HIKVISION UD05531B Quick Start Manual

Network turret camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Network Turret Camera
Quick Start Guide
UD05531B
C
0

Advertisement

Table of Contents
loading

Related Manuals for HIKVISION UD05531B

Summary of Contents for HIKVISION UD05531B

  • Page 1 Network Turret Camera Quick Start Guide UD05531B...
  • Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
  • Page 4 Network Turret Camera·Quick Start Guide IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 5 Network Turret Camera·Quick Start Guide This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 6 Network Turret Camera·Quick Start Guide Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements. Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 7 Network Turret Camera·Quick Start Guide ● Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with 24 VAC or 12 VDC according to the IEC60950-1 standard. Please refer to technical specifications for detailed information. ●...
  • Page 8 Network Turret Camera·Quick Start Guide ● The sensor may be burned out by a laser beam, so when any laser equipment is in using, make sure that the surface of sensor will not be exposed to the laser beam. ● Do not place the camera in extremely hot, cold (the operating temperature shall be-30°C to +60°C, or -40°C to to 60°C if the camera model has an “H”...

  • Page 9: Table Of Contents

    Network Turret Camera·Quick Start Guide Table of Contents 1 Appearance Description ..............9 2 Installation ..................11 2.1 Memory Card Installation ..........11 2.2 Camera Mounting ............13 2.2.1 Ceiling Mounting ..........13 2.2.1 Wall Mounting ............ 17 3 Setting the Network Camera over the LAN ........19 Wiring ................

  • Page 10: Appearance Description

    Network Turret Camera·Quick Start Guide 1 Appearance Description The overview of the camera is shown below. 8 9 10 11 Figure 1-1 Overview of the Camera Table 1-1 Description Description Bottom Cover Sealing Plug Side Outlet Cover...
  • Page 11 Network Turret Camera·Quick Start Guide Description Decoration Ring Cover Reset Button Memory Card Slot Power Interface RJ 45 Network Interface Audio Input Interface Audio Output Interface Alarm Output Interface Alarm Input Interface Note: Hold RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.

  • Page 12: Installation

    Network Turret Camera·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12V DC or PoE (802.3af). Make sure your power supply matches with your camera.
  • Page 13 Network Turret Camera·Quick Start Guide Decoration Ring Figure 2-1 Remove the Decoration Ring 2. Loosen the adjusting screw. Adjusting Screw Figure 2-2 Loosen the Adjusting Screw 3. Rotate the camera to the position as shown in the figure. Memory Card Slot Figure 2-3 Rotate the Camera...

  • Page 14: Camera Mounting

    Network Turret Camera·Quick Start Guide 4. Loosen the screws to remove the cover of the memory card slot. 5. Insert the memory card into the slot. Memory Card Figure 2-4 Insert the Memory Card 6. Replace the slot cover with the screws. 2.2 Camera Mounting 2.2.1 Ceiling Mounting Steps:...
  • Page 15 Network Turret Camera·Quick Start Guide 83.5 Unit: mm Figure 2-5 Drill Holes in the Ceiling 2. Secure the adapter to the ceiling with the supplied screws (PA4X25). Figure 2-6 Secure the Adapter to the Ceiling 3. Hook the camera to the adapter with the safety rope. And loosen the screws and rotate to open the bottom cover.
  • Page 16 Network Turret Camera·Quick Start Guide Safety Rope Bottom Cover Figure 2-7 Hook the Camera to the Adapter 4. Take out the sealing plugs on the bottom cover as required and route the cables. Sealing Plug Figure 2-8 Route the Cables Note: When routing the cables, take out the sealing plug of the corresponding interface as required.
  • Page 17 Network Turret Camera·Quick Start Guide 5. Replace the bottom cover to the camera with screws. And rotate clockwise to secure the camera to the adapter with the screw. Screw Figure 2-9 Secure the Camera 6. Adjust the view angle. Follow the steps below to adjust the view angle. Steps: Rotate to remove the decoration ring and loosen the adjusting screw.

  • Page 18: Wall Mounting

    Network Turret Camera·Quick Start Guide Panning 0° to 355° Rotation 0° to 360° Tilting 0° to 75° Figure 2-11 Adjust the View Angle Tighten the adjusting screw and replace the decoration ring. 7. Adjust zoom and focus. The camera is equipped with a motorized vari-focal lens. You can adjust the zoom and focus level on PTZ control panel by visiting the camera via web browser or client software.
  • Page 19 Network Turret Camera·Quick Start Guide Wall mounting bracket is not included in the package. You need to purchase a bracket separately. Steps: 1. Secure the wall mount bracket on the wall with the screws (M6). Figure 2-13 Secure the Bracket 2.

  • Page 20: Setting The Network Camera Over The Lan

    Network Turret Camera·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 21: Activating The Camera

    Network Turret Camera·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation.

  • Page 22: Activation Via Sadp Software

    Network Turret Camera·Quick Start Guide Figure 3-3 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 23 Network Turret Camera·Quick Start Guide Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera. Steps: 1. Run the SADP software to search the online devices. 2.

  • Page 24: Modifying The Ip Address

    Network Turret Camera·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 25 Network Turret Camera·Quick Start Guide Steps: 1. Run the SADP software. 2. Select an active device. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Figure 3-5 Modify the IP Address...
  • Page 26 Network Turret Camera·Quick Start Guide Note: You can enable the Hik-Connect service for the device during activation. Refer to Chapter 5.1 for detailed information. 4. Input the admin password and click Modify to activate your IP address modification. The batch IP address modification is supported by the SADP. Refer to the user manual of SADP for details.

  • Page 27: Accessing Via Web Browser

    Network Turret Camera·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 28 Network Turret Camera·Quick Start Guide 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.

  • Page 29: Operating Via Hik-Connect App

    Network Turret Camera·Quick Start Guide 5 Operating via Hik-Connect App Purpose: Hik-Connect is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so Note: Hik-Connect service is not supported by certain camera models. Enable Hik-Connect Service on Camera Purpose: Hik-Connect service should be enabled on your camera before using...

  • Page 30: Enable Hik-Connect Service Via Web Browser

    Network Turret Camera·Quick Start Guide Figure 5-1 Verification Code Setting (SADP) Note: The verification code is required when you add the camera to Hik-Connect app. 3. Click and read "Terms of Service" and "Privacy Policy". 4. Confirm the settings. 5.1.2 Enable Hik-Connect Service via Web Browser Before you start: You need to activate the camera before enabling the service.
  • Page 31 Network Turret Camera·Quick Start Guide Steps: 1. Access the camera via web browser. Refer to Chapter 4. 2. Enter platform access configuration interface: Configuration > Network > Advanced Settings > Platform Access Figure 5-2 Platform Access Configuration (Web) 3. Select Platform Access Mode as Hik-Connect. 4.

  • Page 32: Hik-Connect Setup

    Network Turret Camera·Quick Start Guide Hik-Connect Setup Steps: 1. Download and install the Hik-Connect app by searching “Hik-Connect” in App Store or Google Play 2. Launch the app and register for a Hik-Connect user account. 3. Log in Hik-Connect app after registration. Adding Camera to Hik-Connect Before you start: You need to enable the Hik-Connect service on camera before...
  • Page 33 Network Turret Camera·Quick Start Guide You can find the QR code on the camera or on the cover of the Quick Start Guide of the camera in the package. Figure 5-4 Scan QR Code Note: If the QR code is missing or too blur to be recognized, you can also add the camera by tapping the icon and inputting the camera's serial number.

  • Page 34: Initializing The Memory Card

    Network Turret Camera·Quick Start Guide Initializing the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection.
