STC Clear View Assembly Instructions Manual page 15

Slide connectors S09 and S10 half way into pro les G02A and G02B.
1.11B
Continue sliding together making sure rst
row of ribbed edges on panels GY7,
GY8, GY16 and GY17 t securely
into V-channels of pro les G02I
and G02J. Connectors click
securely into pro les.
Connectors S09 and S10 CLICK into place.
!
There is only one way to properly fasten connectors into pro les. Line up parts
rst to ensure correct placement. Slide connectors until they CLICK securely into
pro le. Use WD40 or liquid soap if pieces do not easily slide together. Wear gloves.
1.12A
Place connectors S11 onto pro les G02I
and G03C, G02J and G03L and G02J and
G03D matching up all holes.
S11
1.12B
Screw S02 screws partially into
bottom two holes. Do not tighten.
NOTE: ALL VIEWS ARE FROM INSIDE.
www.stcny.com
S09
S09
G02B
1.12C
S02
S02
GY17
GY16
GY7
Screw S02 screws into top two holes.
Tighten all screws. Repeat for both sides.
S02
13 of 56
S10
GY8
S10
G02A
S02
Connector
#S02
#S11
QTY
12
3
