG, BTH3216(A,B) NG BTH2616BLP/NG BTH3216ALP/NG BTH3216BLP/NG BTH2616ALP/NG (BTH2616B+UN2616ACT) (BTH3216B+UN3216ACT) FREE HELP WARNING Grill Information Center: FROM THE GRILL EXPERTS Ÿ Failure to comply with these instructions could Grand Hall is the expert on this product result in a fire or explosion that could cause and trained to help you with:...
-
Page 2: Table Of Contents
Table of Contents WARNING Primary Safety Warnings......1-3 Pre-Assembly Instructions.......3 Do not store or use gasoline or other Part Diagrams and Lists......4-10 flammable liquids or vapors in the Assembly Instructions.........10-14 vi c i ni ty o f t hi s o r any o t he r Use &... -
Page 3: Pre-Assembly Instructions
Pre-Assembly Instructions For Your Safety PRE-ASSEMBLY CAUTION Read and perform the following pre-assembly instruc- tions: Failure to comply with these instructions may result Tools Required for Assembly in a hazardous situation which, if not avoided, may • Protective work gloves result in injury. - Page 4 Hardware Parts List for Models BTH2616BLP/NG & BTH3216BLP/NG PART # PART DESCRIPTION PURPOSE OF PART P06013018C Hardware Pack For use in assembly of Models BTH3216B, BTH2616B S182G03061 Pan Head Screw 3/16" x 3/8" Install the Transformer Bracket(For BTH3216B Only) S182G03061 Pan Head Screw 3/16"...
- Page 5 Parts Diagram for Models BTH2616BLP/NG...
- Page 6 Parts List for Model BTH2616BLP/NG DESTRIPTION PART# QTY. P0014645A4 Lid Assembly P00601551A Temperature Gauge P00614031A Temperature Gauge Seat Lid Handle Bracket, Left P00307052E Lid Handle Bracket, Right P00308052E Lid Handle P00215041H Protective Pad P05518002I Lid Assembly Bracket, Left P033200074 Lid Assembly Bracket, Right P033200084 Lid Hinge with Nut P05501136L...
- Page 7 Parts List for Model BTH2616BLP/NG DESTRIPTION PART# QTY. Grease Tray Handle P0272017C4 Greas e Tray P027179234 Grease Tray Slide Set P05516140M Lighting Stick P05507140M Regulator Hos e Connector(LPG) P03901056C Regulator With Hose(LPG) P03635005A Regulator With Connector (NG) P03614005C Tank Tray Set (LPG) Y0340055 Hardware Pack P06013018C...
- Page 8 Parts Diagram for Model BTH3216BLP/NG...
- Page 9 Parts List for Model BTH3216BLP/NG DESTRIPTION PART# QTY. P0014760A4 Lid Assembly P00601551A Temperature Gauge P00614031A Temperature Gauge Seat Lid Handle Bracket, Left P00307052E Lid Handle Bracket, Right P00308052E Lid Handle P00215039H Protective Pad P05518002I Lid Assembly Bracket, Left P033200074 Lid Assembly Bracket, Right P033200084 Lid Hinge with Nut P05501136L...
- Page 10 Parts List for Model BTH3216BLP/NG DESTRIPTION PART# QTY. Bowl Front Trim Plate Ass embly P029158934 P029159034 Control Panel Switch for Light P05360001B Control Knob Seat P03415014A Control Knob for Main Burner P03435025U Electric Ignitor, 2-Port P02502252C Grease Tray Heat Shield P069040684 Grease Tray Handle P0272018C4...
- Page 11 Installation Instructions for Models BTH2616BLP/NG & BTH3216BLP/NG NOTE: The grill head you purchased is to be installed on the island which is not included in this purchase. You either need to purchase a prebuilt island or you have to build your own island. Before building your grill island, please read the construction guidelines and clearances in Fig.6 on page 12 carefully.
- Page 12 Connect Transformer to Power Source and turn on Grill Lights(For BTH3216BLP/NG model only) Make a hole on the rear panel of the Island for transformer cord. Pull the transformer cord out from the hole, make sure the cord does not touch the ground. Connect the transformer power supply cord plug to a properly grounded 120VAC outlet.
- Page 13 Install Regulator, Tank Tray Set and Liquid Propane(LP) Gas Tank Note: The connector, for safety consideration, we suggest to use a stainless steel flexible connector. But, if using semi-rigid tubing, do not use materials made of aluminum or aluminum alloy tubing. The connector should be installed visible when opening the door.
- Page 14 Install Ignitor Battery Install Cooking Components Place the flame tamer with ceramic onto Remove Ignitor Cap from Control Panel. the lower ledge of the grill bowl above the Place supplied AA battery into the Ignitor burners. Slot with positive pole facing you. Place the cooking grids onto the upper Install the Cap and Spring over the AA ledge of the grill bowl above the flame...
-
Page 15: Use & Care Instructions
USE AND CARE INSTRUCTIONS Keep fire extinguisher readily accessible. In the event CORRECT LP GAS TANK USE of a oil/grease fire, do not attempt to extinguish with LP Gas grill models are designed for use with a standard water. Use type B extinguisher or smother with dirt, 20 lb. - Page 16 USE AND CARE INSTRUCTIONS LP Gas Model only: NOTE about LP Gas Tank Exchange Programs Secure a 20lb LP Gas Tank to Gas Grill Many retailers who sell grills offer you the option of replacing your empty LP Gas tank through an exchange Note: You can only use a 20lb LP Gas Tank service.
- Page 17 USE AND CARE INSTRUCTIONS LP Gas Model only: Connect Regulator with Hose to your LP Gas Tank Check all connections for LP Gas Leaks Turn all Burner Valves to the OFF position. Never test for leaks with an open flame. Prior to first Inspect the valve connection port and regulator use, at the beginning of each season, or every time assembly for damage or debris.
- Page 18 USE AND CARE INSTRUCTIONS Fig.1 Natural Gas Model only: Connecting Natural Gas To Your Grill Connect the Swivel nut of the 12' Natural Gas Hose to the vertical fitting of NG Regulator as shown in Fig.1. Connect the other hose end Vertical Fitting (male plug) to the gas supply line from your Swivel Nut...
- Page 19 USE AND CARE INSTRUCTIONS Grill Lighting Instructions Before each use, check all hoses for cracks, nicks, cuts, burns or abrasions. If a hose is damaged in any way, do not use your grill before replacing the hose with an authorized part from the Parts List. Also make sure all gas supply connections are securely tightened.
-
Page 20: Troubleshooting
USE AND CARE INSTRUCTIONS Troubleshooting To purge air from your gas line and/or reset If the grill fails to light : the regulator excess gas flow device: Turn gas off at source and turn Control Knobs to OFF. Wait at least 5 minutes for gas to clear, then retry. Turn Control Knobs to the OFF position. - Page 21 USE AND CARE INSTRUCTIONS CORRECT USE OF TRANSFORMER AND LIGHT CORRECT USE OF ELECTRICAL EQUIPMENT Read all instructions before initial use. To protect against electric shock, do not immerse cord or plugs in water or other liquid. IMPORTANT: W hen using transformer appliances, basic safety precautions should always be used.
-
Page 22: Cleaning And Maintenance
CLEANING AND MAINTENANCE Cleaning Exterior Stainless Steel Surfaces: Routine care and maintenance is required to preserve Proper care and maintenance will keep your grill in top operating the appearance and corrosion resistance of stainless condition and prolong its life. Follow these cleaning procedures steel. - Page 23 2. 2. CLEANING THE BURNER TUBES AND BURNER PORTS Regardless of which Burner cleaning procedure you To reduce the chance of FLASHBACK FIRE you must clean use, we recommend that you also complete the follow- the Burner Tubes as follows at least once a month in ing cleaning regimens to help prolong Burner life.
- Page 24 Cooking Instructions Burn-Off Indirect Cooking using Main Burners Before cooking on your gas grill for the first time, you should "burn off" the grill to eliminate any odor or foreign The indirect cooking method can also be used with the matter.
- Page 25 Guide to Grilling using the Main Burners and Direct Cooking Method Approximate Cooking Times Grilling Steak and Ribs Cut of Meat Rare: 4-8 minutes Turn the grill Burners on IGN/HIGH, close Lid and preheat T-bone steak Medium: 10-14 minutes your grill 10 to 15 minutes. Open Lid and place the meat on Sirloin steak Well done: 15-20 minutes the Cooking Grid directly above the lit Burners.
- Page 26 Guide to Roasting and Baking Using the Main Burners Food preparation An Important Note About Heat Settings Trim meat of excess fat. Truss meat and poultry with cooking The suggested heat settings shown are approximate. There string to retain shape if desired. Bacon strips can be used to are many factors such as outside temperature, wind condi- cover the outside surface of lean meat and poultry to help tions and grill location that affect your grill performance.
- Page 27 Guide to Smoking Guide to Using the Warming Rack Preparing to Smoke Vegetables are generally easy to cook on the grill. The W arming Rack makes it convenient because you can still Smoking gives food a distinctive, delicious flavor. You will find use the main cooking area while the vegetables are sus- a variety of wood chips available for use in smoking grilled pended above the grids.
-
Page 28: Warranty
Question: Question: Can I convert my grill from one fuel type to another in Sometimes I hear a humming sound coming from my regulator. What causes this? And - My grill has a low other words from LPG to NG? flame and sometimes will not light. - Page 29 Question: The Regulator and Hose supplied with my gas grill After every use (after your grill has cooled down), wipe does not fit the older LP Gas tank I’ve used for years. stainless surfaces with a soft, soapy cloth or sponge Why not? then rinse with water.
- Page 30 Grand Hall Limited Warranty Grand Hall will warrant to the ORIGINAL PURCHASER of this product that it will be free of defects in material and workmanship for set periods below from the date of purchase when used under normal outdoor use and correct assembly: Cooking Grids and SS Burners - Limited...
