4
Fasten the server to the rack with the 4 thumbscrews (M5).
15

Reinstalling the hard disk units

Reinstalling procedure
1
Reinstall the hard disk units to the server.
With its handle open, insert each hard
disk unit back into their respective 3.5 -
inch storage bays.
Close the handle to lock the hard disk
units in their storage bays.
Be careful not to pinch your fingers or catch any clothing when
sliding the server into the cabinet.
Be sure to reinstall the hard disk units back to their correct bays
from which they were removed.
15 Reinstalling the hard disk units
E
Handle
29
