CIP Training
Pro C9200 series
1
Input

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pro C9200 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Ricoh Pro C9200 Series

  • Page 1 CIP Training Pro C9200 series Input...
  • Page 3: Loading Paper

    CIP Training Pro C9200 series Loading Paper Do not stack paper over the limit mark • Jams and misfeeds can occur when printing on thick glossy sheets. To prevent such problems, be sure to fan glossy sheets thoroughly before loading them.
  • Page 4 CIP Training Pro C9200 series Loading Paper Loosen the stack by riffling the sheets. CVA068 Holding its shorter ends, flex the stack back and forth to create space between the sheets. Repeat this several times. CVA069 CVA070 Make sure there is space between the sheets.
  • Page 5 CIP Training Pro C9200 series Loading Large Capacity Trays Loading Paper into Trays 1, 2, and the Wide Large Capacity Tray Each paper tray is loaded in the same way. The wide LCT is identified as Tray 3, Tray 4, Tray 5, Tray 6, Tray 7, and Tray 8.
  • Page 6 CIP Training Pro C9200 series Loading Large Capacity Trays Step: 1 Check that paper in the paper tray is not being used, and then pull the tray carefully out until it stops. Remove paper if loaded. Step: 2 Release the end fence by pressing and holding green button.
  • Page 7 CIP Training Pro C9200 series Loading Large Capacity Trays Step: 4 Load paper by aligning the paper with the left side of the paper tray. Place paper with print side up. Load a stack of paper about 5–10 mm high.
  • Page 8 CIP Training Pro C9200 series Loading Large Capacity Trays When loading small stock. When you load paper that is 204 mm or smaller, remove the supporting plates from the bottom of the paper tray. Store them in the pocket on the right-hand side of the paper tray.
  • Page 9 CIP Training Pro C9200 series Loading Large Capacity Trays When loading tab stock, attach the tab fence. Step: 1 Check that paper in the paper tray is not being used, and then pull the tray carefully out until it stops.
  • Page 10: Loading Paper Into The Multi Bypass Tray (Tray A)

    CIP Training Pro C9200 series Loading Paper into the Multi Bypass Tray (Tray A) Use the multi bypass tray (Tray A) to use transparencies, translucent paper, and paper that cannot be loaded in the paper trays. • The maximum number of sheets you can load at the same time depends on paper type. Do not stack paper over the limit mark.
  • Page 11 CIP Training Pro C9200 series Loading Paper into the Multi Bypass Tray (Tray A) To remove the end fence, slide it to the right by pressing the stopper down. CWW312 Step: 3 Press the elevator switch on the multi bypass tray (Tray A).
  • Page 12 CIP Training Pro C9200 series Loading Paper into the Multi Bypass Tray (Tray A) Loading tab stock into the multi bypass tray (Tray A) When setting tab stock, always use the tab fence. Tabs must be set at the right side of the multi bypass tray (Tray A).
