STC Clear View Assembly Instructions Manual page 12

1.7
Remove protective plastic from both sides of panels
GY2 . The clear panels are designed with
window shapes that curve outward.
Place the outward curved side
facing down. The rst row of
ribbed edges t securely into
V-channels of pro les G02A,
G02B, G03C, G03D, G17C
and G17D.
!
Remove protective plastic from EACH side of clear
panels before installing. Dispose of plastic properly.
Install with outward curved side FACING DOWN.
1.8A
Carefully line up connector S04 with pro le G02B and
connector S05 with pro le G02A. Slide pro les G01I and G01J half way into place. Continue
sliding until connectors S04 and S05 click securely into pro les.
G02B
G03C
S04
G01I
www.stcny.com
G02B
!
There is only one way to properly fasten connectors into pro les. Line up parts
rst to ensure correct placement. Slide connectors until they CLICK securely into
pro le. Use WD40 or liquid soap if pieces do not easily slide together. Wear gloves.
G03L
G03K
G03D
GY2
G01J
G03L
G03C
G03K
G03D
GY2
NOTE: ALL VIEWS ARE FROM INSIDE.
Connectors S04 and S05 CLICK into place.
1.7B
Line up holes on connectors S08 with holes in
pro les G01I and G01J. Secure each connector
with two S02 screws.
G02A
S05
10 of 56
G17D
G02A
Clear Panel
#GY2
GY2
G01I
S02
Screw
QTY
2
S08
QTY
#S02 6
