Multicolor Illuminated Vandal Resistant
SD-7175SGEX1Q
SD-7275SGEX1Q
SD-7275SGEX2Q
Features:
• Vandal resistant, ø1" (ø25mm) multicolor
illuminated momentary pushbutton
• Illuminated 12VDC LED (supports 24VDC with
1
included 1k6,
/
4
• NO/NC Contact rated 50A@24VAC
Request-to-Exit Plates
Brushed stainless slimline faceplate with English and Spanish
Brushed stainless single-gang faceplate with English and Spanish
Brushed stainless single-gang faceplate with English and Arabic
W resistor)
Manual
• Selectable LED color
(red, green, blue, magenta, yellow, cyan, or white)
• Switch is IP65 rated for outdoor use
• "EXIT" and "SALIDA" silk-screened on plate
(SD-7275SGEX2Q is English and Arabic)
®
SD-7275SGEX1Q shown
