Summary of Contents for Eaton Char-Lynn
- Page 1 Delta Motors Parts and Repair Manual...
- Page 2 Parts Table of Contents Parts Parts List Disassembly Reassembly EATON Char-Lynn Delta Motors Parts and Repair Manual C-MOLO-TS003-E September 2007...
- Page 3 14384-007 138.4 5.45 4999844-009 69.9 2.75 5986952-009 140.5 5.53 39.6 14384-009 151.1 5.95 4999844-010 83.6 3.29 5986952-010 154.2 6.07 46.0 14384-012 164.6 6.48 4999844-011 99.6 3.92 5986952-011 167.9 6.61 EATON Char-Lynn Delta Motors Parts and Repair Manual C-MOLO-TS003-E September 2007...
- Page 4 Replace the bearing only if signs of wear and/or contamination are visible. If necessary remove the bearing from valve plate by tapping it with a hammer and a screwdriver. EATON Char-Lynn Delta Motors Parts and Repair Manual C-MOLO-TS003-E September 2007...
- Page 5 Blow them dry with pressurized air. Do not wipe parts dry with paper towels or cloth, as lint in a hydraulic system will cause damage. BRASS BACKUP EATON Char-Lynn Delta Motors Parts and Repair Manual C-MOLO-TS003-E September 2007...
- Page 6 Lubricate the shaft seal lip with Mobilux EP 111, place on assembly tool No. 600421-2 and press it into the interior bore of the housing. EATON Char-Lynn Delta Motors Parts and Repair Manual C-MOLO-TS003-E September 2007...
- Page 7 Loctite 277 to hold the pins. Install one backup ring, then the o-ring onto the balance ring. Install the wave spring with sufficient petroleum jelly to keep it in place. EATON Char-Lynn Delta Motors Parts and Repair Manual C-MOLO-TS003-E September 2007...
- Page 8 Press bearing into valve plate with Tool No. 606252 with the lettering on the bearing contacting the tool. Place valve plate assembly into the housing aligning the bolt holes. EATON Char-Lynn Delta Motors Parts and Repair Manual C-MOLO-TS003-E September 2007...
- Page 9 Hex Head holes. Lubricate and insert Screw seven bolts and torque them to 500±50 lbf-in (42±4 lbf-ft, 56±5 Nm) in a crisscross pattern. End Cap O-ring Gerolor Assembly O-ring EATON Char-Lynn Delta Motors Parts and Repair Manual C-MOLO-TS003-E September 2007...
- Page 10 300 Huaihai Zhong Road Switzerland Shanghai 200021 Tel: 952-937-9800 Tel: +41 (0) 21 811 4600 China Fax: 952-294-7722 Fax: +41 (0) 21 811 4601 Tel: 86-21-6387-9988 www.hydraulics.eaton.com Fax: 86-21-6335-3912 ©2007 Eaton Corporation All Rights Reserved Printed in USA Document No. C-MOLO-TS003-E September 2007...
