- Page 1 ASSEMBLY INSTRUCTIONS Description : 52 IN ASPEN BENCH Item No. : BE-1552 ITEM NO.: BE-1552 Printed in Vietnam ISSUED NOV 28, 2017 - 1 -...
- Page 2 Description Sketch Description Sketch Bolt Lock Washer (8.5 x 13mm) (M8 x 60mm) Flat Washer Allen Key (2 x 8.5 x 19mm) (M4 x 30mm x 110mm) ITEM NO.: BE-1552 Printed in Vietnam ISSUED NOV 28, 2017 - 2 -...
- Page 3 STEP 1 Attach legs (B) to bench top (A) with bolts (1), and washers (2) and (3) as shown below. Tighten with Allen key (4). ITEM NO.: BE-1552 Printed in Vietnam ISSUED NOV 28, 2017 - 3 -...
