  • Page 1 MP315 Riding Trowel OPERATIONS & PARTS MANUAL REVISION: 07.2017...
  • Page 2 This manual, or a copy of it, must be kept with the machine at all times. There is a manual storage container located on the machine for your convenience. 053423; 12/10...
  • Page 3 No part of this manual may be reproduced or transmitted in any form or by any means, electronics or mechanical, for any purpose, without the express written permission of Allen Engineering Corporation (AEC). AEC assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual.

  • Page 4: Limited Warranty

    Allen reserves the choice to repair or replace. 2. If Allen chooses to replace the part, it will be at no cost to the customer and will be made available to the Allen Distributor, Dealer, or Rental Center from whom the End User purchased the product.

  • Page 5: Table Of Contents

    Table of Contents Sect No. Title Page Limited Warranty ..........ii Information Contained In This Manual .
  • Page 6 Table of Contents, continued Parts ........... . 4-1 Factory Service Information .

  • Page 7: Information Contained In This Manual

    Complete any warranty requirements as specified by the engine manufacturer in their instructions found inside the manual box located on the back of the riding trowel operator’s seat. Your engine and clutch is not manufactured by Allen Engineering Corporation, Inc, and therefore is not covered under Allen Engineering Corporation, Inc warranty.

  • Page 8: Dealer Information

    Dealer Information Your Dealer has Allen Engineering Corporation trained mechanics and original Allen replacement parts. Always contact the Allen Dealer who sold you this machine for Allen Certified repairs and replacement parts. Place Allen Dealer information below for future reference...

  • Page 9: Ordering Parts

    Ordering Parts Section 4.0 contains illustrated parts lists for help in ordering replacement parts for your machine. Follow the instructions below when ordering parts to insure prompt and accurate delivery: All orders for service parts - include the serial number for the machine. Shipment will be delayed if this information is not available.

  • Page 10: Model Number - Serial Number Codes

    Model Number - Serial Number Codes Manufacturer’s Codes: When ordering parts or requesting service information, you will always be asked to specify the model and serial numbers of the machine. The legends below specifically defines each significant character or group of characters of the Model Number and Serial Number codes. Model Number MODEL SERIES...

  • Page 11: Unit Identification

    Unit Identification Unit Identification Plate Location: An identification plate listing the model number and the serial number is attached to each unit and is located on the rear lower left side of mainframe. Refer to Figure 1 for serial number and model number location.

  • Page 12: Technical Specifications

    Technical Specifications Measurements in this manual are in U.S. units and their customary metric units (i.e., metric units contained within brackets [8 mm]). The machine RIGHT-HAND and LEFT-HAND sides are deter- mined by sitting on machine (SOM) facing in the direction the machine will travel when going forward.
  • Page 13 Technical Specifications, continued • Transmission Type .......Torque Converter Clutch • Drive Belt Type .

  • Page 14: Engine Specifications

    Engine Specifications Honda Engine Information • Model ..........GX-690 UTDW •...

  • Page 15: Machine Dimensional Specifications

    Machine Dimensional Specifications All information, specifications, and illustrations on this page in this manual are subject to change without notice and are based on the latest information at the time of publication. 53 [1346 mm] HEIGHT 49 [1245 mm] WIDTH 98 [2489 mm] LENGTH 053423;...
  • Page 16 Power Level Press Overall Overall Maximum dB (A) dB (A) dB (A) m/sec² m/sec² m/sec² MP315 Honda 89.3 87.4 2.40 6.90 3.83 This information was acquired from sound and vibration analysis tests conducted at Allen Engineering Corporation test facilities. 053423; 12/10...
  • Page 17 819 South 5th St., Paragould, AR 72450 USA Authorised Representative in EU: Mr. Thomas Voeler, ab lin-pro Femvägsskälet 3, 421 50 Västra Frölunda. Sweden Equipment: MP315 Riding Trowel Description: Ride-on, IC engine powered, concrete smoothing machine. Notified Body: Not required. Harmonized Standards Applied:...
  • Page 18 INTENTIONALLY LEFT BLANK 053423; 12/10...

  • Page 19: Safety

    SECTION 1 SAFETY Section 1 SAFETY 053423; 12/10...

  • Page 20: State Regulations

    SECTION 1 State Regulations SAFETY CALIFORNIA PROPOSITION 65 WARNING Gasoline engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects and other reproductive harm. 053423; 12/10...
  • Page 21 Federal Regulations SECTION 1 SAFETY SILICOSIS WARNING Grinding/cutting/drilling of masonry, concrete, metal and other materials with silica in their composition may give off dust or mists containing crystalline silica. Silica is a basic component of sand, quartz, brick clay, granite and numerous other min- erals and rocks.

  • Page 22: General Safety Precautions

    SECTION 1 SAFETY General Safety Precautions 1.1.1 Safety-Alert Signs This manual contains Safety-Alert Signs, as defined below, which must be followed to reduce the possibility of improper servi ce damage to the equipment or personal injury. Read and follow all Safety-Alert Signs included in this manual. NOTE defines an operating procedure, condition, etc.

  • Page 23: Spark Arrestor Notice

    SECTION 1 SAFETY Spark Arrestor Notice 1.2.1 Laws Pertaining to Spark Arrestors Some states require that in certain locations arrestors be used on internal combustion engines. A spark arrester is a device designed to prevent the discharge of spark or flames from the engine exhaust. It is often required when operating equipment on forested land to prevent the risk of fires.

  • Page 24: Operating Safety

    SECTION 1 SAFETY Operating Safety 1.3.1 Operating Safety Familiarity and proper training are required for the safe operation of this equipment! Equipment operated improperly or by untrained personnel can be dangerous! Read the operating instructions contained in both this manual and the engine manual and familiarize yourself with the location and proper use of all controls.
  • Page 25 SECTION 1 1.3, continued SAFETY Operating Safety 1.3.13 ALWAYS close fuel valve on engines equipped with one when machine is not being operated. 1.3.14 ALWAYS store the equipment properly when it is not being used. Equipment should be stored in a clean, dry location out of the reach of children. 1.3.15 ALWAYS operate the machine with all safety devices and guards in place and in working order.

  • Page 26: Engine Safety

    SECTION 1 SAFETY Engine Safety 1.4.1 Engine Safety Internal combustion engines present special hazards during operation and fueling. Read and follow the warning instructions in the engine owner’s manual and the safety guidelines below. Failure to follow the warnings and safety guidelines could result in severe injury or death. 1.4.2 DO NOT run the machine indoors or in an enclosed area such as a deep trench unless adequate ventilation, through such items as exhaust fans or hoses, is...
  • Page 27 SECTION 1 Service Safety SAFETY 1.5.1 Service Safety Poorly maintained equipment can become a safety hazard! In order for the equipment to operate safely and properly over a long period of time, periodic maintenance and occasional repairs are necessary. 1.5.2 DO NOT attempt to clean or service the machine while it is running.
  • Page 28 SECTION 1 SAFETY Safety and Operation Labels The safety and operation labels shown in this section are placed in important areas on the machine to draw attention to potential safety hazards and service information. Should any of these labels become unreadable or damaged, replacement labels can be odered from your distributor. This is a multi-purpose label that reqi- ures the operator to have maximum eye, hearing, hand, and feet protec-...

  • Page 29: Safety And Operation Labels

    SECTION 1 1.6, continued SAFETY Safety and Operation Labels This label is a maintenance reminder to grease the thrust bearing daily. This will ensure that the life span of the bearings will be maintained at their optimal preformance level. This label cautions against allowing cleaning agents, surface treatments, or other foreign substances to contaminate drive components.
  • Page 30 SECTION 1 1.6, continued SAFETY Safety and Operation Labels This label warns of the risk hazards associated with engine exhaust fumes causing heath issues as identified by the State of California. This label states that this equipment was proudly manufactured in the United States of America. This label cautions the operator of pinch points on the machine.
  • Page 31 SECTION 1 1.6, continued SAFETY Safety and Operation Labels This label shows the location where hand tools are to be placed while operating the machine. This label warns of sparks created by this machine and that a spark arrestor may be required.
  • Page 32 SECTION 1 SAFETY Pan Installation Instructions This section details the proper technique to utilize the lifting bridle system and the dolly jack system in a safe manner to install pans. (NOTE: Images are for illustration purposes only) Use a lifting sling (bridle) with a capacity of at least a 2:1 weight ratio for the equipment being hoisted.

  • Page 33: Pan Installation Instructions

    SECTION 1 1.7, continued SAFETY Pan Installation Instructions Use the appropriate set of jacks that are designed for the machine you are lifting. STEP 1: Attach the front and rear dolly jacks into the machine at the receiving tube locations. (A) STEP 2: Slowly lift machine in a safe manner to a height that is required to safely install the pans.
  • Page 34 SECTION 1 SAFETY 1-16 053423; 12/10...

  • Page 35: Operations

    SECTION 2 OPERATIONS Section 2 OPERATIONS 053423; 12/10...
  • Page 36 This machine is built with user safety in mind. However, it can present hazards if improperly operated and serviced. Follow operating instructions carefully. If you have any questions about operating or servicing this equipment, please contact your Allen Engineering Dealer or AEC Customer Service at 800-643-0095 or 870-236-7751. 053423; 12/10...

  • Page 37: Introduction

    Introduction 2.1.1 Description The MP315 riding trowel is a modern high production machine. Finishing rates will vary depending on the operators skill and job conditions. This riding trowel has eight finishing blades. The standard duty gearboxes are designed to provide exceptional performance with low maintenance and trouble free use under some of the worst conditions.
  • Page 38 SECTION 2 OPERATIONS Start Up Procedures 2.9.1 Before Starting Procedures Before starting the riding trowel check for the following: Oil level in engine. Oil level in riding trowel gearboxes. Fuel level in fuel tank. Condition of riding trowel arms and blades. Verify that daily maintenance of grease points have been performed.

  • Page 39: Start Up Procedures

    SECTION 2 2.2, continued OPERATIONS Start Up Procedures 12V Accessory LOW OIL LIGHT LIGHT SWITCH KEY SWITCH HOURMETER ENGINE CHOKE FIGURE 2.2.1 TOP VIEW OF CONTROLS 053423; 12/10...
  • Page 40 2.3.1 Operating The Riding Trowel To utilize your Allen Engineering MP315 Rider to its fullest capacity the machine should be driven in the direction the operator is facing. This will finish the widest possible area while giving the operator an excellent view of the slab surface about to be troweled.

  • Page 41: Operating Instructions

    SECTION 2 2.3, continued OPERATIONS Operating Instructions With the operator in the seat, show him the functions of the joysticks [B] and [C] and how to start the machine. Refer to Figure 2.3.1. A hard level concrete slab with water on the surface is an ideal place for an operator to practice with the machine.
  • Page 42 SECTION 2 2.3, continued OPERATIONS Operating Instructions 2.3.3 Steering The Riding Trowel A slight “feathering motion” forward and backward with the left hand joystick is required to move the machine in a straight path to the left or right while operating the right hand joystick.
  • Page 43 SECTION 2 2.3, continued OPERATIONS Operating Instructions 2.3.4 Pitch Adjustment Different pitch angles are needed as you work the different stages of the concrete. Refer to Figure 2.3.4 table below. When changing or setting pitch (angle of trowel blades), slow the machine down, set the desired degree of pitch on the left side of the machine and then adjust the right side to match.
  • Page 44 SECTION 2 2.3, continued OPERATIONS Operating Instructions 2.3.5 Steering Response Adjustment There are three settings on this Riding Trowel for steering response. Some operators like a fast response to steering while others would rather have a slower response when pressure is applied to the operator joysticks. The following illustrations show each appropriate setting on the lower control arms to achieve the desired response.

  • Page 45: Service

    SECTION 3 SERVICE Section 3 SERVICE 053423; 12/10...

  • Page 46: Periodic Maintenance

    SECTION 3 SERVICE Periodic Maintenance Periodic Maintenance Schedule The table below list basic trowel and engine maintenance. Refer to OEM engine manufacturer’s Operation Manual for additional information on engine maintenance. A copy of the engine operator’s manual was supplied with the machine when it was shipped.

  • Page 47: Trowel Gearbox

    Replace fill plug after proper level has been achieved. Fill so that there is oil 1/2 way in the sight glass. Use Allen Oil only. Each Gearbox has a grease fitting on top cover that must be greased (2 SHOTS ONLY) every 300 operating hours.
  • Page 48 SECTION 3 SERVICE Drive Belt 3.3.0 Drive Belt Maintenance The drive belts MUST be free from oil and foreign contaminants to prolong life. 3.3.1 To Replace The Drive Belt: Place the trowel on a flat, level surface with the blades pitched flat. Disconnect the battery.
  • Page 49 SECTION 3 3.3, continued SERVICE Drive Belt REMOVE POSITIVE BATTERY CABLE FIGURE 3.3.1 BATTERY DISCONNECT 053423; 12/10...

  • Page 50: Drive Belt

    SECTION 3 3.3, continued SERVICE Drive Belt DRIVEN PULLEY CLUTCH COVER BELT DRIVELINE BOLT FIGURE 3.3.2 BELT REPLACEMENT 053423; 12/10...
  • Page 51 SECTION 3 3.3, continued SERVICE Drive Belt U-JOINT COUPLER BEARING MOUNT HARDWARE FIGURE 3.3.3 BELT REPLACEMENT 053423; 12/10...
  • Page 52 SECTION 3 SERVICE Control Lever Adjustment Control Lever Adjustment Procedure Be sure that the trowel is on a level surface. The control levers should line up evenly. If levers appear out of adjustment they can be re-adjusted forward or backwards as follows: Trowel must be placed on flat level surface that fully supports the blades on both rotors.

  • Page 53: Control Lever Adjustment

    SECTION 3 3.4, continued SERVICE Control Lever Adjustment FIGURE 3.4.1 CONTROL LEVER ADJUSTMENT 053423; 12/10...
  • Page 54 SECTION 3 SERVICE Right Hand Control Lever Adjust RH Control Lever Adjustment Right Or Left Procedure The right hand lever should be set to the same angle as that of the left to form a “V”. If levers become out of adjustment adjust the right hand lever as follows: Remove jam nuts [D].

  • Page 55: Right Hand Control Lever Adjust

    SECTION 3 3.5, continued SERVICE Right Hand Control Lever Adjust “V” FORM There should be a 10” gap at the top of the joysticks. JOYSTICK LOCATIONS LOWER CONTROL FIGURE 3.5.1 “V” FORM ORIENTATION FIGURE 3.5.2 RIGHT HAND CONTROL ADJUSTMENT 053423; 12/10 3-11...
  • Page 56 SECTION 3 SERVICE Lift Lever Adjustment Lift Lever Adjustment Procedure Damage to and/or replacement of a trowel arm can change the adjustment of the lift lever. This can unbalance the trowel arms and cause the riding trowel to wobble during operation. To operate smoothly the lift lever on all trowel arms must be adjusted the same to ensure that the riding trowel is balanced correctly.

  • Page 57: Lift Lever Adjustment

    SECTION 3 3.6, continued SERVICE Lift Lever Adjustment TROWEL ARM BLADE FIGURE 3.6.1 PRESSURE PLATE LOCATION SPIDER BOSS FIGURE 3.6.2 FASTENER HARDWARE REMOVAL 053423; 12/10 3-13...
  • Page 58 SECTION 3 SERVICE Transporting Trowel Transporting Trowel Procedures Optional dolly jacks are available for short moves or to aid in servicing the trowel. Install dolly jacks as follows: Inspect dolly jack for serviceability and damage. Place riding trowel on firm level ground. Tie steering levers [I] to frame to prevent them from tipping forward when trowel is being lifted.

  • Page 59: Transporting Trowel

    SECTION 3 3.7, continued SERVICE Transporting Trowel FIGURE 3.7.2 FIGURE 3.7.3 FRONT DOLLY JACK REAR DOLLY JACK LOCATION LOCATION 053423; 12/10 3-15...
  • Page 60 SECTION 3 3.7, continued SERVICE Transporting Trowel The dolly jack lifting system is designed for short moves and to aid in servicing the trowel. It is not a substitute for a towing system or trailer. An optional lifting bridle [N] is available and recommended for lifting the trowel.
  • Page 61 SECTION 3 3.7, continued SERVICE Transporting Trowel FIGURE 3.7.7 LIFTING HOOK LOCATION 053423; 12/10 3-17...
  • Page 62 SECTION 3 SERVICE Battery Jump Start Battery Jump Start Procedures Occasionally it may be necessary to jump start a weak battery. If jump starting is necessary the following procedure is recommended to prevent starter damage, battery damage, and personal injury. Jump starting a battery incorrectly can cause the battery to explode resulting in severe personal injury or death.

  • Page 63: Battery Jump Start

    SECTION 3 3.8, continued SERVICE Battery Jump Start BATTERY FIGURE 3.8.1 BATTERY LOCATION 053423; 12/10 3-19...
  • Page 64 SECTION 3 Notes SERVICE 3-20 053423; 12/10...
  • Page 65 SECTION 4 PARTS Section 4 PARTS 053423; 12/10...
  • Page 66 SECTION 4 Factory Service Information PARTS This section contains the illustrated drawings and parts list for help in identifying and/or ordering replacement parts for your machine. Follow the instructions in the front section of this manual “Ordering Parts” when ordering replacement parts to insure prompt and accurate delivery. The Right Hand (RH) and/or Left Hand (LH) orientations are defined from the operator’s view of sitting on machine (SOM).
  • Page 67 SECTION 4 Replacement Parts Procedures PARTS We recommend AEC quality replacement parts, available from the AEC Customer Service Department or your nearest AEC Dealer. Part numbers are subject to change without notice. Part numbers might be different outside of the United States of America. Use part numbers listed in the applicable parts list table when you place your order.
  • Page 68 4.1 Illustration SECTION 4 Seat Frame Unit PARTS 053423; 12/10...
  • Page 69 PANEL, FRONT MP215 WELD’T, SEAT FRAME MP205 053129 U-BOLT, 3 1/2” X 3/8-16 053189 053211 PROP F/ SEAT FRAME 053221 DECAL MP315 RIDER 10-3/4x3 DECAL, PROPOSITION 65 WARNING (SP) 053440 053447 DECAL, HAND TOOL AREA (SP) DECAL, LIGHTS (SP) 053450 053451...
  • Page 70 SECTION 4 4.2 Illustration PARTS Main Frame Unit 15 11 053423; 12/10...
  • Page 71 048448 BEARING ASSEMBLY F/ ROTOR MOUNT X1 048561 BEARING, I-GLIDE FLANGE 048560 048571 FOOT REST STRAP, TANK MSP425 048921 DECAL, MFG. BY ALLEN ENG. 048937 FRONT COVER PLATE 053137 COVER PLATE 053138 COVER PLATE 053170 ASSY, VANGUARD THROTTLE PEDAL 053188...
  • Page 72 SECTION 4 4.3 Illustration PARTS Steering System Mainframe hidden for clarity. 053423; 12/10...
  • Page 73 4.3 Parts List SECTION 4 Steering System PARTS ITEM PART # DESCRIPTION FSTN, HHCS 1/4-20 X 1-1/2 GR 8 010005 FSTN, NUT 1/2-20 JAM HEX 010051 010085 FSTN, FW 1/2 FSTN, NUT NYLOK 3/8-16 010464 010711 CLIP, .125x2-9/16 HITCH PIN 019900 ROD, END FEMALE 1/2”...
  • Page 74 SECTION 4 4.4 Illustration PARTS Spray System Mainframe hidden for clarity. Bottom View with Mainframe hidden for clarity. 4-10 053423; 12/10...
  • Page 75 4.4 Parts List SECTION 4 Spray System PARTS ITEM PART # DESCRIPTION FSTN, NUT HEX NYLOCK 5/16-18 012612 TIP, 80°x0.10 GPM BRASS SPRAY 012702 WSHR, #10 Z STL SAE FLAT 018072 NUT, 10-32 NYLOCK HEX 029568 PUMP, SPRAY SYSTEM 033735 SCR, 10-32 X 3/8 SLTD RDH MACH 036791 039329...
  • Page 76 SECTION 4 4.5 Illustration PARTS Pitch Control Assembly Tube not shown for clarity. 4-12 053423; 12/10...
  • Page 77 PLUNGER, 1/4-20 BALL 036797 BUSHING, CABLE ASSY 036914 BEARING, NAT-1220 THRUST 100340 CRANK HANDLE & SCREW SHAFT ASY 026541 FSTN, SHSS 1/4-20 X 3/8 012869 DECAL, F/ PITCH CONTROL TUBE 032377 DECAL, ALLEN VERTICAL BRUSHED CHROME 053442 053423; 12/10 4-13...
  • Page 78 SECTION 4 4.6 Illustration PARTS Engine System - GX690 Honda 4-14 053423; 12/10...
  • Page 79 SECTION 4 4.6 Parts List PARTS Engine System - GX690 Honda ITEM PART # DESCRIPTION FSTN, HHCS 3/8-16 X 3/4 010035 FSTN, HHCS 7/16-14 X 1-1/4 010053 FSTN, HHCS 1/2-13 X 2-1/4 GR 5 010072 010083 FSTN, FW 3/8 010084 FSTN, FW 7/16 010091 FSTN, LW 3/8...
  • Page 80 SECTION 4 4.7 Illustration PARTS Driveline System Engine Plate Member 4-16 053423; 12/10...
  • Page 81 4.7 Parts List SECTION 4 Driveline System PARTS ITEM PART # DESCRIPTION FSTN, HHCS 7/16-14 X 1-1/4 010053 FSTN, HEX NUT 7/16-14 010104 KEY, 3/16 SQ X 2 010273 KEY, 1/4 SQ X 1 LG MACHINE 011791 1” FLANGED 2 BOLT BEARING ECENTRIC COLLAR 039136 STOCK, 1/4 SQx4 LG KEY 024820...
  • Page 82 SECTION 4 4.8 Electrical Schematic PARTS 4-18 053423; 12/10...
  • Page 83 SECTION 4 4.8 Electrical Schematic (cont’d) PARTS 053423; 12/10 4-19...
  • Page 84 SECTION 4 4.9 Illustration PARTS Right Hand Rotor Assembly 4-20 053423; 12/10...
  • Page 85 4.9 Parts List SECTION 4 Right Hand Rotor Assembly PARTS ITEM PART # DESCRIPTION FSTN, HHCS 5/16-18 X 1-3/4 010023 FSTN, HHCS 5/16-18 X 2 GR 5 010024 FSTN, HHCS 3/8-16 X 3/4 010035 010090 FSTN, LW 5/16 010091 FSTN, LW 3/8 FSTN, NUT HEX NYLOCK 5/16-18 012612 RING, Ø7/16 E-STYLE RETAINING...
  • Page 86 SECTION 4 4.10 Illustration PARTS Left Hand Rotor Assembly 4-22 053423; 12/10...
  • Page 87 4.10 Parts List SECTION 4 Left Hand Rotor Assembly PARTS ITEM PART # DESCRIPTION FSTN, HHCS 5/16-18 X 1-3/4 010023 FSTN, HHCS 5/16-18 X 2 GR 5 010024 FSTN, HHCS 3/8-16 X 3/4 010035 010090 FSTN, LW 5/16 010091 FSTN, LW 3/8 FSTN, NUT HEX NYLOCK 5/16-18 012612 RING, Ø7/16 E-STYLE RETAINING...
  • Page 88 SECTION 4 4.11 Illustration and Parts List PARTS Right Hand Spider Assembly ITEM PART # DESCRIPTION SPIDER ASSY, 1200 SFC RH-SOM 033818 FSTN, CABLT 3/8-16 X 1-1/4” 012990 WASHER, 3/8 EXT TOOTH LOCK 015682 BOLT, 3/8-16 X 7/8 DOG PT HEX HD CAP 015683 FSTN, NUT HEX JAM 3/8-16 015684...
  • Page 89 SECTION 4 4.12 Illustration and Parts List PARTS Left Hand Spider Assembly ITEM PART # DESCRIPTION SPIDER ASSY, 1200 SFC LH-SOM 024812 FSTN, CABLT 3/8-16 X 1-1/4” 012990 WASHER, 3/8 EXT TOOTH LOCK 015682 BOLT, 3/8-16 X 7/8 DOG PT HEX HD CAP 015683 FSTN, NUT HEX JAM 3/8-16 015684...
  • Page 90 SECTION 4 4.13 Illustration PARTS RH Standard Duty Gearbox Torque to 22 Ft. Lbs. Grease this area for re-assembly only. 4-26 053423; 12/10...
  • Page 91 RH Standard Duty Gearbox PARTS ITEM PART # DESCRIPTION GREASE, MOBILITH SCH 220 001003 .094 OIL, ALLEN ENGINEERING GEARBOX 048299 .757/LT PLUG, 3/8 NPT BI SQ HD PIPE 010498 FITTING, 1/4-28 NPT STR GREASE 010513 PLUG, 3/4 NPTF BI SQ HD PIPE...
  • Page 92 SECTION 4 4.14 Illustration PARTS LH Standard Duty Gearbox Torque to 22 Ft. Lbs. Grease this area for re-assembly only. 4-28 053423; 12/10...
  • Page 93 LH Standard Duty Gearbox PARTS ITEM PART # DESCRIPTION GREASE, MOBILITH SCH220 001003 .094 OIL, ALLEN ENGINEERING GEARBOX 048299 .757/LT PLUG, 3/8 NPT BI SQ HD PIPE 010498 FITTING, 1/4-28 NPT STR GREASE 010513 PLUG, 3/4 NPTF BI SQ HD PIPE...
  • Page 94 SECTION 4 4.15 Illustration Accessory - Pro Dolly Jack System PARTS 4-30 053423; 12/10...
  • Page 95 4.15 Parts List SECTION 4 Accessory - Pro Dolly Jack System PARTS ITEM PART # DESCRIPTION SET, PRO DOLLY JACK 027684 017751 WASHER, 3/8 FLAT PIN, 3/16 X 2 COTTER 010133 CAP, 1/4 RED GREASE 015692 NUT, 3/8-16 NYLOCK LOCK 010464 SPACER, DOLLY JACK WHEEL 024628...
  • Page 96 SECTION 4 4.16 Illustration Accessory - Non-standard Items PARTS 4-32 053423; 12/10...
  • Page 97 4.16 Parts List SECTION 4 Accessory - Non-standard Items PARTS ITEM PART # DESCRIPTION PAN, 10GA 46.5” 4-BLADE SAFETY UNV 051551 PAN, 10GA 46.5” 4-BLADE Z-CLIP UNV 051550 COMPODISK, 46-1/8” OD X 3/4” (4) 045900 BRIDLE, 2500 LB 5 FT SLING LIFT 035461 053423;...
  • Page 98 SECTION 4 4.17 Illustration Tools - Service PARTS 4-34 053423; 12/10...
  • Page 99 4.17 Parts List SECTION 4 Tools - Service PARTS ITEM PART # DESCRIPTION JIG, TROWEL ARM ALIGNMENT 016863 KIT, STD 4-ARM SPIDER PULLER 035688 053423; 12/10 4-35...
  • Page 100 4.18 Gearbox Seal Kit SECTION 4 PARTS ITEM PART NO. DESCRIPTION KIT, GEARBOX OIL SEAL FOR 026442 & 026443 066979 SEAL, OIL CR# 7455V (p) 015670 SEAL, OIL CR# 133661 (p) 015671 O-RING, 15/16 X 1 - 3/16 X 1/8 BUNA 015673 O-RING, GEAR BOX END CAPS (p) 015660...
  • Page 101 Notes SECTION 4 PARTS 053423; 12/10 4-37...
  • Page 102 INTENTIONALLY BLANK 053423; 12/10...
  • Page 103 P.O. BOX 819 PARAGOULD, AR 72451 USA 800.643.0095 (USA ONLY) / 870.236.7751 FAX: 800.643.0097 (USA ONLY) / 870.236.3934 WWW.ALLENENG.COM CONNECT WITH US ON...
