  • Page 1 Operating Instructions Adjustment Item Menu Guide: TCRU/ORU For safe and correct use, be sure to read Safety Information before using the machine.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction................................. 8 How to Read This Manual..........................9 Symbols................................9 Disclaimer................................9 Notes................................9 Manuals for This Machine..........................10 Paper Feed Direction of Printed Copies (Side 1/Side 2)................11 1. Adjustment Settings for Operators Accessing Adjustment Settings for Operators....................13 Layout of Adjustment Settings for Operators....................14 Features of the Displayed Items and Setting Operations................15 Notes on How Adjustment Settings Are Applied to Printed Copies.............18 2.
  • Page 4 0306 [Detect J097/098]...........................34 0307 [Control J097/098].........................34 0308 [Detect JAM048]..........................35 [Machine: Productivity]............................36 0401 [No. of Sheets for Auto Color Selection]..................36 0402 [Print Mode When Switching Paper Type]..................36 0403 [Paper Feed Interrupt Setting]......................36 [Machine: Maintenance]..........................38 0501 [Execute Cleaning Initial Setting for PCU]..................38 0502 [Wind Fuser Cleaning Unit at Replacement]..................
  • Page 5 0609 [Punch Skew Correction]........................58 0610 [Amount of Punch Skew Correction]....................59 0611 [Paper Alignment in Shift Tray Setting]....................59 0612 [Paper Alignment in Shift Tray: Across Feed]..................60 0613 [Output Tray Descending Position]....................60 0614 [Exit Guide Close Timing].........................61 0615 [Output Trail Edge Press Setting]..................... 61 0616 [Output Fan Setting]..........................61 0617 [Output Fan Level]..........................62 0618 [Staple Position for Booklet]......................62...
  • Page 6 0645 [Paper Alignment in Shift Tray: Across Feed]..................82 0646 [Paper Alignment for Stapling: With Feed: 1st Time]..............83 0647 [Paper Alignment for Stapling: With Feed: 2nd Time]..............84 0648 [Paper Alignment for Stapling:Paper Weight:With Feed:1st]............85 0649 [Paper Alignment for Stapling:Paper Weight:With Feed:2nd]............. 86 0650 [Punch Skew Correction]........................87 0651 [Z-fold Skew Correction]........................87 0652 [Amount of Z-fold Skew Correction]....................
  • Page 7 0705 [Letter Fold-out Position 1: 1 sheet Fold]..................102 0706 [Letter Fold-out Position 1: Multi-sheet Fold]................102 0707 [Letter Fold-out Position 2: 1 sheet Fold]..................103 0708 [Letter Fold-out Position 2: Multi-sheet Fold]................104 0709 [Letter Fold-in Position 1: 1 sheet Fold]..................104 0710 [Letter Fold-in Position 1: Multi-sheet Fold]..................
  • Page 8 2103 [Interposer Fan Level]........................125 3. Custom Paper Settings for Administrators Accessing Advanced Settings........................127 Description of Paper Icons..........................128 Deleting Saved Custom Paper Profiles......................129 Backing up and Restoring Custom Paper Profiles..................130 Backing up Custom Paper Profiles Registered Under the [CustomPaper Management] Setting..130 Backing up and Restoring Custom Paper Profiles Using the External Controller's Control Panel..131 Paper Presets in "Advanced Settings"......................
  • Page 9 1250 [Print Mode When Switching Paper Type]...................147 [Machine: Paper Feed/ Output]........................148 1301 [Main/2-Tray LCIT: Paper Feed Mode]..................148 1302 [Main/2-Tray LCIT: Fan/Shutter]....................148 1303 [Main/2-Tray LCIT: Other Setting]....................151 1311 [Correct Paper Curl]........................151 1321 [Jam Detection]..........................152 1331 [Motor Speed]..........................153 1341 [Adjust Paper Curl (Fusing)]......................154...

  • Page 10: Introduction

    Introduction This manual contains detailed instructions and notes on the operation and use of this machine. For your safety and benefit, read this manual carefully before using the machine. Keep this manual in a handy place for quick reference.

  • Page 11: How To Read This Manual

    How to Read This Manual Symbols This manual uses the following symbols: Indicates points to pay attention to when using functions. This symbol indicates points that may result in the product or service becoming unusable or result in the loss of data if the instructions are not obeyed. Be sure to read these explanations.

  • Page 12: Manuals For This Machine

    Manuals for This Machine The following manuals are for skilled operators only. Adjustment Item Menu Guide This manual explains the items in [Adjustment Settings for Operators] and the advanced settings for custom paper adjustment in "Advanced Settings". Replacement Guide This manual explains how to replace the machine's components. Troubleshooting This manual explains how to troubleshoot problems related to image quality, paper delivery, and other aspects of machine operation.

  • Page 13: Paper Feed Direction Of Printed Copies (Side 1/Side 2)

    Paper Feed Direction of Printed Copies (Side 1/Side 2) Depending on the setting, printed copies are fed as follows: Side 1 is the surface of the paper printed during one-sided printing, or the surface of the first print during duplex printing. Side 2 is the surface of the paper printed on the back side of Side 1 during duplex printing.
  • Page 14 Single-sided printing: Printed side face up DFP408 A. Side 1 B. Paper feed direction of Side 1 Duplex printing: Printed side face up DFP409 A. Side 1 B. Paper feed direction of Side 1 C. Side 2 D. Paper feed direction of Side 2...

  • Page 15: Adjustment Settings For Operators

    1. Adjustment Settings for Operators Accessing Adjustment Settings for Operators Press "Login/Logout" ( ) on the top right of the screen. The name that appears lower the "Login/Logout" icon ( ) depends on the type of administrator logging in. Enter your login user name and password, and then press [Login]. If you are logging on as the administrator for the first time, enter "admin"...

  • Page 16: Layout Of Adjustment Settings For Operators

    1. Adjustment Settings for Operators Layout of Adjustment Settings for Operators This section explains how to use Adjustment Settings for Operators. To Print Screen DWQ560 1. [ ] Press this key to collapse the hierarchical display of the adjustment items, and display only the group names of those items.

  • Page 17: Features Of The Displayed Items And Setting Operations

    Features of the Displayed Items and Setting Operations Features of the Displayed Items and Setting Operations The following operations are available for each adjustment item: • Value setting • Item setting • Executing • Display only Value setting Press [+] or [-] to increase or decrease the value respectively, or use the numeric keypad to enter the value.
  • Page 18 1. Adjustment Settings for Operators • [ ]: Press to delete the entered value character by character. • [Clear]: Clear the entered value. • [ / ]: Change the sign of the entered value from (positive) to (negative) and vice versa. •...
  • Page 19 Features of the Displayed Items and Setting Operations Display only You can check the setting of the selected item.

  • Page 20: Notes On How Adjustment Settings Are Applied To Printed Copies

    1. Adjustment Settings for Operators Notes on How Adjustment Settings Are Applied to Printed Copies The adjustment settings are applied to printed copies according to the settings specified for each paper tray and paper weight. Depending on the adjustment setting, the same settings specified under different categories may be applied to printed copies concurrently.
  • Page 21 Notes on How Adjustment Settings Are Applied to Printed Copies • For information about the paper tray and tray paper size settings that can be specified for a particular function, see the manual for the relevant function. • In "Advanced Settings" for custom paper, there are settings identical to those in Adjustment Settings for Operators.
  • Page 22 1. Adjustment Settings for Operators Values Operation (with e Adjustment Settings for Adjustment Settings for ach sheet counted as A4) Custom Paper Settings Operators [Automatic Execution] [1:Normal] The fusing belt is cleaned for 60 seconds every 2000 sheets. [2:Frequently] The fusing belt is cleaned for 60 seconds every 667 sheets.
  • Page 23 Notes on How Adjustment Settings Are Applied to Printed Copies Values Operation (with e Adjustment Settings for Adjustment Settings for ach sheet counted as A4) Custom Paper Settings Operators [Automatic [1:Normal] The fusing belt is cleaned for 30 seconds Execution:Set by User] every 500 sheets and for 150 seconds every 2000 sheets.
  • Page 24 1. Adjustment Settings for Operators...

  • Page 25: Details Of Menu Items In Adjustment Settings For Operators

    2. Details of Menu Items in Adjustment Settings for Operators [Machine: Image Position] 0101 [Image Position: With Feed: Side 1]/0102 [Image Position: With Feed: Side 2] Adjust the horizontal position of the image to print on Side 1/2 of the paper. •...

  • Page 26: 0103 [Image Position: Across Feed: Side 1]/0104 [Image Position: Across Feed: Side 2]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [Tray 1] 0.00 3.00 -3.00 0.01 [Tray 2] [2-Tray LCIT: Tray 3] [2-Tray LCIT: Tray 4] [2-Tray LCIT: Tray 5] [2-Tray LCIT: Tray 6] [2-Tray LCIT: Tray 7] [2-Tray LCIT: Tray 8]...
  • Page 27 [Machine: Image Position] Default Max. Min. Setting Items Step Unit Value Value Value [Tray 1] 0.00 3.00 -3.00 0.01 [Tray 2] [2-Tray LCIT: Tray 4] [2-Tray LCIT: Tray 5] [2-Tray LCIT: Tray 6] [2-Tray LCIT: Tray 7] [2-Tray LCIT: Tray 8] [Bypass Tray] [Extended Option Tray] 0105 [Image Magnification: With Feed: Side 1]/0106 [Image Magnification:...

  • Page 28: 0107 [Image Magnification: Across Feed: Side 1]/0108 [Image Magnification: Across Feed: Side 2]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [Tray 1] 0.000 0.500 -0.500 0.025 [Tray 2] [2-Tray LCIT: Tray 3] [2-Tray LCIT: Tray 4] [2-Tray LCIT: Tray 5] [2-Tray LCIT: Tray 6] [2-Tray LCIT: Tray 7] [2-Tray LCIT: Tray 8]...

  • Page 29: 0109 [Perpendicularity Adjustment]

    [Machine: Image Position] Default Max. Min. Setting Items Step Unit Value Value Value [Tray 1] 0.000 0.500 -0.500 0.001 [Tray 2] [2-Tray LCIT: Tray 3] [2-Tray LCIT: Tray 4] [2-Tray LCIT: Tray 5] [2-Tray LCIT: Tray 6] [2-Tray LCIT: Tray 7] [2-Tray LCIT: Tray 8] [Bypass Tray] [Extended Option Tray]...

  • Page 30: 0111 [Auto Adjust Image Position: No. Of Printed Sheets]

    2. Details of Menu Items in Adjustment Settings for Operators Setting Items Values Default Value [Tray 1] [Normal] [Normal] [High Accuracy] [Tray 2] [2-Tray LCIT: Tray 4] [2-Tray LCIT: Tray 5] [2-Tray LCIT: Tray 6] [2-Tray LCIT: Tray 7] [2-Tray LCIT: Tray 8] [Bypass Tray] [Extended Option Tray] 0111 [Auto Adjust Image Position: No.
  • Page 31 [Machine: Image Position] Default Max. Min. Setting Items Step Unit Value Value Value [Upper Limit] 0.40 0.50 0.00 0.05 [Lower Limit] -0.50 0.00 -0.50 0.05...

  • Page 32: [Machine: Image Quality]

    2. Details of Menu Items in Adjustment Settings for Operators [Machine: Image Quality] 0201 [Execute Image Quality Adjustment] Execute the following adjustment manually: image density /reduce density diff. in across direction / reduce density diff. in feeding direction / reduce color dispersion. Setting Items Remarks [Adjust All]...

  • Page 33: 0204 [Fusing Temperature On Standby]

    [Machine: Image Quality] Default Max. Min. Setting Items Step Unit Value Value Value [Black] None [Cyan] [Magenta] [Yellow] 0204 [Fusing Temperature on Standby] Adjust the fusing conditions in the standby status. Default Max. Min. Setting Items Step Unit Value Value Value [Heat Rlr: On Standby] [Press Rlr: On Panel Off]...

  • Page 34: [Machine: Paper Feed/ Output]

    2. Details of Menu Items in Adjustment Settings for Operators [Machine: Paper Feed/ Output] 0301 [Correct Output Paper Curl: 1 Sided: Face Up]/0302 [Correct Output Paper Curl: 1 Sided: Face Down]/0303 [Correct Output Paper Curl: 2 Sided] Select the paper curl correction mode and correction amount. Setting Items Values Default Value...

  • Page 35: 0305 [Detect Jam080]

    [Machine: Paper Feed/ Output] Setting Items Values Default Value [Tray 1] [Off] [On] [On] [Tray 2] [2-Tray LCIT: Tray 3] [2-Tray LCIT: Tray 4] [2-Tray LCIT: Tray 5] [2-Tray LCIT: Tray 6] [2-Tray LCIT: Tray 7] [2-Tray LCIT: Tray 8] [Bypass Tray] [Extended Option Tray] 0305 [Detect JAM080]...

  • Page 36: 0306 [Detect J097/098]

    2. Details of Menu Items in Adjustment Settings for Operators 0306 [Detect J097/098] Set ON/OFF for the function to make paper jam deliberately when skew or perpendicularity-error is detected. Setting Items Values Default Value [Tray 1] [Off] [On] [On] [Tray 2] [2-Tray LCIT: Tray 3] [2-Tray LCIT: Tray 4] [2-Tray LCIT: Tray 5]...

  • Page 37: 0308 [Detect Jam048]

    [Machine: Paper Feed/ Output] Setting Items Values Default Value [Tray 1] [Off] [On] [On] [Tray 2] [2-Tray LCIT: Tray 3] [2-Tray LCIT: Tray 4] [2-Tray LCIT: Tray 5] [2-Tray LCIT: Tray 6] [2-Tray LCIT: Tray 7] [2-Tray LCIT: Tray 8] [Bypass Tray] [Extended Option Tray] 0308 [Detect JAM048]...

  • Page 38: [Machine: Productivity]

    2. Details of Menu Items in Adjustment Settings for Operators [Machine: Productivity] 0401 [No. of Sheets for Auto Color Selection] Specify the number of sheets the machine prints in full color mode before switching to black-and-white mode when printing a job which involves full color printing followed by black-and-white printing. When the machine prints a job which involves full color printing followed by black-and-white printing, you can specify whether to perform the black-and-white printing in full color mode, or whether to switch to black-and-white mode after printing a specified number of black-and-white sheets in full color mode.
  • Page 39 [Machine: Productivity] Default Max. Min. Setting Item Step Unit Value Value Value [Maximum Wait Time] 300.0...

  • Page 40: [Machine: Maintenance]

    2. Details of Menu Items in Adjustment Settings for Operators [Machine: Maintenance] 0501 [Execute Cleaning Initial Setting for PCU] Execute after replacement of photoconductor cleaning unit and drum. Do not open the left and right front covers during the operation. The control panel shows information during the operation. •...
  • Page 41 [Machine: Maintenance] Setting Items Remarks [PCU Cleaning Unit (K)] Press [Execute]. [Charger Unit (K)] [Photoconductor Unit (K)] [PCU Cleaning Unit (C)] [Charger Unit (C)] [Photoconductor Unit (C)] [PCU Cleaning Unit (M)] [Charger Unit (M)] [Photoconductor Unit (M)] [PCU Cleaning Unit (Y)] [Charger Unit (Y)] [Photoconductor Unit (Y)] [ITB Cleaning Unit]...

  • Page 42: 0504 [Display Parts Life Counter]

    2. Details of Menu Items in Adjustment Settings for Operators Setting Items Remarks [Dust Filter (K)] Press [Execute]. [Dust Filter (C)] [Dust Filter (M)] [Dust Filter (Y)] [Ozone Filter] [Tray 1: Feed Belt] [Tray 2: Feed Belt] [Bypass Tray] [Interposer Upper Tray] [Interposer Lower Tray] [2-Tray LCIT:Tray3:Fd Blt] [2-Tray LCIT:Tray4:Fd Blt]...
  • Page 43 [Machine: Maintenance] Setting Items Remarks [PCU Cleaning Unit (K)] Value display only. [Charger Unit (K)] [Photoconductor Unit (K)] [PCU Cleaning Unit (C)] [Charger Unit (C)] [Photoconductor Unit (C)] [PCU Cleaning Unit (M)] [Charger Unit (M)] [Photoconductor Unit (M)] [PCU Cleaning Unit (Y)] [Charger Unit (Y)] [Photoconductor Unit (Y)] [ITB Cleaning Unit]...

  • Page 44: 0505 [Temperature / Humidity Inside]

    2. Details of Menu Items in Adjustment Settings for Operators Setting Items Remarks [Dust Filter (K)] Value display only. [Dust Filter (C)] [Dust Filter (M)] [Dust Filter (Y)] [Ozone Filter] [Tray 1: Feed Belt] [Tray 2: Feed Belt] [Bypass Tray] [Intpsr.

  • Page 45: 0506 [Temperature / Humidity Outside]

    [Machine: Maintenance] 0506 [Temperature / Humidity Outside] Display temperature and humidity around the machine. Setting Items Remarks [Temperature] Value display only. [Humidity] 0507 [Screw-on Cap to Replace] The Toner Bottle Cap closes. The Toner Bottle in use can be pulled out when the Cap is closed. Use it when you want to replace the Toner Bottle.

  • Page 46: 0509 [Execute Photoconductor Refreshing]

    2. Details of Menu Items in Adjustment Settings for Operators Setting Items Remarks [All Colors] Press [Execute]. [Black] 0509 [Execute Photoconductor Refreshing] Remove the dirt on the Drum surface. It takes about 4 minutes. Do not open the Front Cover during the operation.

  • Page 47: 0512 [Fusing Belt Smoothing Setting]

    [Machine: Maintenance] 0512 [Fusing Belt Smoothing Setting] Set the conditions for Fusing Belt smoothing. Setting Items Values Default Value [Auto Exe: Belt Scratches] [Off] [Automatic Execution] [Automatic Execution] [Most Frequently] [Automatic Execution: Set by User] [Feed Speed] [High] [Low 3] [Middle] [Low 1] [Low 2]...

  • Page 48: 0515 [Fusing Belt Smoothing Setting (Set By User)]

    2. Details of Menu Items in Adjustment Settings for Operators 0515 [Fusing Belt Smoothing Setting (Set by User)] Set interval and duration when [Auto Execute: Set by User] is selected at [Auto Exe: Belt Scratches] in [Fusing Belt Smoothing Setting] for Custom Paper. Default Max.
  • Page 49 [Machine: Maintenance] Setting Items Remarks [Curt:Dist:Fuser Unit] Counter display only. [Curt:Dist:Fusing Belt] [Curt:Dist:Fusing Rllr] [Curt:Dist:Press Rllr] [Curt:Dist:Thermistor] [Curt:Dist:Separation Pad] [Curt:Dist:Fusing Heater] [Curt:Dist:Gear Set] [Curt:Page:Fuser Unit] [Curt:Page:Fusing Belt] [Curt:Page:Fusing Rllr] [Curt:Page:Press Rllr] [Curt:Page:Thermistor] [Curt:Page:Separation Pad] [Curt:Page:Fusing Heater] [Curt:Page:Gear Set] [Curt:Paper Feed :Clng Web] [Curt:Rot:Clng Web] [Curt:Smooting Time]...
  • Page 50 2. Details of Menu Items in Adjustment Settings for Operators Setting Items Remarks [Unit1:Save:Dist:Fuser Unit] Counter display only. [Unit1:Save:Dist:Fusing Belt] [Unit1:Save:Dist:Fusing Rllr] [Unit1:Save:Dist:Press Rllr] [Unit1:Save:Dist:Thermistor] [Unit1:Save:Dist:Separ Pad] [Unit1:Save:Dist:Fusing Htr] [Unit1:Save:Dist:Gear Set] [Unit1:Save:Page:Fuser Unit] [Unit1:Save:Page:Fusing Belt] [Unit1:Save:Page:Fusing Rllr] [Unit1:Save:Page:Press Rllr] [Unit1:Save:Page:Therm] [Unit1:Save:Page:Separ Pad] [Unit1:Save:Page:Fusing Htr] [Unit1:Save:Page:Gear Set]...
  • Page 51 [Machine: Maintenance] Setting Items Remarks [Unit2:Save:Dist:Fusing Belt] Counter display only. [Unit2:Save:Dist:Fusing Rllr] [Unit2:Save:Dist:Press Rllr] [Unit2:Save:Dist:Therm] [Unit2:Save:Dist:Separ Pad] [Unit2:Save:Dist:Fusing Htr] [Unit2:Save:Dist:Gear Set] [Unit2:Save:Page:Fuser Unit] [Unit2:Save:Page:Fusing Belt] [Unit2:Save:Page:Fusing Rllr] [Unit2:Save:Page:Press Rllr] [Unit2:Save:Page:Therm] [Unit2:Save:Page:Separ Pad] [Unit2:Save:Page:Fusing Htr] [Unit2:Save:Page:Gear Set] [Unit2:Save:Feed:Clng Web] [Unit2:Save:Rot:Clng Web] [Unit2:Save:Smoothing Time] [Unit3:Save:Dist:Fuser Unit] [Unit3:Save:Dist:Fusing Belt]...
  • Page 52 2. Details of Menu Items in Adjustment Settings for Operators Setting Items Remarks [Unit3:Save:Dist:Press Rllr] Counter display only. [Unit3:Save:Dist:Therm] [Unit3:Save:Dist:Separ Pad] [Unit3:Save:Dist:Fusing Htr] [Unit3:Save:Dist:Gear Set] [Unit3:Save:Page:Fuser Unit] [Unit3:Save:Page:Fusing Belt] [Unit3:Save:Page:Fusing Rllr] [Unit3:Save:Page:Press Rllr] [Unit3:Save:Page:Therm] [Unit3:Save:Page:Separ Pad] [Unit3:Save:Page:Fusing Htr] [Unit3:Save:Page:Gear Set] [Unit3:Save:Feed:Clng Web] [Unit3:Save:Rot:Clng Web] [Unit3:Save:Smoothing Time]...
  • Page 53 [Machine: Maintenance] Setting Items Remarks [Unit4:Save:Dist:Therm] Counter display only. [Unit4:Save:Dist:Separ Pad] [Unit4:Save:Dist:Fusing Htr] [Unit4:Save:Dist:Gear Set] [Unit4:Save:Page:Fuser Unit] [Unit4:Save:Page:Fusing Belt] [Unit4:Save:Page:Fusing Rllr] [Unit4:Save:Page:Press Rllr] [Unit4:Save:Page:Therm] [Unit4:Save:Page:Separ Pad] [Unit4:Save:Page:Fusing Htr] [Unit4:Save:Page:Gear Set] [Unit4:Save:Feed:Clng Web] [Unit4:Save:Rot:Clng Web] [Unit4:Save:Smoothing Time]...

  • Page 54: [Finishing: Finisher]

    2. Details of Menu Items in Adjustment Settings for Operators [Finishing: Finisher] 0601 [Staple Position: Across Feed 1] Adjust the position of the staple in the vertical direction at the time of Edge Stapling. Use [+] or [-] to expand or reduce the distance to the paper side end. Default Max.

  • Page 55: 0602 [Staple Position: Across Feed 2]

    [Finishing: Finisher] 0602 [Staple Position: Across Feed 2] Adjust the space of the two staples in the vertical direction. Use [+] or [-] to expand or shrink the space. Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] [B4 JIS SEF] [A4 LEF] [A4 SEF]...

  • Page 56: 0604 [Paper Alignment For Stapling: Across Feed]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [11 × 17 SEF] × 14 SEF] ×...

  • Page 57: 0605 [Paper Alignment For Stapling: With Feed]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [11 × 17 SEF] × 14 SEF] × 11 LEF] × 11 SEF] [8K SEF] [16K LEF] [16K SEF]...

  • Page 58: 0606 [Number Of Sheets Align For Stapling]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -2.5 [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [11 × 17 SEF] ×...

  • Page 59: 0607 [Punch Position: Across Feed]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] sheet(s) [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [11 × 17 SEF] × 14 SEF] × 11 LEF] × 11 SEF] [8K SEF] [16K LEF] [16K SEF]...

  • Page 60: 0608 [Punch Position: With Feed]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [2 Holes JP/ EU] -2.0 [3 Holes US] [4 Holes EU] [4 Holes NE] [2 Holes US] 0608 [Punch Position: With Feed] Adjust the position (left and right) of the punch holes in the feeding direction.

  • Page 61: 0610 [Amount Of Punch Skew Correction]

    [Finishing: Finisher] Setting Item Values Default Value [Setting] [Off] [On] [On] 0610 [Amount of Punch Skew Correction] Adjust the punch skew level. It reduces the punch skew due to paper size, thickness and curl. Set [+] to increase the correction amount. Default Max.

  • Page 62: 0612 [Paper Alignment In Shift Tray: Across Feed]

    2. Details of Menu Items in Adjustment Settings for Operators 0612 [Paper Alignment in Shift Tray: Across Feed] Adjust the width of Paper Alignment Jogger on Shift Tray. It reduces diversion of paper in vertical direction due to paper size, thickness and curl. Use [+] or [-] to expand or reduce the width. Default Max.

  • Page 63: 0614 [Exit Guide Close Timing]

    [Finishing: Finisher] Setting Item Selection Default Value [Setting] [Paper Weight 1] [Paper Weight 1] [Paper Weight 2] [Paper Weight 3-8] 0614 [Exit Guide Close Timing] Set the timing to close the Paper Exit Guide. The proper timing for the paper in use prevents the deflection of the staple bundle at the time of ejection.

  • Page 64: 0617 [Output Fan Level]

    2. Details of Menu Items in Adjustment Settings for Operators 0617 [Output Fan Level] Adjust the fan volume to the sheets on the shift tray. Increase the air level if the sheets are in close contact. Setting Item Selection Default Value [Level] [Standard] [Standard]...

  • Page 65: 0619 [Folding Position For Booklet]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [SRA3 SEF] [SRA4 SEF] [13 ×19 SEF] [13 × 19 SEF] [13 × 18 SEF] × 19 SEF] ×...

  • Page 66: 0620 [Paper Alignment For Booklet: Across Feed]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [SRA3 SEF] [SRA4 SEF] [13 × 19 SEF] [13 × 19 SEF] [13 ×...

  • Page 67: 0621 [Set Number Of Folds For Booklet]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -0.5 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [SRA3 SEF] [SRA4 SEF] [13 × 19 SEF] [13 × 19 SEF] [13 × 18 SEF] × 19 SEF] ×...

  • Page 68: 0622 [Paper Alignment For Booklet: With Feed]

    2. Details of Menu Items in Adjustment Settings for Operators 0622 [Paper Alignment for Booklet: With Feed] Adjust movement range of Tip Stopper. It reduces dispersion of paper in horizontal orientation due to paper size, thickness, curl and so on. Use [+] or [-] to expand or reduce the width. Default Max.

  • Page 69: 0623 [Z-Fold Skew Correction]

    [Finishing: Finisher] 0623 [Z-fold Skew Correction] Select way to correct skew during Z-folding. [On] corrects by striking. [On: Reverse] corrects by both striking and reverse rotation of Regist. Roller. Setting Item Values Default Value [Setting] [Off] [On: Reverse] [On] [On: Reverse] 0624 [Amount of Z-fold Skew Correction] Adjust striking amount of paper during Z-folding skew correction.

  • Page 70: 0626 [Maximum No. Stacked Sheets In Output Tray]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Item Step Unit Value Value Value [Setting] -3.0 0626 [Maximum No. Stacked Sheets in Output Tray] Set the number of sheets to stack on the shift tray at the time of shift sorting. To avoid paper jams, set the number proper to each paper size.

  • Page 71: 0631 [Folding Position For Booklet]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [SRA3 SEF] [SRA4 SEF] [310 × 432 mm SEF] [226 × 310 mm SEF] [13 × 19 SEF] [13 ×...
  • Page 72 2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [SRA3 SEF] [SRA4 SEF] [310 × 432 mm SEF] [226 ×...

  • Page 73: 0632 [Staple Position: Across Feed 1]

    [Finishing: Finisher] 0632 [Staple Position: Across Feed 1] Adjust the position of the staple in the vertical direction at the time of Edge Stapling. Use [+] or [-] to expand or reduce the distance to the paper side end. This function can be used with Finisher SR5110 or Booklet Finisher SR5120. Default Max.

  • Page 74: 0634 [Staple Position: With Feed]

    2. Details of Menu Items in Adjustment Settings for Operators This function can be used with Finisher SR5110 or Booklet Finisher SR5120. Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] 115.0 -14.5 [B4 JIS SEF] 75.0 [A4 LEF] 115.0 [A4 SEF]...

  • Page 75: 0635 [Punch Position: Across Feed]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -2.0 [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [11 × 17 SEF] × 14 SEF] × 11 LEF] × 11 SEF] [8K SEF] [16K LEF] [16K SEF]...

  • Page 76: 0636 [Punch Position: With Feed]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [2 Holes JP/ EU] -2.0 [3 Holes US] [4 Holes EU] [4 Holes NE] [2 Holes US] 0636 [Punch Position: With Feed] Adjust the position of the punch holes in the feeding direction.

  • Page 77: 0637 [Paper Alignment For Booklet: Across Feed]

    [Finishing: Finisher] 0637 [Paper Alignment for Booklet: Across Feed] Adjust the width of the Staple Jogger to reduce dispersion of paper in vertical orientation for each paper size. Use [+] or [-] to expand or reduce the width. This function can be used with Booklet Finisher SR5120.

  • Page 78: 0638 [Set Number Of Folds For Booklet]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -0.5 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [SRA3 SEF] [SRA4 SEF] [310 × 432 mm SEF] [226 ×...

  • Page 79: 0639 [Feed Amount Of Folding Roller For Booklet]

    [Finishing: Finisher] When you select "0", the default value, the finisher folds the booklet according to the number of sheets in the booklet, as shown below. • 1–6 sheets: 1 time • 7–10 sheets: 2 times • 11–30 sheets: 6 times Default Max.
  • Page 80 2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -2.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [SRA3 SEF] [SRA4 SEF] [310 × 432 mm SEF] [226 ×...

  • Page 81: 0641 [Paper Alignment For Stapling: Across Feed: 1St Time]

    [Finishing: Finisher] 0641 [Paper Alignment for Stapling: Across Feed: 1st Time] Adjust the width of the Staple Jogger to reduce the dispersion of paper orientation in right angle for each paper size. Use [+] or [-] to expand or reduce the width. This function can be used with Finisher SR5110 or Booklet Finisher SR5120.

  • Page 82: 0643 [Paper Alignment For Stapling:paper Weight:across Feed:1St]

    2. Details of Menu Items in Adjustment Settings for Operators This function can be used with Finisher SR5110 or Booklet Finisher SR5120. Default Max. Min. Setting Items Step Unit Value Value Value A3 SEF -1.0 B4 JIS SEF A4 LEF A4 SEF B5 LEF B5 JIS SEF...

  • Page 83: 0644 [Paper Alignment For Stapling:paper Weight:across Feed:2Nd]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [Paper Weight 1] -1.0 [Paper Weight 2] [Paper Weight 3] [Paper Weight 4] [Paper Weight 5] [Paper Weight 6] [Paper Weight 7] [Paper Weight 8] 0644 [Paper Alignment for Stapling:Paper Weight:Across Feed:2nd] Adjust the width of the Staple Jogger to reduce the dispersion of paper orientation in right angle for each paper weight.

  • Page 84: 0645 [Paper Alignment In Shift Tray: Across Feed]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [Paper Weight 1] -1.0 [Paper Weight 2] [Paper Weight 3] [Paper Weight 4] [Paper Weight 5] [Paper Weight 6] [Paper Weight 7] [Paper Weight 8] 0645 [Paper Alignment in Shift Tray: Across Feed] Adjust the width of Paper Alignment Jogger on Shift Tray.It reduces diversion of paper in vertical...

  • Page 85: 0646 [Paper Alignment For Stapling: With Feed: 1St Time]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [A5 LEF] [A5 LEF] [11 × 17 SEF] × 14 SEF] × 11 LEF] ×...

  • Page 86: 0647 [Paper Alignment For Stapling: With Feed: 2Nd Time]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -2.5 [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [11 × 17 SEF] ×...

  • Page 87: 0648 [Paper Alignment For Stapling:paper Weight:with Feed:1St]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -2.5 [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [11 × 17 SEF] × 14 SEF] × 11 LEF] × 11 SEF] [8K SEF] [16K LEF] [16K SEF]...

  • Page 88: 0649 [Paper Alignment For Stapling:paper Weight:with Feed:2Nd]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [Paper Weight 1] -2.5 [Paper Weight 2] [Paper Weight 3] [Paper Weight 4] [Paper Weight 5] [Paper Weight 6] [Paper Weight 7] [Paper Weight 8] 0649 [Paper Alignment for Stapling:Paper Weight:With Feed:2nd] Adjust Tip Stopper movement when using Edge Stapling.

  • Page 89: 0650 [Punch Skew Correction]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [Paper Weight 1] -2.5 [Paper Weight 2] [Paper Weight 3] [Paper Weight 4] [Paper Weight 5] [Paper Weight 6] [Paper Weight 7] [Paper Weight 8] 0650 [Punch Skew Correction] Set the punch skew correction.

  • Page 90: 0652 [Amount Of Z-Fold Skew Correction]

    2. Details of Menu Items in Adjustment Settings for Operators Setting Item Values Default Value [Setting] [Off] [On: Reverse] [On] [On: Reverse] 0652 [Amount of Z-fold Skew Correction] Adjust the striking amount of paper during Z-folding skew correction. [-] reduces the striking amount. This function can be used with Finisher SR5110 or Booklet Finisher SR5120.

  • Page 91: 0654 [Amount Of Punch Skew Correction]

    [Finishing: Finisher] 0654 [Amount of Punch Skew Correction] Adjust the punch skew level. It reduces the punch skew due to paper size, thickness and curl. When the punch hole is skewed, set [+] to increase the correction amount. This function can be used with Finisher SR5110 or Booklet Finisher SR5120. Default Max.

  • Page 92: 0656 [Paper Alignment In Shift Tray Setting: Stapled Signature]

    2. Details of Menu Items in Adjustment Settings for Operators 0656 [Paper Alignment in Shift Tray Setting: Stapled Signature] Set the alignment precision of output sheets during Shift Sorting. Select [Accuracy Priority] to reduce the skew. This function can be used with Finisher SR5110 or Booklet Finisher SR5120. Setting Item Values Default Value...

  • Page 93: 0659 [Output Tray Descending Position]

    [Finishing: Finisher] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] None [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [11 × 17 SEF] × 14 SEF] × 11 LEF] × 11 SEF] [8K SEF] [16K LEF] [16K SEF]...

  • Page 94: 0660 [Output Trail Edge Press Setting]

    2. Details of Menu Items in Adjustment Settings for Operators 0660 [Output Trail Edge Press Setting] Set whether or not to hold the trailing edge of sheets when ejected on the Shift Tray. Setting it [ON] reduces the diversion of sheets due to the paper type and paper condition. This function can be used with Finisher SR5110 or Booklet Finisher SR5120.

  • Page 95: 0664 [Max. No. Stacked Sheets In Output Tray: Stapled Signature]

    [Finishing: Finisher] Setting Item Values Default Value [Paper Length 216] [Default] [Default] [1500 Sheets] [1000 Sheets] [216<Paper Length 432] [Default] [Default] [1000 Sheets] [500 Sheets] [432<Paper Length] [Default] [Default] [500 Sheets] 0664 [Max. No. Stacked Sheets in Output Tray: Stapled Signature] Set the proper number of stapled sheets for each paper size to stack on the shift tray.

  • Page 96: 0666 [Staple Tray: Rib Installed Mode To Strengthen Paper]

    2. Details of Menu Items in Adjustment Settings for Operators Setting Item Values Default Value [Setting] [Default] [Default] [Increase by a Small Amount] [Increase by a Medium Amount] [Increase by a Large Amount] 0666 [Staple Tray: Rib Installed Mode to Strengthen Paper] Set the operation when the Paper Strengthening Rib is installed to Staple Tray.

  • Page 97: 0669 [Convert Number Of Sheets For Booklet]

    [Finishing: Finisher] Setting Item Values Default Value [Setting] [Speed Priority] [Speed Priority] [Accuracy Priority] 0669 [Convert Number of Sheets for Booklet] Set the convert number of sheets for a booklet. This function can be used with Booklet Finisher SR5120. Default Max.

  • Page 98: 0671 [Paper Alignment Angle On Shift Tray]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] [B4 SEF] [A4 LEF] [A4 SEF] [B5 LEF] [B5 SEF] [11 × 17 SEF] × 14 SEF] × 11 LEF] ×...
  • Page 99 [Finishing: Finisher] Setting Item Values Default Value [Setting] [Off] [Off] [On]...

  • Page 100: [Finishing: Fold]

    2. Details of Menu Items in Adjustment Settings for Operators [Finishing: Fold] 0701 [Z-fold Position 1] Adjust the edge of Z-folding when Z-folding is done by the Paper Folding Unit. Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF]...

  • Page 101: 0703 [Half Fold Position: 1 Sheet Fold]

    [Finishing: Fold] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF] [12 × 18 SEF] [11 × 17 SEF] × 14 SEF] × 11 SEF] [8K SEF] [Other Paper Sizes] 0703 [Half Fold Position: 1 sheet Fold] Adjust the edge of folding when Folding in Two is done by the Paper Folding Unit.

  • Page 102: 0704 [Half Fold Position: Multi-Sheet Fold]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [SRA3 SEF] [SRA4 SEF] [310 × 432mm SEF] [226 × 310mm SEF] [13 ×...
  • Page 103 [Finishing: Fold] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [SRA3 SEF] [SRA4 SEF] [310 × 432mm SEF] [226 × 310mm SEF] [13 × 19 SEF] [13 × 19 SEF] [13 ×...

  • Page 104: 0705 [Letter Fold-Out Position 1: 1 Sheet Fold]

    2. Details of Menu Items in Adjustment Settings for Operators 0705 [Letter Fold-out Position 1: 1 sheet Fold] Adjust the edge of folding when Outside 3 Folding is done by the Paper Folding Unit. It is applied when Single Folding is selected. Default Max.

  • Page 105: 0707 [Letter Fold-Out Position 2: 1 Sheet Fold]

    [Finishing: Fold] Default Max. Min. Setting Items Step Unit Value Value Value [B4 JIS SEF] -4.0 [A4 SEF] [B5 JIS SEF] -3.0 × 14 SEF] -4.0 × 11 SEF] [Other Paper Sizes] 0707 [Letter Fold-out Position 2: 1 sheet Fold] Adjust the outer frame size when Outside 3 Folding is done by the Paper Folding Unit.

  • Page 106: 0708 [Letter Fold-Out Position 2: Multi-Sheet Fold]

    2. Details of Menu Items in Adjustment Settings for Operators 0708 [Letter Fold-out Position 2: Multi-sheet Fold] Adjust the outer frame size when Outside 3 Folding is done by the Paper Folding Unit. It is applied when Overlap Folding is selected. Default Max.

  • Page 107: 0710 [Letter Fold-In Position 1: Multi-Sheet Fold]

    [Finishing: Fold] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [12 × 18 SEF] [11 × 17 SEF] × 14 SEF] × 11 SEF] [8K SEF] [Other Paper Sizes] 0710 [Letter Fold-in Position 1: Multi-sheet Fold] Adjust the edge of folding when Inside 3 Folding is done by the Paper Folding Unit.

  • Page 108: 0711 [Letter Fold-In Position 2: 1 Sheet Fold]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [12 × 18 SEF] [11 × 17 SEF] × 14 SEF] ×...

  • Page 109: 0712 [Letter Fold-In Position 2: Multi-Sheet Fold]

    [Finishing: Fold] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [12 × 18 SEF] [11 × 17 SEF] × 14 SEF] × 11 SEF] [8K SEF] [Other Paper Sizes] 0712 [Letter Fold-in Position 2: Multi-sheet Fold] Adjust the fold size when Inside 3 Folding is done by the Paper Folding Unit.

  • Page 110: 0713 [Double Parallel Fold Position 1]/0714 [Double Parallel Fold Position 2]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [12 × 18 SEF] [11 × 17 SEF] × 14 SEF] ×...

  • Page 111: 0715 [Gate Fold Position 1]

    [Finishing: Fold] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [12 × 18 SEF] [11 × 17 SEF] × 14 SEF] × 11 SEF] [8K SEF] [Other Paper Sizes] 0715 [Gate Fold Position 1] Adjust the folding position on the front end side when Gate Folding is done by the Paper Folding Unit.

  • Page 112: 0716 [Gate Fold Position 2]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [11 × 17 SEF] × 14 SEF] × 11 SEF] [8K SEF] [Other Paper Sizes] 0716 [Gate Fold Position 2]...

  • Page 113: 0717 [Gate Fold Position 3]

    [Finishing: Fold] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [11 × 17 SEF] × 14 SEF] × 11 SEF] [8K SEF] [Other Paper Sizes] 0717 [Gate Fold Position 3] Adjust the center folding position when Gate Folding is done by the Paper Folding Unit.

  • Page 114: 0718 [Folding Unit Tray Full Detection]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -4.0 [B4 JIS SEF] [A4 SEF] [B5 JIS SEF] [12 × 18 SEF] [11 × 17 SEF] × 14 SEF] ×...
  • Page 115 [Finishing: Fold] Default Max. Min. Setting Item Step Unit Value Value Value [Setting] sheet(s)

  • Page 116: [Finishing: Perfect Binder]

    2. Details of Menu Items in Adjustment Settings for Operators [Finishing: Perfect Binder] 0801 [Perf Bind Cvr Sht Posit: Across Feed] For Perfect Binding, correct the positional deviation in the vertical direction (top and bottom) of the front cover and middle paper bundle. Default Max.

  • Page 117: 0804 [Applying Binding Glue]

    [Finishing: Perfect Binder] Fore Edge Tail Edge Head Edge CZC219 Default Max. Min. Setting Items Step Unit Value Value Value [Head Edge] 10.0 -10.0 [Tail Edge] [Fore Edge] 0804 [Applying Binding Glue] Adjust the amount of glue for Perfect Binding. Default Max.

  • Page 118: [Finishing: Stacker]

    2. Details of Menu Items in Adjustment Settings for Operators [Finishing: Stacker] 0901 [Ppr Align in Stack Tray: Acr Feed 1] Adjust the alignment width in Main Jogger at the Stacker to reduce dispersion of sheets at right angles due to paper size, thickness, curl, etc. Default Max.

  • Page 119: 0902 [Ppr Align In Stack Tray: Acr Feed 2]

    [Finishing: Stacker] 0902 [Ppr Align in Stack Tray: Acr Feed 2] Adjust the alignment width in Sub Jogger at the Stacker to reduce dispersion of sheets at right angles due to paper size, thickness, curl, etc. Default Max. Min. Setting Items Step Unit Value...

  • Page 120: 0904 [Ppr Align In 2Nd Stack Tray: Acr Feed 1]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [A5 LEF] [A5 SEF] [11 ×...

  • Page 121: 0905 [Ppr Align In 2Nd Stack Tray: Acr Feed 2]

    [Finishing: Stacker] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [A5 LEF] [A5 SEF] [11 × 17 SEF] × 14 SEF] × 11 LEF] ×...

  • Page 122: 0906 [Ppr Align In 2Nd Stack Tray: With Feed]

    2. Details of Menu Items in Adjustment Settings for Operators Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [11 × 17 SEF] × 14 SEF] [Other Paper Sizes] 0906 [Ppr Align in 2nd Stack Tray: With Feed] Adjust the alignment position of the Tip Stopper of the Second Stacker.

  • Page 123: 0907 [Maximum Stack Quantity In Stacker Tray]

    [Finishing: Stacker] Default Max. Min. Setting Items Step Unit Value Value Value [A3 SEF] -1.0 [B4 JIS SEF] [A4 LEF] [A4 SEF] [B5 JIS LEF] [B5 JIS SEF] [A5 LEF] [A5 SEF] [11 × 17 SEF] × 14 SEF] × 11 LEF] ×...
  • Page 124 2. Details of Menu Items in Adjustment Settings for Operators Setting Items Selections Default Value [Small Size] [100%] [50%] [75%] [50%] [25%]...

  • Page 125: [Density Difference Printing: Across Feed]

    [Density Difference Printing: Across Feed] [Density Difference Printing: Across Feed] 1001 [Density Difference Printing: Across Feed] To reduce image density diff. vertically, set 18 shts ppr of min. 279mm wide/min. 420mm long, in the tray. Then select 6 for slider setting and execute printing. Adjustment will reflect to last 2 sheets. Default Max.

  • Page 126: [Finishing: Interposer]

    2. Details of Menu Items in Adjustment Settings for Operators [Finishing: Interposer] 2101 [Detect JAM573] Set ON / OFF for JAM573 (detection of multi feed). If this is set to [On], the machine detects double feeding and so keeps unintended blank sheets out of the delivered paper.

  • Page 127: 2103 [Interposer Fan Level]

    [Finishing: Interposer] 2103 [Interposer Fan Level] Adjust the correction value for the standard value of the interposer fan level. Use [+] or [-] to increase or decrease the fan volume. Default Max. Min. Setting Items Step Unit Value Value Value [Interposer Upper Tray] [Interposer Lower Tray]...
  • Page 128 2. Details of Menu Items in Adjustment Settings for Operators...

  • Page 129: Custom Paper Settings For Administrators

    3. Custom Paper Settings for Administrators Accessing Advanced Settings Press "Login/Logout" ( ) on the top right of the screen. The name that appears lower the "Login/Logout" icon depends on the type of administrator logging in. Enter your login user name and password, and then press [Login]. If you are logging on as the administrator for the first time, enter "admin".

  • Page 130: Description Of Paper Icons

    3. Custom Paper Settings for Administrators Description of Paper Icons You can check the custom paper status by checking the paper icon in the [CustomPaper Management] screen. If you change the custom paper profile in the advanced settings, the paper icon changes as follows: DXW101 1.

  • Page 131: Deleting Saved Custom Paper Profiles

    Deleting Saved Custom Paper Profiles Deleting Saved Custom Paper Profiles Only the machine administrator can delete the custom paper profile saved in the paper library. Press "Login/Logout" ( ) on the top right of the screen. The name that appears lower the "Login/Logout" icon depends on the type of administrator logging in.

  • Page 132: Backing Up And Restoring Custom Paper Profiles

    3. Custom Paper Settings for Administrators Backing up and Restoring Custom Paper Profiles Backing up Custom Paper Profiles Registered Under the [CustomPaper Management] Setting The machine administrator can save all types of registered custom paper to the paper library in an SD card at one time.

  • Page 133: Backing Up And Restoring Custom Paper Profiles Using The External Controller's Control Panel

    Backing up and Restoring Custom Paper Profiles Press Press the [Home] ( ) icon at the center bottom of the screen. • Up to 1,000 custom papers can be saved in the library. • Each saved custom paper is assigned a sequential number from 0001. New data overwrites existing data if both the paper names and paper size settings are the same.

  • Page 134: Paper Presets In "Advanced Settings

    3. Custom Paper Settings for Administrators Paper Presets in "Advanced Settings" In "Advanced Settings", there are paper presets for various types of commercially-available paper. Even if you select a paper preset corresponding to a commercially-available paper from the Paper Library and register it in the [CustomPaper Management] screen, the preset, depending on the custom paper profile version, may not be an exact match for the actual paper.

  • Page 135: Details Of Menu Items In Advanced Settings

    4. Details of Menu Items in Advanced Settings [Machine: Image Position] 1101 [Image Position] Items other than [Switch Paper Edge Detection Sensor] may be used when using a template to align the image position on Sides 1 and 2. [Image Position Result: Side 1]/[Image Position Result: Side 2] Adjust the vertical/horizontal position of the image to be printed on side 1 or 2 of the paper.
  • Page 136 4. Details of Menu Items in Advanced Settings Setting Item Max. Value Min. Value Step Unit 05: Across Feed/06: With Feed 3.00 -3.00 0.01 [Image Magnification Result: Side 1]/[Image Magnification Result: Side 2] Display the vertical/horizontal image scaling on the side 1/2 of the paper according to the paper expansion or shrinkage when performing auto adjust image position.
  • Page 137 [Machine: Image Position] Setting Item Max. Value Min. Value Step Unit 11: Across Feed 0.500 -0.500 0.001 12: With Feed 0.025 [Trapezoidal Distortion Result: Side 1]/[Trapezoidal Distortion Result: Side 2] Display the perpendicularity (image magnification of trailing edge with across feed direction) of side 1/2 when performing auto adjust image position.

  • Page 138: 1102 [Auto Adjust Image Position]

    4. Details of Menu Items in Advanced Settings Setting Item Max. Value Min. Value Step Unit 17: Operator Side/18: Opposite Side of 0.250 -0.250 0.001 Operator [Switch Paper Edge Detection Sensor] Select accuracy of paper edge detection sensor to correct image position in feeding direction. Select [Normal] if paper jam(J031) occurs when the paper other than white is fed.

  • Page 139: 1103 [Image Position Feedback Correction]

    [Machine: Image Position] Setting Item Values 03: Setting [Normal] [High Accuracy] [Paper Edge Detection Sensor: Distance of Sensors] Correct the distance between the two paper edge detection sensors when Auto Adjust Image Position is executed. Setting Item Max. Value Min. Value Step Unit 04: Correction Value...
  • Page 140 4. Details of Menu Items in Advanced Settings [Image Position: Side 1]/[Image Position: Side 2] Adjust the vertical/horizontal position of the image to be printed on side 1/2 of the paper. Setting Item Max. Value Min. Value Step Unit 01: Across Feed/02: With Feed/03: 3.00 -3.00 0.01...

  • Page 141: [Machine: Image Quality]

    [Machine: Image Quality] [Machine: Image Quality] 1201 [Max Image Density] Adjust the maximum image density for each color. Setting Item Max. Value Min. Value Step Unit 01: Black/02: Cyan/03: Magenta/04: None Yellow 1212 [Image Transfer Output] [BW] Adjust the output of the image transfer roller. Black &...

  • Page 142: 1215 [Image Transfer Output Correction]

    4. Details of Menu Items in Advanced Settings Black & White Printing: Superimposed AC Bias Setting Item Max. Value Min. Value Step Unit 01: Side 1/02: Side 2/03: Side 1: None AC/04: Side 2: AC [FC] Adjust the paper transfer output. Full Color Printing: Current Value Full Color Printing: Superimposed AC Bias Setting Item...

  • Page 143: 1217 [Paper Transfer Output Correction: Paper Edge]

    [Machine: Image Quality] [FC] Adjust the correction amount of image transfer output for leading edge. Cyan/Magenta/Yellow Setting Item Max. Value Min. Value Step Unit 03: Leading Edge: Color None [FC] Adjust the correction range of image transfer output for leading edge. Cyan/Magenta/Yellow Setting Item Max.

  • Page 144: 1229 [Paper Transfer Pressure]

    4. Details of Menu Items in Advanced Settings Setting Item Max. Value Min. Value Step Unit 06: Leading Edge/08: Trailing Edge/09: None Trailing Edge: AC 07: Leading Edge Length 10: Trailing Edge Length 1229 [Paper Transfer Pressure] Adjust the transfer pressure at the paper transfer section. Select a higher value (1 -> 4) for the pressurization for paper that is more uneven.

  • Page 145: 1241 [Fusing Temperature]

    [Machine: Image Quality] 1241 [Fusing Temperature] [BW] Adjust the temperature of heat roller and pressure roller. Black & White Printing • If the paper fusing temperature is specified differently (with a difference of 6°C or more) for different paper types, the throughput is reduced because of the need to switch the fusing temperature when handling a job with sheets of mixed paper type.

  • Page 146: 1242 [Fusing Pressure Roller On Before Fusing]

    4. Details of Menu Items in Advanced Settings Setting Item Max. Value Min. Value Step Unit 05: Corct Temp: Initial Feed 06: Corct Temp: Pre-Feed [Initial Sheet Interval] Adjust the sheet interval by reducing the print speed. • If the value in this setting is changed, the throughput is reduced because of the increased interval between printing each sheet immediately after printing starts.

  • Page 147: 1244 [Fusing Cleaning]

    [Machine: Image Quality] Setting Item Values 01: Setting [0:Off] [1:On] 1244 [Fusing Cleaning] Adjust the rotation interval, and contact and disengage movement of the web for pressure roller cleaning. Setting Item Values 01: Cleaning Interval [1:Normal] [2:Frequently] [3:More Frequently] [4:Most Frequently] 02: Contact and Disengage [0:Off] [1:On]...

  • Page 148: 1247 [Fusing Temperature Range]

    4. Details of Menu Items in Advanced Settings Setting Item Max. Value Min. Value Step Unit 01: Other than Envelope None 02: Envelope 2900 msec 1247 [Fusing Temperature Range] [BW/FC] Set fusing temp conditions which permit paper feed. The lager value becomes, the earlier print starts. However, fusing quality may become lower.

  • Page 149: 1250 [Print Mode When Switching Paper Type]

    [Machine: Image Quality] • The higher the frequency, the longer it takes to execute fusing belt smoothing. Setting Item Values 01: For Belt Scratches [0:Off (Do not Execute)] [1:Normal] [2:Frequently] [3:More Frequently] [4:Most Frequently] 1250 [Print Mode When Switching Paper Type] Adjust the waiting time of switching the paper by selecting the print mode of a job with mixed paper.

  • Page 150: [Machine: Paper Feed/ Output]

    4. Details of Menu Items in Advanced Settings [Machine: Paper Feed/ Output] 1301 [Main/2-Tray LCIT: Paper Feed Mode] Adjust the fan operation if double feed or nonfeed occurs in Main Tray and 2-Tray LCIT. Setting Item Values 01: Paper Feed Mode:Fan Level [0:Prevent Double Feed (Weakest Blow)] [1:Prevent Double Feed (Weaker Blow)] [2:Standard (Default)]...
  • Page 151 [Machine: Paper Feed/ Output] Setting Item Max. Value Min. Value Step Unit 08: Size: Across: S/ Feed: s/09: Size: Across: S/ Feed: m/10: Size: Across: S/ Feed: l/11: Size: Across: L/ Feed: s/12: Size: Across: L/ Feed: m/13: Size: Across: L/ Feed: l [Side Fan Level] Adjust the side fan operation in Main Tray and 2-Tray LCIT.
  • Page 152 4. Details of Menu Items in Advanced Settings Setting Item Max. Value Min. Value Step Unit 26: Size: Across: S/ Feed: s/27: Size: Across: S/ Feed: m/28: Size: Across: S/ Feed: l/29: Size: Across: L/ Feed: s/30: Size: Across: L/ Feed: m/31: Size: Across: L/ Feed: l [Updraft Fan Shutter] Turn on or off the updraft fan shutter in Main Tray and 2-Tray LCIT.

  • Page 153: 1303 [Main/2-Tray Lcit: Other Setting]

    [Machine: Paper Feed/ Output] Setting Item Values 34: Setting [0:Off] [1:On] [Vacuum Fan Shutter] Turn on or off the vacuum fan shutter in Main Tray and 2-Tray LCIT. If [On] is set, the fan operates according to the paper fed timing. [Off] enables constant operation of the fan. Setting Item Values 35: Setting...

  • Page 154: 1321 [Jam Detection]

    4. Details of Menu Items in Advanced Settings Setting Item Values 01: Correction Mode [1: Off] [2: П Curl Correction Level: Small] [3: П Curl Correction Level: Medium] [4: П Curl Correction Level: Large] [5: U Curl Correction Level: Small] [6: U Curl Correction Level: Medium] [7: U Curl Correction Level: Large] 1321 [Jam Detection]...

  • Page 155: 1331 [Motor Speed]

    [Machine: Paper Feed/ Output] Setting Item Max. Value Min. Value Step Unit 06: Setting None 1331 [Motor Speed] [Speed Adjustment] Adjust the speed of each motor. • If the value in "02: Paper Transfer Roller" is set differently for each paper type, the throughput is reduced because of the need to adjust the paper transfer line speed for each paper type when handling a job with sheets of mixed paper type.

  • Page 156: 1341 [Adjust Paper Curl (Fusing)]

    4. Details of Menu Items in Advanced Settings Setting Item Values 06: Process Speed Setting [0:Standard Speed] [1:Low Speed] [Speed Adjustment] Adjust the speed of each motor. • If the value in "07: Paper Feed Interval Setting" is changed, the interval between each sheet of paper during printing is increased, resulting in reduced throughput.
  • Page 157 [Machine: Paper Feed/ Output] Setting Item Values 01: Curl Adjustment Setting [0:Off] [1:On] [Speed Adjustment] Set whether to adjust the warp (curl) of paper in fusing. • Specify the interval between each sheet of paper in "01: Curl Adjustment Setting". The higher the value, the greater the interval becomes, resulting in reduced throughput.
  • Page 158 MEMO M0B2-1023D...
  • Page 160 EN GB EN US EN AU M0B2-1023D © 2018, 2019, 2020...

This manual is also suitable for:

Pro c9210

Table of Contents
