UM0897
User manual
Embedded Ethernet web client based on the STR91x
Introduction
This document describes the functioning of the STEVAL-PCC008V1 demonstration board
with an embedded Ethernet web client system which is based on ST's STR91xFAW
ARM966E-S™ 16/32-bit Flash MCU with Ethernet microcontroller. This system is designed
for viewing/monitoring jpeg images taken from an HTTP web server or from an IP camera
present on the network. The images are displayed on the TFT present on the board, thus
enabling surveillance. This system needs to be plugged into the network to access jpeg
images from the HTTP web server or from the IP camera. This system is compatible with
web servers which do not require support for secure socket layer (SSL) and it uses specific
programmed requests to capture images from specific web servers.
The system uses a 2.4" TFT for displaying the images captured from the network. The
captured jpeg images are displayed on the TFT by converting them into bitmap through a
jpeg decompression algorithm. A six-button keypad is provided for navigating through the
menus. The availability of the micro-SD card on the board helps in handling large quantities
of data from the network.
July 2010
Doc ID 17012 Rev 1
1/25
www.st.com
Advertisement
Table of Contents
Related Manuals for ST STEVAL-PCC008V1
Summary of Contents for ST STEVAL-PCC008V1
- Page 1 Introduction This document describes the functioning of the STEVAL-PCC008V1 demonstration board with an embedded Ethernet web client system which is based on ST's STR91xFAW ARM966E-S™ 16/32-bit Flash MCU with Ethernet microcontroller. This system is designed for viewing/monitoring jpeg images taken from an HTTP web server or from an IP camera present on the network.
-
Page 2: Table Of Contents
Contents UM0897 Contents Getting started ..........4 Package . - Page 3 UM0897 List of figures List of figures Figure 1. Web client with local display ..........4 Figure 2.
-
Page 4: Getting Started
Getting started UM0897 Getting started Package The embedded Ethernet web client based on the STR91x system package includes the following items: ● Hardware content – Demonstration board equipped with a TFT, micro-SD card, and keypad ● Firmware – Already programmed in the system –... -
Page 5: Jumper Settings
UM0897 Getting started 1.2.2 Jumper settings The jumper configurations are listed in the table below. Jumper JP19 is used to make the system work either as "Web Client with local display" or as "Web Client with remote display". Table 1. Jumper settings Jumper Jumper position... -
Page 6: Network Setup
Getting started UM0897 Network setup The system needs to be plugged into a network. The network can be accessed in either of the following ways: ● Setting up a local network ● Using an existing network (provided it doesn't restrict external devices). 1.3.1 Setting up a local network The configuration shown in... -
Page 7: Ipcam Board Setup
UM0897 Getting started These images should be given names as advised below: Name the images starting from 31.jpeg, 32.jpeg, …… 60.jpeg. In network mode, the demonstration unit requests these images one by one. If the user wishes to add one file (for example IMAGE.jpeg), first delete any file from the list (for example 40.jpeg), then rename IMAGE.jpeg to 40.jpeg which allows the user to display that image on the TFT. -
Page 8: System Overview
System overview UM0897 System overview Server client general description The system is based on the web server-client relationship as shown in Figure 5. The web server system connects to the network by opening up a connection and listening on it. Any web client system can connect to that port on which the server is listening. -
Page 9: Str9 Microcontroller
The STR912FAW44X6 has 512 kbytes of main Flash and 96 kbytes of SRAM. It has many communication interfaces. For more details refer to http://www.st.com/mcu/inchtml-pages-str9.html. Note: The STR9 has two SPI channels. In the demonstration board one SPI is allocated to U2, ®... -
Page 10: Power Supply Unit
System overview UM0897 2.2.4 Power supply unit The onboard supply unit contains the low drop fixed positive voltage regulator LD1117D33TR to generate 3.3 V and ultra-low drop voltage regulator LDS3985M18R to generate 1.8 V. This 1.8 V supply is needed for the STR9 microcontroller. 2.2.5 User interface section A set of 6 keys is provided for the user interface section in order to select the options on the... -
Page 11: Running The System
UM0897 Running the system Running the system Powering up The web client system works on a 5 V power supply. An adapter capable of supplying 5 V, 500 mA can be used. When the system working as "Web client with local display" is powered up, a menu will be displayed on the TFT as shown in Figure 1. -
Page 12: Figure 9. Tft Display 2
Running the system UM0897 Figure 9. TFT display 2 When the Enter button is pressed, the TFT displays the message below. By default HTTP WEBSERVER ADDRESS is selected. Use UP and DOWN to change the digits and the LEFT and RIGHT keys to navigate between the digits. Figure 10. -
Page 13: Figure 11. Tft Display 4
UM0897 Running the system Figure 11. TFT display 4 Use the ESC key to go back to the previous menu. Once the IP address is set, connect the board to the network. Press the appropriate button to capture the images from the server and they will be displayed on the TFT. -
Page 14: Schematics
Schematics UM0897 Schematics Figure 12. Microcontroller 14/25 Doc ID 17012 Rev 1... -
Page 15: Figure 13. Ethernet
UM0897 Schematics Figure 13. Ethernet Doc ID 17012 Rev 1 15/25... -
Page 16: Figure 14. Connectors
Schematics UM0897 Figure 14. Connectors 16/25 Doc ID 17012 Rev 1... -
Page 17: Figure 15. Power Management
UM0897 Schematics Figure 15. Power management Doc ID 17012 Rev 1 17/25... -
Page 18: Bill Of Material
Bill of material Table 2. STEVAL-PCC008V1 main board : BOM Manufacturer’s ordering code / Supplier Reference Category Comp. descr. Package Manuf. orderable part Suppl. orderin designator number or g code equivalent Ethernet PHY TQFP64 10x10 mm STMicroelectronics E-STE100P LDS3985M18R ultra-low drop... - Page 19 Table 2. STEVAL-PCC008V1 main board : BOM (continued) Manufacturer’s ordering code / Supplier Reference Category Comp. descr. Package Manuf. orderable part Suppl. orderin designator number or g code equivalent PCB mountable, Part# RJ45 with magnetics and CONN1 right angle, through-...
- Page 20 Table 2. STEVAL-PCC008V1 main board : BOM (continued) Manufacturer’s ordering code / Supplier Reference Category Comp. descr. Package Manuf. orderable part Suppl. orderin designator number or g code equivalent D5,D6,D9 SMD0805 C5,C7 10 pF SMD0805 C72,C73 12.5 pF SMD0805 LEDs...
- Page 21 Table 2. STEVAL-PCC008V1 main board : BOM (continued) Manufacturer’s ordering code / Supplier Reference Category Comp. descr. Package Manuf. orderable part Suppl. orderin designator number or g code equivalent R1,R7,R26,R27,R 100 Ω 29,R31,R113, SMD0805 R114 R2,R3,R4,R14, R24,R30,R32, R33,R34,R35, SMD0805 Resistors...
- Page 22 Table 2. STEVAL-PCC008V1 main board : BOM (continued) Manufacturer’s ordering code / Supplier Reference Category Comp. descr. Package Manuf. orderable part Suppl. orderin designator number or g code equivalent L1,L2,L3,L6 10 µH Through-hole (6mm x 6mm ) push- button, through-...
- Page 23 Table 3. STEVAL-PCC008V1: daughterboard: BOM Manufacturer’s Reference Component ordering code / Supplier Ordering Category Package Manufacturer Supplier Designator Description Orderable Part Code Number or Equivalent SWITCH, SW1, SW2, SW3, 6.00 mm x 6.00 C&K Switches TACTILE, SPNO, PTS645SL70TR LFS Digi-Key...
-
Page 24: Revision History
Revision history UM0897 Revision history Table 4. Document revision history Date Revision Changes 05-Jul-2010 Initial release. 24/25 Doc ID 17012 Rev 1... - Page 25 No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this document refers to any third party products or services it shall not be deemed a license grant by ST for the use of such third party products or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such third party products or services or any intellectual property contained therein.
