VP-732 Quick Start Guide
This guide helps you install and use your VP-732 for the first time.
Go to
Scan for full manual
upgrades are available.
Step 1: Check what's in the box
VP-732 Presentation Switcher/Dual Scaler
1 Power cord
Step 2: Get to know your VP-732
#
Feature
1
Receiver
IR
2
LED
UNIV 1 –4
3
PROGRAM
INPUTS Buttons
HDMI 1 – 4
4
(light green
when selected)
DP 1 – 2
5
6
PROGRAM BLANK Button
7
PROGRAM FREEZE Button
UNIV 1 –4
8
PIP / PREVIEW
INPUTS Buttons
HDMI 1 – 4
9
(light yellow
when selected)
DP 1 – 2
10
11 PIP / PREVIEW BLANK Button
12 PIP / PREVIEW FREEZE
Button
13 PREVIEW MODE Button
14 MENU Button
VP-732 Quick Start (P/N: 2900-300893QS REV 2)
www.kramerav.com/downloads/VP-732
4 Rubber feet
1 Quick start guide
Function
Receives signals from the remote control transmitter.
Lights red when the unit receives IR remote commands.
Press to select one of the universal inputs (configured via the OSD menu) and the appropriate
audio source.
Press to select one of the HDMI inputs.
Press to select one of the DP inputs.
Press to toggle between a blank screen (blue or black) and the video display. Can be configured
to mute the audio signal at the same time.
Configure using the OSD menu.
Press to freeze/unfreeze the video display. Can be configured to mute the audio signal at the
same time. Configure using the OSD menu.
Press to select one of the universal inputs (configured via the OSD menu) and the appropriate
audio source.
Press to select one of the HDMI inputs.
Press to select one of the DP inputs.
Press to toggle between a blank screen (blue or black) and the video display. Can be configured
to mute the audio signal at the same time.
Configure using the OSD menu.
Press to freeze/unfreeze the video display. Can be configured to mute the audio signal at the
same time. Configure using the OSD menu.
Press to toggle between PIP and Preview Mode operation.
Press to display the OSD menu screen. Press again to return to normal operation.
to download the latest user manual and check if firmware
1 Set of rack ears
IR remote control transmitter with batteries
P/N:
2 9 0 0 - 3 0 0 8 9 3 QS
Rev:
2
