Legend
No Buttons
OFF
ON
MENU
RIGHT
ENTER
TV/VCR
DOWN
PAUSE
Button press indicator LEDs
The following buttons cannot be programmed in VCR mode. The DVCM
must be in DVD mode to program them.
Title
Menu
Enter
Right (Tuner)
Left (Tuner)
The TV/VCR button cannot be programmed in DVD mode. It can be
programmed only in VCR mode.
If you press a button that does not function in the current mode, the button's
orange indicator LED(s) blink three times, indicating that the button cannot be
programmed.
• The IR learning LED that indicates the button memory block currently
available for programming begins to blink. (See IR learning indicators in the
chapter 2 of the DVCM 50 User's Manual for further information.) The LEDs
located below the blinking LED light steadily, indicating that they already
contain commands.
