Installation and Operating Instructions
MODEL NO. FV42 – 0518 FULLVIEW DIRECT VENT GAS FIREPLACE
WARNING: If the information in these instructions
are not followed exactly, a fire or explosion may
result causing property damage, personal injury or
loss of life.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
f i r e - p a r t s . c o m
•
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
•
If you cannot reach your gas supplier, call
the fire department.
- Installation and service must be performed by a
qualified installer, service agency or the gas supplier.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA only)
or mobile home, where not prohibited by local
codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gassed, unless a
certified kit is used.
A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance
and shall be installed.
www.mendotahearth.com
HEATER
AVERTISSEMENT. Assurez-vous de bien suivre les instructions
données dans cette notice pour réduire au minimum le risque
d'incendie ou d'explosion ou pour éviter tout dommage
matériel, toute blessure ou la mort.
Ne pas entreposer ni utiliser d'essence ni d'autres vapeurs ou
liquids inflammables dans le voisinage de cet appareil ou de
tout autre appareil.
- QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucun interrupteur. Ne pas vous servir des
téléphones se trouvant dans le bâtiment où vous vous trouvez.
• Appelez immédiatement votre fournisseur de gaz depuis un
voisin. Suivez les instructions du fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz, appelez le
service des incendies.
- L'installation et l'entretien doivent être assurés par un
installateur ou un service d'entretien qualifié ou par le
fournisseur de gaz.
Cet appareil peut être installé dans une maison préfabriquée
(É.-U. seulement) ou mobile déjà installée à demeure si les
règlements locaux le permettent.
Cet appareil doit être utilisé uniquement avec les types de gaz
indiqués sur la plaque signalétique. Une trousse de conversion
est fournie avec cet appareil.
Une barrière conçue pour réduire le risque de brûlures du verre
chaud est fournie avec cet appareil et doit être installée.
A Division of Johnson Gas Appliance Company
Advertisement
Table of Contents
Related Manuals for Mendota FV42-0518
Summary of Contents for Mendota FV42-0518
- Page 1 Installation and Operating Instructions MODEL NO. FV42 – 0518 FULLVIEW DIRECT VENT GAS FIREPLACE WARNING: If the information in these instructions HEATER AVERTISSEMENT. Assurez-vous de bien suivre les instructions are not followed exactly, a fire or explosion may données dans cette notice pour réduire au minimum le risque result causing property damage, personal injury or d'incendie ou d'explosion ou pour éviter tout dommage loss of life.
-
Page 2: Table Of Contents
Contents GENERAL INFORMATION SAFETY AND WARNING INFORMATION ........................ 6 Building Permit and Installation Inspection Approval Requirements ............... 6 Safety Warnings ..............................7 Specific Requirements for the Common Wealth of Massachusetts ............... 10 Safety and Structural Concerns ........................11 Venting Requirements ............................ 11 Heating Performance ............................ - Page 3 Sealant Types Approved for Use ......................... 25 R-VALUE TABLES ..............................26 WILLOWBROOK/GRACE FRONT GUIDE OPTIONS ....................27 GAS SUPPLY REQUIREMENTS ..........................29 Gas Supply Line Sizing ............................. 29 Gas Pressure Requirements ..........................30 Gas Input Rate Verification Requirements ..................... 31 Natural Gas Applications Gas Input Rate Verification Procedures .............
- Page 4 To Replace Damaged Glass ......................... 63 INSTALLATION CHECKLIST ........................... 64 LIGHTING CHECKLIST............................64 HOMEOWNER OPERATION WELCOME TO MENDOTA ........................... 65 OPERATION INFORMATION ..........................66 Using Your Remote Control ..........................66 Synchronizing the Fireplace and the Remote Control ................66 Remote Control Functions .......................... 67 Remote Control Operating Instructions ......................
- Page 5 Why won’t my fireplace turn on? ....................... 76 What happens when I first light my fireplace? ................... 77 WARRANTY QUALIFICATION AND SERVICE REFERENCE ..................78 MENDOTA STANDARD WARRANTY AND LIFETIME WARRANTY on DIRECT VENT GAS FIREPLACES AND INSERTS ................................79 FV42...
-
Page 6: General Information
National Fuel Gas Code. In the absence of local codes, the installation must conform to the most current edition of the National Fuel Gas Code ANSI Z223.1, also known as NFPA 54. NOTE: The Mendota Fireplace is approved for mobile home and bedroom installations. -
Page 7: Safety Warnings
Safety Warnings HIGH-ALTITUDE INSTALLATION INFORMATION: Prior to installing at altitudes higher than 7,500’, understand the need for gas input derating. Contact Mendota Technical Service for support. INSTALLER NOTE: These instructions are to remain with homeowner. FOR YOUR SAFETY In the Commonwealth of Massachusetts:... - Page 8 Be sure to read and understand all instructions carefully before starting the fireplace. Failure to follow these instructions may result in a possible fire hazard and will void the warranty: Safety Standards and Warnings Any safety screen or guard removed for servicing must be replaced before operating this fireplace. Tout écran ou protecteur retiré...
- Page 9 été plongée dans l’eau. This fireplace is for use with only doors certified by Mendota. Do not use any fronts or doors with this fireplace unless they are certified by Mendota and installed by a certified installer.
-
Page 10: Specific Requirements For The Common Wealth Of Massachusetts
Specific Requirements for the Common Wealth of Massachusetts The information in this section applies to all installations performed in the Common Wealth of Massachusetts only. For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes and where the side wall exhaust vent termination is less than seven (7) feet above grade, the following requirements shall be satisfied: If there is no carbon monoxide detector with an alarm already installed in compliance with the most current... -
Page 11: Safety And Structural Concerns
6" or more, no hearth protector is required. Venting Requirements This Mendota fireplace can be vented using many available listed direct vent coaxial pipe (8”x5”) off the top. Approved brands of vent components include DuraVent, AmeriVent, ICC, Selkirk, Olympia, and Security vent pipes and venting components. -
Page 12: Heating Performance
Heating Performance With its high heat output, this Mendota fireplace will heat a large area of the home if located properly to maximize heat/air circulation. Air movement options for maximizing heat circulation that can be considered are the continuous operation of central heating furnace blowers or ceiling fans. The most efficient method for overall heat distribution within a single room is a ceiling fan. -
Page 13: Specifications
SPECIFICATIONS General Specifications FIREPLACE OVERALL DIMENSIONS: 49 ⅝” wide x 40 ½” high x 19 ½” deep MINIMUM FRAMING DIMENSIONS: 55” wide x 41” high x 20” deep GLASS SIZE: Neoceram glass with non-reflective coating. Visible glass measures 828 in (38 ½”... -
Page 14: Listing Label
Listing Label f i r e - p a r t s . c o m FV42 85-03-01068... -
Page 15: Technical Specifications
Technical Specifications High Fire - Adjustable to - Low Fire BTUH. NAT GAS 44,000 14,100 BTUH. LP GAS 44,000 18,600 NOTE: LPG CONVERSION KIT HA-110-00084, MUST BE PURCHASED SEPARATELY TO CONVERT TO BURN LPG IN THIS FIREPLACE. MAIN ORIFICE [0-2000ft (610 m)]: REAR BURNER: #38 NG [54” L.P.] – FRONT BURNER: #44 NG [54“ LP] [2000-4500ft (610-1370 m)]: REAR BURNER: #38 NG [54”... -
Page 16: Fireplace Dimensions
Fireplace Dimensions 51 5/8 OVERALL UNIT WIDTH 19 1/2 UNIT WIDTH AT FRONT UNIT DEPTH GAS SUPPLY INLET 1/2" FNPT 40 1/2 ELECTRICAL SUPPLY INLET 25 1/8 UNIT HEIGHT 110 VAC FINISHING GUIDE 32 5/8 HEIGHT FLOOR TO VENT STARTER TOP 11 1/2 9 3/8 f i r e - p a r t s . -
Page 17: Framing Dimensions
Framing Dimensions 55 MINIMUM ENCLOSURE FRAMING WIDTH 10 3/8 72 M INIM UM UNIT FACE TO 18 M INIM UM TO SOFFIT. UNIT BASE TO CELING VENT CENTERLINE 24" TO VINYL SOFFITS. 20 M INIM UM FRAM ING DEPTH 54 M INIM UM ENCLOSURE CELING HEIGHT FINISHED FRAMING WIDTH... -
Page 18: Wiring Diagram
Wiring Diagram f i r e - p a r t s . c o m The appliance must be electrically connected and grounded in accordance with local codes or, in the absence of local codes, with the current NFPA 70-National Electric Code or CSA C22.1-Canadian Electrical Code. -
Page 19: Installation
INSTALLATION PLANNING THE INSTALLATION Before Installing When planning on fireplace installation, determine the following: ➢ Where the fireplace is to be installed ➢ Vent system configuration to be used ➢ Gas supply piping ➢ Electrical wiring ➢ Framing and finishing details ➢... -
Page 20: Installing The Fireplace
WARNING FIRE RISK ODOR RISK • Install appliance on hard metal or wood surfaces extending full width and depth of this fireplace. • Do not install this fireplace directly on carpeting, vinyl or any combustible material other than wood. Construct chase to all clearance specifications in manual. -
Page 21: Constructing The Fireplace Chase
Constructing the Fireplace Chase A chase is a vertical box-like structure built to enclose this fireplace and its vent system. Vertical vents that run on the outside of a building may be, but are not required to be, installed inside a chase. Construction of the chase may vary with the type of building. -
Page 22: Mantel Clearances
Mantel Clearances Mantel clearances for this fireplace may be measured from the top of the convection air opening or the floor level of this fireplace. The location that is referenced normally to measure mantel clearances is the top of the convection air opening. The chart and diagram, in this page, provide all the reference dimensional information necessary in determining the distance a combustible mantel may protrude out from the face surface of this fireplace. -
Page 23: Hearth Protection Pad Requirements
• To achieve this required R-rating, Mendota strongly suggests that you employ ½” thick mineral/ceramic board as the base substrate on top of the combustible floor construction or combustible raised hearth structure before you place additional finishing materials or natural stone products to achieve an R-1.0 minimum rating. Refer to the R- Rating specification tables in this manual. -
Page 24: Framing Depth And Finishing Guides
Mendota strongly recommends not using mortar blends with polymer additives or any premix mastics or any adhering compounds with chemical base such as PL construction adhesives or silicone. Use of these products will cause a high likelihood of offgasing odors. -
Page 25: Hearth Pad Requirements
Note: Mendota will not be responsible for and will not warranty a smooth wall or natural stone wall finish because of the vulnerability and uncertainty of these finish products under heat stress. -
Page 26: R-Value Tables
R-VALUE TABLES Backer Materials R-Ratings Table R-Values of Common Backer Materials Material Thickness Value Application Recommendation Mineral Fiber Board ( Micore 160) 1/2" 1.27 Recommended Mineral Fiber Board (Micore 300) 1/2" 1.03 Recommended Ceramic Board (Rescor 360) 1/2" 1.11 Recommended Ceramic Board (Fiberfrax Duraboard LD) 1/2"... -
Page 27: Willowbrook/Grace Front Guide Options
There are three options for finishing the fireplace when installing a Grace or Willowbrook front. Please read the following instruction before installing the finishing material on the front of the fireplace. If you have any questions about finishing the fireplace contact a Mendota dealer or the Mendota Service Department. - Page 28 OPTION 2: INSTALLING THE FRONT ON TOP OF FINISHING MATERIALS WITH THE SCREEN RECESSESED Note: Order “template kit” or Option 2 in the pricing. Option 2 requires that your finish material be less than 2.5” thick including backing materials and reasonably flat.
-
Page 29: Gas Supply Requirements
Correct gas pressure and proper gas supply line sizing is imperative to the successful performance of this Mendota gas fireplace. Be sure the gas supplier or plumber carefully checks for correct gas pressure and gas line sizing when installing the fireplace. -
Page 30: Gas Pressure Requirements
Gas Pressure Requirements Inlet and manifold gas pressure checking taps are located on gas valve. Perform inlet and outlet pressure tests before completing the facing installation. Remove valve access cover box on left side of fireplace to access the gas valve and all control components. A qualified installer must take pressure measurements at these ports to verify and set the correct inlet gas pressures during initial installation. -
Page 31: Gas Input Rate Verification Requirements
Gas Input Rate Verification Requirements Natural Gas Applications Gas Input Rate Verification Procedures Verify main orifice size. The main orifice body has the orifice size stamped on it. Natural gas orifice size will be #38 (rear burner) and #44 (front burner) for all elevations. Verify that the manifold gas pressure is within 3.5"... -
Page 32: Converting Fireplace For Lp Gas
CONVERTING FIREPLACE FOR LP GAS WARNING This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion or production of carbon monoxide may result causing property damage, personal injury or loss of life. - Page 33 5. You will now be able to access the burner orifices, which are located inside the air shutter boxes. Using a ½” deep well socket wrench, remove front and rear orifices. When removing and installing the orifices be sure to use a wrench to keep the fitting the orifice screws onto from rotating.
- Page 34 10. Install the airbox and both rear and front burners in their original locations and positions and secure down using screws you removed earlier. 11. Make certain front burner is running parallel to front face of unit positioned properly so that the pilot hood pointing to the left is pointed properly toward the burner’s flame propagation ports.
- Page 35 21. Make stepper motor and valve electrical connections. Apply gas to the system. Relight the fireplace according to Mendota instructions. f i r e - p a r t s . c o m 22. With the main burner on, test the new pressure regulator assembly for leaks using a soap solution.
-
Page 36: Pilot Flame And Main Burner Relationship Verification
Pilot Flame and Main Burner Relationship Verification Prior to completing the conversion process, the qualified service technician must, light the pilot and verify the relationship between the pilot flames and the main burners. The pilot flames directed toward the propagation ports on the rear and front burner must overlap the propagation ports on the burners. The pilot flames must be a minimum of 1.0”... -
Page 37: Lp Gas Pressure Requirements
LP Gas Pressure Requirements Inlet and manifold gas pressure checking taps are located on gas valve. These ports are only accessible from the outer left side of the fireplace. A qualified installer will take pressure measurements at these ports to verify and set the correct gas pressures during the LP Kit installation and before fascia materials are installed over the front of this fireplace. -
Page 38: Attaching Lp Gas Conversion Label
Attaching LP Gas Conversion Label A printed informational label is included with the LP Gas Conversion Kit (as shown). Attach this label to the back surface of the wire diagram plate that is located in the convection air cavity below the firebox: f i r e - p a r t s . -
Page 39: Electrical Supply Requirement
Do not cut or remove the grounding wire. Electronic ignition system, dual blowers, and an accent light system are included in this Mendota direct vent fireplace. These devices require constant electrical power except during power outages. A 120-volt electrical service must be supplied at the fireplace location at the time of installation on the left side of this fireplace. -
Page 40: Backup Dc Power Inlet Port Installation
Backup DC Power Inlet Port Installation Under normal conditions when AC power is available, this fireplace is designed to operate on 120VAC power. During power outages, it is designed to operate using 6 V DC backup power. This fireplace is supplied with a DC power inlet harness, a single gang outlet box, and two single cover plates. -
Page 41: Flue Venting Instructions
Milpak 1000°F silicate stove sealant (#65-06-00909). Aluminum foil tape may be used on the outer (air intake) pipe joint but is not mandatory. Local codes may vary. Contact the Mendota dealer for proper materials. Component "Twist-Lock" Connection Procedure DuraVent and American Metals pipe and fittings are designed with special twist-lock connections. -
Page 42: Vent Cap Heat Shield
Warning: Always use heat shield (#AA-11-00458) when exterior wall covering is made of vinyl, wood or other combustible materials. Heat shield (#AA-11-00458) or an equivalent heat shield must be installed. Heat shield (#AA-11-00458) is available for order directly from Mendota fireplaces. f i r e - p a r t s . c o m... -
Page 43: Exterior Vent Locations And Restrictions
Exterior Vent Locations and Restrictions Exterior Vent f i r e - p a r t s . c o m ALL MEASUREMENTS FROM CENTERLINE OF VENT CAP - - - Vent Terminal Air Supply Inlet Area Where Terminal Is Not Permitted Clearance above grade, veranda, porch, deck, or *Not to be installed above a meter/regulator assembly balcony (*12”... -
Page 44: Flue Venting Components Identification
Flue Venting Components Identification Note: Do not separate telescoping sections. Use telescoping sections as complete assemblies. ITEM FLUE VENTING COMPONENTS DESCRIPTION 6" or 7” PIPE (DuraVent 6”/AmeriVent 7”), 9”, 12” 12" VENT STACK 24" VENT STACK 36" VENT STACK 48" VENT STACK 9,10 90ºGALVANIZED ELBOW 45º... -
Page 45: Master Flue Venting Requirements Chart
Master Flue Venting Requirements Chart Note: This chart is applicable to both natural gas and LP installations. ➢ 9” minimum vertical pipe run required to be connected directly to this fireplace’s flue starter collar. Maximum horizontal run allowed with the minimum 9” vertical run is 12”. ➢... -
Page 46: Important Venting Configuration Notes
Important Venting Configuration Notes Note: Prior to installing at altitudes higher than 7,500’, understand the gas deration requirement and adjust burner gas orifices accordingly. If unable, please contact the Mendota technical service department for specific venting requirements and venting restrictions. -
Page 47: Using 45° Elbows
Using 45° Elbows Two 45° elbows may be used in place of one 90 ° elbow. On 45 ° runs, one foot of diagonal pipe is equal to 8 ½” horizontal run and 8 ½” vertical run. Two 45° elbows may be connected directly to the vent starter adapter on this fireplace to create an offset to provide the required clearances to combustible framing or sheathing materials. -
Page 48: Approved Vent Systems Quick Reference Chart
Approved Vent Systems Quick Reference Chart STRAIGHT UP, VERTICAL VENTING ZERO VERTICAL HORIZONTAL TERMINATION VERTICAL RISE HORIZONTAL TERMINATION NOT ALLOWED 40 FEET MAXIMUM NOT ALLOWED APPROVED APPROVED VERTICAL RISE DUAL 90° ELBOWS HORIZONTAL TERMINATION f i r e - p a r t s . c o m VERTICAL RISE DUAL 90°... -
Page 49: Minimum Rise With Horizontal Termination
Minimum Rise with Horizontal Termination A maximum horizontal run of 12” is allowed if a 9” vertical starter section and one 90° elbow is connected directly to this fireplace’s flue starter collar. The horizontal centerline of the 90ºelbow will be 46 ⅜” up from the floor level of this fireplace. -
Page 50: Vertical Rise Horizontal Termination
Vertical Rise Horizontal Termination The minimum vertical section required to be connected directly to the starter adapter on this fireplace is 4’ when used with a maximum horizontal run of 32’. If the total length of the vertical sections connected directly to the starter adapter on this fireplace is between 4’... - Page 51 Vertical Rise Two 90° Elbows VERTICAL RISE V(2’ MIN) H1 + H2 MAX DUAL 90° ELBOW S Horizontal Termination HORIZONTAL TERMINATION 2’ 9’ 11” 3’ 19’ 6” 4’ 32’ 4’ – 12’ 32’ For V greater than 12’, see Master Venting Chart f i r e - p a r t s .
-
Page 52: Vertical Through-The-Roof Venting
Vertical Through-The-Roof Venting The maximum vertical run of vent pipe is 40’ from the top of the fireplace. The fireplace will support a run of a maximum of 40’. Maintain 1" air space clearances on all sides of vents. If an offset is required directly on top of the fireplace, two 45 °... - Page 53 10. Height "H" from roof surface to the top of vent cap can be determined using the “H” Dimension table. 11. Complete the installation with the storm collar and vent cap. "H" DIMENSION ROOF PITCH FEET METERS FLAT to 6/12 7/12 to 9/12 10/12 to 12/12...
-
Page 54: Vertical Through-The-Roof Venting Using Four 90 Elbows
Mendota has spent considerable time and effort in the design of this fireplace and its venting system. Through this effort, Mendota has been able to certify the use of four 90 °... -
Page 55: Initial Installer Startup Information
Adhesives, glue, wall substrate, wall finish material, paints, and polishes are common materials that if used incorrectly will cause odor issues. Mendota is not responsible for any odor issues caused by materials used around the fireplace. -
Page 56: Adjusting Flame Appearance
ADJUSTING FLAME APPEARANCE Both the burner air shutters and the fireplace’s exhaust damper can be used to adjust and fine tune the fireplace’s flame appearance. Always let fireplace burn for at least 30 minutes minimum before making final adjustments. The flame’s appearance will change as the fireplace heats up. Air Shutter Adjustments Be sure burner and logs are properly installed (refer to the specific log set installation manual). -
Page 57: Normal Flame Height
To adjust the exhaust damper, use a flashlight to look into the convection air cavity and note the damper position indicator. Hook glass latch tool in the hole at the end of the damper rod, pull outward about ⅛” and turn clockwise to close the vent damper, release. -
Page 58: Replacement Parts And Service
Maintaining Correct Pilot-Flame, Pilot Outage, and Relighting The pilot flame must be checked during initial installation and annually by a qualified Mendota Technician. This fireplace uses flame rectification technology. If the pilot flame is turned down too low, the flame sensor may not detect the pilot flame and the pilot may not stay lit. -
Page 59: Convection Blowers
Convection Blowers: The convection blowers are mounted on the firebox’s rear wall. To access the convection blowers, remove the burners and airbox from the fireplace. Accent Light: The accent light is mounted in the firebox top center area. The accent light wire harness is run from the light housing to the left side and then down to the ignition control module. -
Page 60: Valve Assembly
Valve Assembly 65-02-01033 FIREBOX SIDE PANEL GASKET, FV36 65-02-01034 VALVE ACCESS PANEL GASKET, FV42 HA-120-00017 FRONT SHUTTER BOX ASSEMBLY 05-04-00075 PILOT, PSE-NA361, 2-W AY HOOD HA-110-00007 HA-120-00018 VALVE AND SOLENOID ASSEM BLY REAR SHUTTER BOX ASSEMBLY f i r e - p a r t s . c o m 05-02-00344 VALVE, 885 PROFLAM E (NG) SIT# 0.885.001 HA-57-00714... -
Page 61: Burners
Burners 70-01-00145 BURNER, REAR 70-01-00147 BURNER, FRONT f i r e - p a r t s . c o m HA-110-00017 GRATE HA-109-00167 AIRBOX FV42 85-03-01068... -
Page 62: Glass Frame Assembly
Glass Frame Assembly TO REMOVE DOOR 1. Use the glass latch tool to disconnect the spring latches from the glass frame. Insert tool into hole in latch, pull towards you and Rotate 90 degrees to disengage top latches. Remove tool. There are two spring latches on top of this gas fireplace. -
Page 63: To Replace Damaged Glass
GASKET GLASS f i r e - p a r t s . c o m The glass frame assembly and its individual components are available through Mendota. Contact your dealer for more detailed ordering information. GLASS FRAME ASSEMBLY #HA-120-00001... -
Page 64: Installation Checklist
INSTALLATION CHECKLIST All items on the checklist must be completed. Co-axial vent rigid pipe, wall vent cap or roof vent cap is installed by a Mendota approved serviceperson in accordance with instructions. All joints are secured, "twist-locked" and leak-proof. 1000°F sealant is used on the inner pipe joints of all DuraVent pipe sections. -
Page 65: Homeowner Operation
Thank you for choosing a Mendota to be a source of comfort and beauty in your home. We have designed this manual to help you enjoy all your Mendota fireplace has to offer. You will find tips, operating instructions, and frequently asked questions to support the features and functions of your fireplace. -
Page 66: Operation Information
OPERATION INFORMATION Using Your Remote Control Your Mendota remote control is pre-programmed to your fireplace. Ensure you have installed 3 AAA batteries into your remote. Press the top button on the remote control. If you do not hear a beep when you press this button, follow the instructions below to synchronize your fireplace and remote control. -
Page 67: Remote Control Functions
Remote Control Functions Note: You will hear an audible beep once every time a remote control button is pressed, signaling that the command has been received. Locate the four function buttons on the remote control: f i r e - p a r t s . c o m 1. - Page 68 c. Smart Thermostat (Smart): In this mode, room temperature is maintained and flame height adjusts automatically to provide continual, efficient heat. All other functions of the normal thermostat mode, except the flame height adjustment, are allowed. Manual flame height adjustment is not allowed in this mode.
-
Page 69: Remote Control Operating Instructions
Remote Control Operating Instructions To Turn on the Fireplace 1. Press the on/off button. The remote control display will show all active icons on the screen. 2. Select the thermostat mode by pressing the thermostat button: OFF (meaning Manual), ON (meaning Normal Thermostat) or Smart (meaning Smart Thermostat). - Page 70 Icon Details Mode Button: Pressing the mode button toggles between the various available functions: flame height, fan speed, accent light intensity and rear burner on/off. Flame Height: Six flame height levels are available. While the flame height icon is displayed, pressing the up or down button once will increase or decrease the flame height by 1 of 6 increments.
-
Page 71: Ipi And Cpi Modes
- p a r t s . c o m mode. Recommended: Mendota recommends keeping the fireplace in CPI mode. While not mandatory, this will keep the fireplace chimney heated for proper updraft during burner ignition, and it will also eliminate excessive condensation of exhaust vapors on the door glass. -
Page 72: First-Time Lighting Instructions
FIRST-TIME LIGHTING INSTRUCTIONS Warning: If you do not WHAT TO DO IF YOU SMELL GAS follow these instructions • Do not light any appliance. exactly, a fire or • Do not touch any light switch explosion may result • Do not use any phone in your building. causing property •... -
Page 73: Frequently Asked Questions
Where can I find the model and serial numbers? When requesting service, you will be asked to provide the model number, serial number, and manufacture date to your Mendota dealer. This information will expedite the warranty verification process. This is an example of your listing label:... -
Page 74: Can I Operate My Fireplace During Power Outages
Required Annual Maintenance The following procedures must be performed each year by a qualified Mendota service person. Note: Any adjustments to burner, pilot, or logs must be done by a qualified Mendota service person. Recommended steps for yearly maintenance: f i r e - p a r t s . c o m 1. -
Page 75: How Do I Clean The Viewing Glass
(usually a thin black film on the fireplace viewing glass or on the outside of the home around the vent cap), the unit must be immediately turned off and the local Mendota f i r e - p a r t s . -
Page 76: How Do I Set The Child-Lock Mode
7. Toggle master switch back on. 8. Press Mode button on remote. Select CPI mode to reignite the pilot. After pilot lights, turn on your remote to ignite fireplace. After completing these steps, contact your Mendota dealer if fireplace won’t turn on. FV42 85-03-01068... -
Page 77: What Happens When I First Light My Fireplace
Adhesives, glue, wall substrate, wall finish material, paints, and polishes are common materials that if used incorrectly will cause odor issues. Mendota is not responsible for any odor issues caused by materials used around the fireplace. -
Page 78: Warranty Qualification And Service Reference
Brief and Instruct owner on periodic maintenance of unit Owner Registration After installation, Mendota fireplace owners must register with Mendota to qualify for the Lifetime Limited Warranty. Product registration will activate your Lifetime Limited Warranty and ensure long life and trouble- free operation. -
Page 79: Mendota Standard Warranty And Lifetime Warranty On Direct Vent Gas Fireplaces And Inserts
Any part(s) found to be defective during the warranty period as outlined above will be repaired or replaced at Mendota’s option through an accredited distributor, dealer or pre-approved and assigned agent provided that the defective part is returned to the distributor, dealer or agent for inspection if requested by Mendota. - Page 80 Mendota dealers or agents in the negligence of their service work. At all times Mendota reserves the right to inspect reported complaints on location in the field claimed to be defective prior to processing or authorizing of any claim. Failure to allow this upon request will void the warranty.
- Page 81 Customers should contact the authorized selling dealer to obtain warranty service. In the event the authorized selling dealer is unable to provide warranty service, please contact Mendota by mail at the address listed below. Please include a brief description of the problem and your address, email and telephone contact information. A representative will contact you to make arrangements for an inspection and/or warranty service.
- Page 82 Owner Registration After installation, Mendota fireplace owners must register with Mendota to qualify for the Lifetime Limited Warranty. Product registration will activate your Lifetime Limited Warranty and ensure long life and trouble-free operation. Owners should complete the forms available at www.mendotahearth.com.
- Page 83 f i r e - p a r t s . c o m FV42 85-03-01068...
- Page 84 Please direct questions or concerns to your qualified Mendota dealer and installer. Thank you for choosing Mendota. Johnson Gas Appliance Company 520 E Avenue NW Cedar Rapids, Iowa 52405 www.mendotahearth.com f i r e - p a r t s . c o m...
