SECO-LARM Enforcer SD-C141S Installation Manual

Door Closer Installation Manual

Specifications:

SD-C141S
Door widths 3' 6" (1100mm) wide
Door weight 88lbs. (40kg.) ~ 143lbs.(65kg.)
Door types
Metal or wood
Hand Non-handed
Body Anodized aluminum
Arm Forged steel
WARNING: Incorrect mounting which leads to exposure to rain or moisture inside the enclosure could damage the
device and void the warranty.
WARRANTY This SECO-LARM product is warranted against defects in material and workmanship while used in normal
service for a period of one (1) year from the date of sale to the original consumer customer. SECO-LARM's obligation is
limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM.
This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect,
repair, or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines
that such equipment is not operating properly as a result of causes other than defects in material and workmanship.
The sole obligation of SECO-LARM, and the purchaser's exclusive remedy, shall be limited to replacement or repair only, at
SECO-LARM's option. In no event shall SECO-LARM be liable for any special, collateral, incidental, or consequential
personal or property damages of any kind to the purchaser or anyone else.
NOTICE: The information and specifications printed in this manual are current at the time of publication. However, the
SECO-LARM policy is one of continual development and improvement. For this reason, SECO-LARM reserves the right
to change specifications without notice. SECO-LARM is also not responsible for misprints or typographical errors.
Copyright © 2007 SECO-LARM U.S.A., Inc. All rights reserved. This material may not be reproduced or copied, in
whole or in part, without the written permission of SECO-LARM.
SECO-LARM ® U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Tel: 800-662-0800 / 949-261-2999 Fax: 949-261-7326
Made in T aiwan
Website: www.seco-larm.com
® PITSW6
@
E-mail: sales seco-larm.com
DoorCloser.pmd
SECO-LARM U.S.A., Inc.
Installation Manual
ENFORCER
SD-C14 1S
Door Closer

Features:

•
Reversible non-handed design
•
Metal or wood doors up to 42" wide
•
Two valve adjustments (Sweep and
Latch) for speed. Caution:
•
Anodized aluminum body
A misadjusted door closer can cause
•
Silver finish
damage or injury. Read the complete
•
Forged steel arms installation manual before you begin
•
to insure correct installation.
Includes hardware

What It Does:

SECO-LARM's SD-C141S Door Closer is designed to work on either left or right swinging doors. It has adjustable sweep
and latch speed for more control over how fast the door swings.
Fig. 1 -- Dimensions:
2 / 1 " (58mm)
4
5 / 3 " (133mm)
16
3
8 /
16
®
11 / " (17mm)
16
3" (75mm)
" (208mm)
2 / 3 "
16
(55mm)
3
1 / "
8
(40mm)
