Page 1: User Manual
POH-0850TX 19” 8-port MidSpan POE HUB USER MANUAL... -
Page 2: Table Of Contents
Contents 1. Introduction ................1 Features........................1 Package Contents.....................2 2. Hardware Description ............3 Physical Dimension....................3 Front Panel .......................3 LED Indicators......................3 Rear Panel ........................4 Power On ........................4 Network Application ....................5 3. Software Utility Installation ..........6 4. GUI Management ..............9 Connecting to PoE ....................9 System Setup &... -
Page 3: Introduction
Optionally, the standard permits Powered Devices to signal to the PSEs exactly how much power they need. Features POH-0850TX, 8-port power over Ethernet Hub IEEE802.3af compliance, Power over Ethernet Mid-Spain mode Remote power feeding up to 100 meters and for IEEE802.3 10Base-T, IEEE 802.3u 100Base-TX standard... -
Page 4: Package Contents
POH-0850TX RS-232 Cable Power Cord User Guide Software Utility CD-ROM Figure 1-2. Package Contents Compare the contents of your POH-0850TX package with the standard checklist above. IF any item is missing or damaged, please contact your local dealer for service. -
Page 5: Hardware Description
2. Hardware Description This Section mainly describes the hardware of the POH-0850TX, and gives a physical and functional overview. Physical Dimension The 8-port Power over Ethernet Hub physical dimension is: 440mm x 224mm x 44mm (Lx W x H) Front Panel The Front Panel of the POH-0850TX consists of 8x RJ-45 Ethernet ports, LED indicators, and one console port. -
Page 6: Rear Panel
8 port Power over Ethernet Hub. The device will work with AC in the range 100-240V AC, 50-60Hz. Figure 2-3 Rear panel of the POH-0850TX Power On Connect the power cord to the power socket on the rear panel of the Switch. The other... -
Page 7: Network Application
side of power cord connects to the power outlet. The internal power supply of the Switch works with voltage range of AC in the 100-240VAC, frequency 50~60Hz. Check the power indicator on the front panel to see if power is properly supplied. Network Application The Power over Ethernet Hub can provides power to the PD that follow the IEEE 802.3af standard in the network. -
Page 8: Software Utility Installation
3. Software Utility Installation Berfore you star to remote configuring PD, please intsall the software utility. Through the software utility, you can easily to controll the PD that connect with PoE and view the PD parameter informations. The software utility provides GUI interface and user can easily to start with it. - Page 9 Figure 3-2 6. When installation finishes, click “OK” button to finish. See Figure 3-3. Figure 3-3 7. To run the software utility, go to “Star” “Program” “Power Over Ethernet”.
- Page 10 8. If you want to remove the software utility, go to “Star” “Control Panel” “Remove/ Add application” “Power Over Ethernet”.
-
Page 11: Gui Management
4. GUI Management Connecting to PoE Connecting the PoE with PC through the console port. Then, connect the PD (Powered Device) to the port of PoE. Run the software utility and select the COM port form Serial Link Setup function. You will see the main utility interface as figure 4-1. Figure 4-1. -
Page 12: System Setup & Control
device current configuration to the utility system and enable auto refresh function. Port Specific Control: each port specific function control and relate parameters display. Parametric Information: port parameters information display. System Setup & Control Master Enable: Enable/Disable the control of GUI. You must enable this item to do the port controlling. -
Page 13: System Information
System Information Chip Version: display the system chipset version and revision information. Firmware Version: display the system firmware version. Utility Version: display the system utility version Total Port Power (W): total of all the port power that the system provided to PD. Figure 4-3. - Page 14 Figure 4-4 Device Setting interface...
-
Page 15: Port Specific Control
Port Specific Control Port Enable: enabling the port. This function is co-responding with “Master Enable” function. Bypass Detection: bypass the detection function. Normally the system will try to detect the 25kΩ resistor in an 802.3af compliant PD device. If the PD doesn’t follow by IEEE 802.3af standard, you can enable this option to skip the detection on PD. - Page 16 The LED indicator will change depends on the PD status. Green: It represents PD is connecting with the POE hub system and working normally. Yellow: It represents there is no PD connecting with the port. RED: It represents PD’s power request is over the system support limit or the cable is short.
-
Page 17: Parametric Information
Parametric Information Discovery R (ohms): display resistance value. Port Current (mA): display current value. Port Voltage (V): display voltage value. Port Power (W): display watt value. Class Current (mA): display class current value. When you enable the “Bypass classification” function, the class current value will not show in here. Please refer to the following table for output value. -
Page 18: Technical Specification
5. Technical Specification Standard IEEE802.3af Power over Ethernet Data in: 8 x RJ-45, Data pin 1,2,3,6 Connector Data and power out: 8 x RJ-45. Data pin 1,2,3,6 Power pin (V+): 4,5, Power pin (V-): 7,8 Per port DC 48V@350mA (Maximum), Per Power out put system 125Watts (maximum) Microsoft windows based application for power... - Page 19 It will show current PD parameters which include Discover-resistor detected value, Parametric information current, voltage, power consumption, classification current and determined class System: power Per port: power Forwarding, power off AC 100~240V, 50/60 Hz, 130 Watts, IEC Power power socket with fuse and power switch 130 Watts (maximum) Power consumption Cooling...
-
Page 20: Appendix
6. Appendix Console Port Pin Assignments The female DB-9 serial port on the POE hub front panel is used to connect to the switch for out-of-band console configuration. The web interface configuration program can be accessed from PC running the system utility program. The pin assignments used to connect to the serial port are provided in the following tables. - Page 21 Console Port to 9-Pin DTE Port on PC Switch’s 9-Pin Serial CCITT Signal PC’s 9-Pin DTE Port Port 2 RXD <---------RXD ------------ 3 TxD 3 TXD -----------TXD ----------> 2 RxD 5 SGND -----------SGND ---------- 5 SGND No other pins are used.
