STC Clear View Assembly Instructions Manual page 14

Remove protective plastic from both sides of panels GY7, GY8, GY16 and
1.10C
GY17. The clear panels are designed with window shapes that curve
outward. Place the outward curved side facing down.
Slide panels into V-channels on pro les G02A, G02B, G03C, G03D and G03L. Fit
inside V-channels on pro les G05H. The rst row of ribbed edges t securely into
the V-channels.
GY17
GY16
GY7
NOTE: ALL VIEWS ARE FROM INSIDE.
1.11A
Slide pro les G02I and G02J into connectors
S09, S10 and S12 until they click into place.
G02I
IMPORTANT: The holes are not at the midpoint
of the pro les. Arrange pro le so the 24.5"
portion will be the bottom when standing.
!
There is only one way to properly fasten connectors into pro les. Line up parts
rst to ensure correct placement. Slide connectors until they CLICK securely into
pro le. Use WD40 or liquid soap if pieces do not easily slide together. Wear gloves.
Pro le
#G02I
#G02J
www.stcny.com
!
Remove protective plastic from EACH side of clear
panels before installing. Dispose of plastic properly.
Install with outward curved side FACING DOWN.
1.10D Slide hex nut S14 and hex bolts S13
into U-cutout in sides of pro les
G03C, G03D, G03L and G03K.
Tighten securely to hold in place.
GY8
NOTE: The top set of G05H pro les have
nuts and bolts only next to pro le G03L.
24.5"
(623 mm)
Connector
QTY
1
1
Clear Panel
Connectors S09, S10 and S12 CLICK into place.
24.5"
(623 mm)
Connector
QTY
#S09 1
12 of 56
G03L
G05H
G03L
G03C
G05H
Clear Panel
QTY
#GY7 1
#GY8 1
G02I
G02J
Connector
QTY
#S10 1
G05H
G03D
G05H
QTY
#GY16 1
#GY17 1
G02J
QTY
#S12 1
