and the air inlet and outlet are not blocked. Ensure the induction cooker hob is in
good work state. As shown below
Note: The safety distance between the hotplate and the cupboard above
the hotplate should be at least 760 mm.
A(mm) B(mm)
760 50 mini

Befor e locatin g th e fixin g brackets

Th e uni t shoul d b e place d o n a stable , smoot h surf ace (u se th e
packaging). D o no t appl y fo rce ont o th e control s protrudin g fro m th e hob.
C(mm) D
20 mini Air intake
E
Air exit 5mm
16
