Davey Peristaltic Pump
Operating Instructions
WARNING: Failure to follow these instructions and comply with all applicable
codes may cause serious bodily injury and/or property damage.
The installation of this product should be carried out by a person knowledgable
in swimming pool plumbing requirements following the installation instructions
provided in this manual.
Please pass these instructions on to the operator of this equipment.
AS Series
Model: M5138
Installation and
Advertisement
Table of Contents
Related Manuals for Davey M5138
Summary of Contents for Davey M5138
- Page 1 Davey Peristaltic Pump AS Series Model: M5138 Installation and Operating Instructions WARNING: Failure to follow these instructions and comply with all applicable codes may cause serious bodily injury and/or property damage. The installation of this product should be carried out by a person knowledgable in swimming pool plumbing requirements following the installation instructions provided in this manual.
-
Page 2: Table Of Contents
6.4 Controller Winterising ..................15 6.5 Probe Winterising ..................15 7. Trouble Shooting ....................16 Davey Repair or Replacement Guarantee ............17 In accordance with AS/NZS 60335.2.41 we are obligated to inform you that this pump is not to be used by children or... -
Page 3: Warnings And Tips
1.2 Risks • After unpacking the pump, make sure that it is completely sound. In case of doubt, do not use the pump and contact Davey •The packing materials (plastic bags, polystyrene, etc.) should be kept out of the reach of children: As they may constitute a potential source of danger •... -
Page 4: Toxic And/Or Dangerous Liquid Dosage
Failure to respect this condition could render the pump unsafe to use • When the Davey AS Series pump is not in use for a substantial period of time, or use is to be discontinued, disconnect the unit from any power... -
Page 5: Pump Description
Acid. These containers can be purchased at pool stores. 2. Pump Description The Davey Peristaltic pump is characterised by its ability to measure pH value (between 0 and 14) with its probe placed on the filtration system that analyses the pool water. -
Page 6: Buttons Description
2.2 Buttons Description pH - Fig. 2 1. Press SET to see and adjust the set point. 2. Press CAL allows calibration of the pH level associated to the SET button to change the value of the set point 3. Value/level of pH in water 4. -
Page 7: Installation And Recommendation
• Carefully observe any standards in force in your state, territory or country, as to electrical installation regulations and requirements • The Davey AS Series pump will be in operation only when your filtration pump is running WARNING •... -
Page 8: Accessories Mounting
3.2 Mounting the Pump 3.2.1 Bracket • Use mounting accessories « H » to fix the bracket of the pump • Remove the bracket on the pump by sliding it down • Locate the bracket in the space chosen and mark the holes •... -
Page 9: Mounting Of The Clamp
3.2.2 Mounting of the Probe clamp This assembly is fixed on the pipe Pierce the top wall of the pipe work. work through the clamp: - Ø 8mm for the injection valve - Ø 14 mm for the electrode/pH probe. A nut Next Oring... -
Page 10: Mounting Of The Probe On The Probe Holder
3.2.4 Mounting of the pH Probe into the Probe Holder After removing the protective cap from the probe, you need to insert all the parts as shown in the Fig.9. Once the probe has been constructed as indicated in Fig.9, tighten the probe nut without crimping the probe body. -
Page 11: Connecting The Power And Pool Pump To Your Ph Controller
4. Connecting the power and pool pump to your pH Controller Connection diagram for the ESC pH Pump System The ESC pH pump system should ideally be plumbed and connected up as shown in the diagram below. Never connect your pH pump direct to mains power. Always connect it to the chlorinator power supply so it operates during the preset filtration time cycles. -
Page 12: Commissioning And Operation
5. Commissioning and Operation 5.1 Calibration Procedure This operation is used to set the sensor response reading of the pH and peristaltic pump. Before carrying out the calibration of the probe, remember to: Disk brake • Stop the filtration pump Washer seat •... -
Page 13: Settings
3) Next immerse the probe in the pH - pH 7 solution, stir around in bottle and leave it in the solution being 4) After a period of at least one minute, careful not to the stabilized value is displayed. Press the touch the probe CAL button until the display shows CAL or the cable. -
Page 14: Operating Principle
5.3 Operating Principle The Davey Peristaltic pump adjusts its dosage in proportion to the demand. It will dose less if the displayed measure is near the set point. In normal operation, the AS Series pump will increase its ‘non operational’... -
Page 15: Maintenance Of The Peristaltic Tube
6.2 Maintenance of the Peristaltic Tube and Roller Holder The Peristaltic Pump uses a roller holder and a “squeeze” tube to pump the acid into the pool. This tube is perishable and must be replaced periodically. We recommend replacement approximately once per year. The tube should be visually inspected regularly for leaks or damage. -
Page 16: Trouble Shooting
- Total alkalinity Alarm Alr Err - TH (hardness) - pH The dosing pump will restart as soon as the pH reading If trouble persists, please contact Davey or your nearest Davey Dealer for assistance. -
Page 17: Davey Repair Or Replacement Guarantee
Davey Dealer from which you purchased the Davey product. Alternatively you can send a written letter to Davey at the addresses listed below. On receipt of your claim, Davey will seek to resolve your difficulties or, if the product is faulty or defective, advise you on how to have your Davey product repaired, obtain a replacement or a refund. - Page 18 NOTES :...
- Page 20 Website: davey.com.au Website: daveyeurope.eu Website: daveyuae.com ® Davey is a trademark of Davey Water Products Pty Ltd. © Davey Water Products Pty Ltd 2017. P/N 402616-4 * Installation and operating instructions are included with the product when purchased new. They may also be found on our website.
