VP-734 Quick Start Guide
This guide helps you install and use your product for the first time. For more detailed information, g
http://www.kramerav.com/manual/VP-734 to download the latest manual or scan the QR code on the left.
Step 1: Check what's in the box
The VP-734 Presentation Switcher/ Scaler
IR remote control transmitter with batteries
Step 2: Install the VP-734
To rack mount the machine attach both ear brackets to the machine (by removing the three screws
from each side of the machine and replacing those screws through the ear brackets) or place the
machine on a table.
Step 3: Connect inputs and outputs
Always switch OFF the power on each device before connecting it to your
For best results, we recommend that you always use Kramer high-performance cables to connect AV equipment to the VP-734.
DVD Player
Computer Graphics
(CV via breakout cable)
Source (VGA)
Connect the AUDIO LINE OUT stereo audio output
Step 4: Connect the power
Connect AC power to the rear of the VP-734, switch on its power
and then switch on the power on each device.
VP-734 Quick Start (P/N: 2900-300357QS REV 2)
BlueRay
Laptop
Notebook
Disk Player
Balanced stereo audio
connection
1 Power cord
1 Quick start guide
VP-734
.
Analog Audio
Inputs
Projector
Monitor
Control Device
Unbalanced stereo
audio connection
o to
1 Set of ear racks
4 Rubber feet
Active
Speakers
PC
Audio Power
Speakers
Amplifier
P/N:
2 9 0 0 - 3 0 0 3 5 7 QS
Rev:
2
