Status Lights
Certifications
1.3 Casing Details
The front casing contains 3 types of status lights: Power, PLC Link, and Ethernet Link
Port 1 ~ 4..
Power Light
PLC Link Light
4 Ethernet Link
Status Lights
Power
On: This HomePlug Ethernet Bridge is receiving electrical power
Off: Power off
PLC Link
The PLC (power line) Link light will indicate the overall speed of your network with 3
colors:
Red: Minimum connection indicates weak signal and slower network speed: less than
50Mbps
Orange: Normal signal with standard network speed: 50-100Mbps
Green: Excellent signal with optimal network speed: 100Mbps+
Off: No activity. This HomePlug Ethernet Bridge is not connected
Power: On/Off
PLC(power line) Link: Red/Orange/Green/Off
Ethernet Link (Port 1 to 4): Solid/Blinking/Off
HomePlug AV power line Certification
IEEE1901, FCC Class B / CE Mark
3
