BT8385-130
1.3m Column
PARTS LIST
5
6
2
7
www.btechavmounts.com
4
3
1
8
ITEM
1
2
3
4
5
6
7
8
9
10
9
10
DESCRIPTION
1.3M COLUMN
COLUMN REAR COVER
METAL END CAP
M6 x 12mm HEX SCREW
M6 x 12mm GRUB SCREW
SQUARE NUT
RUBBER RING
COVER STRIP
3AF HEX KEY
4AF HEX KEY
QTY
1
1
1
2
4
4
2
4
1
1
