English
Idle speed: 2,700 rpm
Cut-off speed (rated): 12,300 rpm
Max. output shaft
speed (cutting
attachment): 8,870 rpm
FS 490 C
Displacement: 51.6 cc
Bore: 44.7 mm
Stroke: 32.9 mm
Engine power to 2.4 kW (3.3 bhp)
ISO 8893: at 9,500 rpm
Idle speed: 2,500 rpm
Cut-off speed (rated): 12,300 rpm
Max. output shaft
speed (cutting
attachment): 8,870 rpm
Ignition System
Electronic magneto ignition
FS 360 C, FS 410 C, FS 460 C
Spark plug (resistor NGK CMR6H
type): Bosch USR4AC
Electrode gap: 0.5 mm
FS 490 C
Spark plug (resistor NGK BPMR7A
type):
Electrode gap: 0.5 mm
Fuel System
All position diaphragm carburetor with
integral fuel pump
Fuel tank capacity:
FS 360 C: 750 cc (0.75 l)
46
FS 410 C: 750 cc (0.75 l)
FS 460 C: 750 cc (0.75 l)
FS 490 C: 990 cc (0.99 l)
Weight
Dry, without cutting attachment and
deflector
FS 360 C-EM:
FS 410 C-EM:
FS 410 C-EM L:
FS 460 C-EM:
FS 460 C-EM L:
FS 490 C-EM:
FS 490 C-EM L:
Overall length
without cutting attachment
FS 360 C-EM:
FS 410 C-EM:
FS 410 C-EM L:
FS 460 C-EM:
FS 460 C-EM L:
FS 490 C-EM:
FS 490 C-EM L:
Features
C Convenience features
E ErgoStart
M M-Tronic
L Long drive tube
Z Spark arresting screen
Noise and Vibration Data
Noise and vibration data measurements
on FS units include idling and rated
maximum speed with the same duration
of exposure.
For further details on compliance with
Vibration Directive 2002/44/EC see
www.stihl.com/vib.
8.5 kg
Sound pressure level L
8.5 kg
8.6 kg
with mowing head
8.5 kg
FS 360 C-EM:
8.6 kg
FS 410 C-EM:
9.1 kg
FS 410 C-EM L:
9.2 kg
FS 460 C-EM:
FS 460 C-EM L:
FS 490 C-EM:
FS 490 C-EM L:
with metal mowing
1790 mm
attachment
1790 mm
FS 360 C-EM:
1850 mm
FS 410 C-EM:
1790 mm
FS 410 C-EM L:
1850 mm
FS 460 C-EM:
1795 mm
FS 460 C-EM L:
1855 mm
FS 490 C-EM:
FS 490 C-EM L:
Sound power level L
with mowing head
FS 360 C-EM:
FS 410 C-EM:
FS 410 C-EM L:
FS 460 C-EM:
FS 460 C-EM L:
FS 490 C-EM:
FS 360 C-M, FS 410 C-M, FS 460 C-M, FS 490 C-M
to ISO 22868
p
99 dB(A)
101 dB(A)
101 dB(A)
101 dB(A)
101 dB(A)
102 dB(A)
102 dB(A)
98 dB(A)
99 dB(A)
99 dB(A)
100 dB(A)
100 dB(A)
102 dB(A)
102 dB(A)
to ISO 22868
w
112 dB(A)
113 dB(A)
113 dB(A)
110 dB(A)
110 dB(A)
112 dB(A)
