- Page 1 WASHING MACHINE USER‘S MANUAL GWN37430W www.grundig.com Document Number 2820526019/ 12-06-17.(18:36)
- Page 2 Please read this user manual first! Dear Customer, Thank you for preferring a Grundig product. We hope that you get the best results from your product which has been manufactured with high quality and state-of- the-art technology. Therefore, please read this entire user manual and all other accompanying documents carefully before using the product and keep it as a reference for future use.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Important instructions for safety Functions/Programmes Selected by and environment Pressing the Function Buttons for 3 Seconds ..... .28 General safety . -
Page 4: Important Instructions For Safety And Environment
Important instructions for safety and environment This section contains safety instructions that will help protect from risk of personal injury or property damage. Failure to follow these instructions shall void any warranty. General safety • This product can be used by children at and above 8 years old and by persons whose physi- cal, sensory or mental capabilities are not fully developed or who lack experience and knowl-... -
Page 5: Product Safety
• Connect the product to a grounded outlet pro- tected by a 16 A fuse. Have the grounding instal- lation made by a qualified electrician. Our com- pany shall not be liable for any damages that will arise when the product is used without ground- ing in accordance with the local regulations. -
Page 6: Intended Use
• Do not force open the locked loading door. The loading door will be ready to open just a few min- utes after the washing cycle comes to an end. In case of forcing the loading door to open, the door and the lock mechanism may get damaged. -
Page 7: Children's Safety
Children's safety • Packaging materials are dangerous to children. Keep packaging materials in a safe place away from reach of the children. • Electrical products are dangerous to children. Keep children away from the product when it is in use. Do not let them to tamper with the prod- uct. -
Page 8: Compliance With The Weee Directive
Compliance with the WEEE Directive This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This product has been manufactured with high quality parts and materials which can be reused and are suitable for recycling. Do not dispose of the waste product with normal do- mestic and other wastes at the end of its service life. -
Page 9: Your Washing Machine
Your washing machine Overview 1- Power cable 2- Top panel 3- Control panel 4- Filter cap 5- Adjustable feet 6- Loading door 7- Detergent drawer 8- Drain hose... -
Page 10: Package Contents
Package Contents 1- Power cable 2- Drain hose 3- Transportation safety bolts * 4- Mains water inlet hose (One of the following filter types is used for the mains hose connection.) a- Electronic water shut-off b- Mechanical water shut-off c- Standard 5- Liquid detergent container** 6- User Manual 7- Blind plug***... -
Page 11: Technical Specifications
Technical specifications Complying Commission Delegated Regulation (EU) No 1061/2010 Supplier name or trademark GRUNDIG Model name GWN37430W Rated capacity (kg) Energy efficiency class / Scale from A+++ (Highest Efficiency) to D (Lowest Efficiency) A+++ Annual Energy Consumption (kWh) Energy consumption of the standard 60°C cotton programme at full load (kWh) 0.787... -
Page 12: Installation
Installation • Do not place heat sources such as Hobs, Irons, Ovens, etc. on the To make the product ready for use, washing machine and do not use review the information in the user them on the product. manual and make sure that the Removing packaging reinforcement electricity, tap water supply and water Tilt the machine backwards to remove... -
Page 13: Connecting Water Supply
• Remove transportation safety • Tighten all hose nuts by hand. bolts by turning them gently. Never use a tool when tightening the nuts. • Open the taps completely after • Attach the plastic covers supplied making the hose connection in the User Manual bag into the to check for water leaks at the holes on the rear panel. -
Page 14: Adjusting The Feet
Adjusting the feet • In case the hose is elevated after laying it on the floor level WARNING: In order to ensure or close to the ground (less than that the product operates more 40 cm above the ground), water silently and vibration-free, it must discharge becomes more difficult stand level and balanced on its... -
Page 15: Electrical Connection
Electrical connection Electrical requirements Before you insert the plug into the wall Connect the product to a grounded socket make sure that the voltage and outlet protected by a 16 A fuse. Our the frequency shown in the rating label company shall not be liable for any corresponds to your electricity supply. - Page 16 Important Transportation of the product • Unplug the product before Fitting a different plug transporting it. As the colours of the wires in the • Remove water drain and water mains lead of this appliance may supply connections. not correspond with the coloured •...
-
Page 17: Preparation
Preparation Sorting the laundry • Sort laundry according to type of fabric, colour, and degree of soiling and allowable water temperature. • Always obey the instructions given on the garment tags. LAUNDRY WASH SYMBOLS Machine Wash Symbols WASH Maximum Water Temperatures Symbol(s) Drying... -
Page 18: Preparing Laundry For Washing
Preparing laundry for washing Things to be done for energy saving • Laundry items with metal Following information will help you attachments such as, underwired use the product in an ecological and bras, belt buckles or metal energy-efficient manner. buttons will damage the machine. •... -
Page 19: Correct Load Capacity
Correct load capacity Using detergent and softener The maximum load capacity depends When using detergent, softener, on the type of laundry, the degree of starch, fabric dye, bleach or soiling and the washing programme limescale remover, read the desired. manufacturer's instructions on The machine automatically adjusts the package carefully and follow the suggested dosage values. - Page 20 Choosing the detergent type • If the liquid detergent has lost its fluidity, dilute it with water before The type of detergent to be used depends on the type and colour of the putting in the detergent cup. fabric. • Use different detergents for coloured and white laundry.
-
Page 21: Tips For Efficient Washing
Tips for efficient washing Using starch • Add liquid starch, powder starch Clothes or the fabric dye into the softener Light colours and whites compartment. • Do not use softener and starch (Recommended temperature range based on soiling level: 40- together in a washing cycle. - Page 22 Clothes Dark colours (Recommended temperature range based on soiling level: cold -40 °C) Liquid detergents suitable for Heavily colors and dark colors can be Soiled used at dosages recommended for heavily soiled clothes. Liquid detergents suitable for Normally colors and dark colors can be Soiled used at dosages recommended for normally soiled clothes.
-
Page 23: Operation
Operation Control panel Cotton Rinsing Down Wear Cotton Eco 1400 No Water Synthetics Sports 1200 Start / Pause DarkCare Mini Wash Curtain Spin WoolProtect Shirts Delicate HygieneCare AntiCrease+ Spin+Pump Lingerie Express Extra Temp. Spin Prewash Time Start On/Off Rinse Delay Pause 1 - Programme selection display 8 - Auxiliary function button 3... -
Page 24: Programme And Consumption Table
Programme and consumption table Auxiliary functions Selectable Programme temperature range °C 2.45 1400 • • • • Cold-90 Cotton 1400 • • • • Cold-90 0.95 1400 • • • • Cold-90 60** 44.78 0.787 1400 Cold-60 Cotton Eco 60** 0.621 1400 Cold-60... -
Page 25: Programmes
Indicative values for Synthetics programmes (EN) Remaining Moisture Remaining Moisture Content (%) ** Content (%) ** ≤ 1000 rpm > 1000 rpm Synthetics 60 1.30 115/140 Synthetics 40 0.80 115/140 * You can see the washing time of the programme you have selected on the display of the machine. It is normal that small differences may occur between the time shown on the display and the real washing time. -
Page 26: Special Programmes
• Delicate • Sports You can wash your delicate clothes You can use this programme to wash such as cotton/synthetic blended sports and outdoors garments that knitwear or hosiery in this programme. contain cotton/synthetics mix and It washes with more delicate washing water repellent covers such as gore- action. -
Page 27: Temperature Selection
Temperature selection Auxiliary function selection Whenever a new programme Select the desired auxiliary functions is selected, the recommended before starting the programme. temperature for the selected When this programme and a relevant programme appears on the auxiliary function that can be selected temperature indicator. -
Page 28: Auxiliary Functions
Auxiliary functions • Child Lock You can prevent children from • Prewash tampering with the machine by using A Prewash is only worthwhile for the Child Lock feature. Thus you heavily soiled laundry. Not using the can avoid any changes in a running Prewash will save energy, water, programme. -
Page 29: End Time
End Time Changing the duration of End Time Press End Time button. Every time With the End Time function, the startup the button is pressed, the period will of the programme may be delayed up change in 3-hour increments and the to 24 hours. -
Page 30: Changes That Can Be Made After Programme Has Started
Changes that can be made after Cancelling the programme programme has started The programme is cancelled when the machine is turned off and on again. Adding laundry after the programme has Press and hold On / Off button for 3 started: seconds. -
Page 31: Quick User Manual Preparing The Machine
Quick User Manual Cancelling the programme The programme is cancelled when the Preparing the machine machine is turned off and on again. • Check if the hoses are connected Press and hold On / Off button for 3 tightly. seconds. •... -
Page 32: Maintenance And Cleaning
Maintenance and cleaning Cleaning the loading door Service life of the product extends and frequently faced problems decrease if and the drum cleaned at regular intervals. For products with drum cleaning Cleaning the detergent drawer programme, please see Operating the product - Programmes. -
Page 33: Cleaning The Body And Control Panel
Cleaning the body and control panel Draining remaining water and cleaning the pump filter Wipe the body of the machine with soapy water or non-corrosive mild gel The filter system in your machine detergents as necessary, and dry with prevents solid items such as buttons, a soft cloth. -
Page 34: If The Product Has An Emergency Draining Hose, To Discharge The Water
If the product has an • Open the filter cap. • If the filter cap is composed of emergency draining hose, two pieces, press the tab on the to discharge the water: filter cap downwards and pull the piece out towards yourself. You can remove the filter cover by slightly pushing downwards with a •... -
Page 35: Troubleshooting
Troubleshooting Program does not start after closing the door. *Press the Start / Pause / Cancel • Start / Pause / Cancel button was not pressed. >>> button. Reduce the • It may be difficult to close the loading door in case of excessive loading. >>> amount of laundry and make sure that the loading door is closed properly. - Page 36 Loading door cannot be opened. Drain the water by • Door lock is activated because of the water level in the machine. >>> running the Pump or Spin programme. Wait until the • Machine is heating up the water or it is at the spinning cycle. >>> programme completes.
- Page 37 Washing performance is poor: Laundry turns grey. (**) Use the • Insufficient amount of detergent was used over a long period of time. >>> recommended amount of detergent appropriate for water hardness and the laundry. • Washing was made at low temperatures for a long time over a long period of time. >>> Select the proper temperature for the laundry to be washed.
- Page 38 Laundry became stiff after washing. (**) Using insufficient amount of detergent for • Insufficient amount of detergent is used. >>> the water hardness can cause the laundry to become stiff in time. Use appropriate amount of detergent according to the water hardness. If detergent is put in the prewash •...
- Page 39 Foam is overflowing from the detergent drawer. Mix 1 tablespoonful softener and ½ l water and pour into • Too much detergent is used. >>> the main wash compartment of the detergent drawer. • Put detergent into the machine suitable for the programmes and maximum loads indicated in the “Programme and consumption table”.
- Page 40 Repairs necessary as a direct or indirect result of: Accidental damage, misuse or abuse of a product. An attempted repair of a product by anyone other than a Grundig Approved Engineer (the “Engineer”). Installation or use of a product where such installation or use fails to meet the requirements contained in this guarantee or the User Instructions Booklet.
- Page 41 Optional extras, where available (i.e. extendable feet) are supplied on a chargeable basis only. Does Grundig offer replacements? This is a repair-only guarantee. On occasion, the Manufacturer may at its sole discretion, replace your product with a new product instead of carrying out a repair. Where a replacement is offered, this would normally be an identical model, but when this is not possible, a model of similar specification will be provided.
- Page 42 Will there be any charge for the repairs? It is your responsibility to provide evidence to the Engineer that your product is covered by this guarantee with a proof of purchase. The Manufacturer reserves the right to charge for the reasonable cost of any service call if: ...
- Page 43 Should you experience any difficulty in obtaining service contact the Grundig Customer Helpline on Tel: 0333 207 9920 or e-mail: customerservice@support.grundig.co.uk...
- Page 44 www.grundig.com...
