STC Clear View Assembly Instructions Manual page 13

1.9A
Slide hex bolt S13 into channels of four G05H pro les as shown.
S13
G05H
NOTE: Insert two sets of nuts and bolts into two G05H pro les.
The other two G05H pro les have one set of nuts and bolts.
1.10A Remove protective plastic from both sides of panels GY20 and GY21. The clear panels are
designed with window shapes that curve outward. Place the outward curved side facing down.
Line up GY20 and GY21 panels between pro les
G05H as shown. The rst row of ribbed edges t
securely into the V-channels.
G05H
G05H
G05H
GY20
G05H
G05H
GY21
www.stcny.com
1.9B
G05H
1.10B
G05H
GY20
GY21
NOTE: ALL VIEWS ARE FROM INSIDE.
Screw hex nut S14 onto bolt. Do not
completely tighten.
G05H
G05H
Pro le
!
Remove protective plastic from EACH side of clear
panels before installing. Dispose of plastic properly.
Install with outward curved side FACING DOWN.
Slide panels with pro les G05H into V-channels of
pro les G02A, G02B, G03C,
G03D, G03L and G03K.
G02B
Clear Panel
11 of 56
S14
Bolt/Nut
QTY
#L05H 4
G05H
G05H
GY20
GY20
G05H
G05H
GY21
GY21
G03C
G03L
Clear Panel
QTY
#GY20 2
QTY
#S13 6
#S14 6
G03D
G02A
QTY
#GY21 2
