AN5116-06B
Optical Line Terminal Equipment
Hardware Description
Version A
Code: MN000000067
FiberHome Telecommunication Technologies Co., Ltd.
January 2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AN5116-06B and is the answer not in the manual?

Questions and answers

Related Manuals for FiberHome AN5116-06B

Summary of Contents for FiberHome AN5116-06B

  • Page 1 AN5116-06B Optical Line Terminal Equipment Hardware Description Version A Code: MN000000067 FiberHome Telecommunication Technologies Co., Ltd. January 2010...
  • Page 3 Please contact your local sales representative, service representative or distributor for any help needed at the contact information shown below. Fiberhome Telecommunication Technologies Co., Ltd. Address: No. 5 Dongxin Rd., Hongshan Dist., Wuhan, China Zip code: 430073 Tel:...
  • Page 5 ® ® ® ® are trademarks of FiberHome Telecommunication Technologies Co., Ltd. (Hereinafter referred to as FiberHome) All brand names and product names used in this document are used for identification purposes only and are trademarks or registered trademarks of their respective holders.

  • Page 7: Preface

    Configuration Guide software upgrading configuration, to guide users on start-up for various services and software upgrading. Introduces the shortcut menu for every card of the AN5116-06B inside ANM2000 Network Management System, including the AN5116-06B Optical Line function, parameter explanation, precautions and configuration...
  • Page 8 Reference alarm processing. Introduces the fault processing principles and methods of fault diagnosis and locating for the AN5116-06B. Also discusses the AN5116-06A Optical Line typical fault cases of various services. If the trouble is too Terminal Equipment...

  • Page 9: Version And Usage

    Version and Usage Version Instruction Initial version Intended Readers This manual is intended for the following readers: Marketing engineers Commissioning engineers Operation and maintenance engineers To utilize this manual, these prerequisite skills are necessary: Electrical safety information Related mechanical engineering knowledge...

  • Page 10: Conventions

    Conventions Terminology Conventions Terminology Meaning AN5116-06B AN5116-06B Optical Line Terminal Equipment FiberHome e-Fim ANM2000 Broadband Access Network Management ANM2000 System EC4B 4×EPON-C Interface Card (type B) 8 × PON-C Interface Card (type B) GC4B 4×GPON-C Interface Card (type B) C155A 4×GE +1×10GE Optical Interface Uplink Card (CES Mode)

  • Page 11: Table Of Contents

    Contents Preface ........................I  Relevant Manuals ................I  Version and Usage ................III  Intended Readers ................III  Conventions ..................IV  1  The Cabinet ....................1-1  1.1  Appearance ..................1-2  1.2  Size and Weight ................1-2  1.3  Structure ..................1-3  1.4  Typical Layout ................
  • Page 12 Environmental Monitoring Interface ......3-6  3.6.3  Alarm Interface ............. 3-6  3.6.4  Outband Network Management Interface ....3-6  4  The AN5116-06B Cards ................4-1  4.1  Card Configuration Table ............... 4-2  4.2  The HSWA Card ................4-2  4.3  The EC4B Card ................4-5 ...
  • Page 13 Figures Figure 1-1  An illustration of the cabinet ............1-2  Figure 1-2  The cabinet ..................1-3  Figure 1-3  An illustration of the typical layouts ..........1-4  Figure 1-4  The layout of the wires and cables in the top access wiring mode . 1-5  Figure 1-5 ...
  • Page 14 Figure 5-14  The serial port cable ..............5-11  Figure 5-15  The dry contact cable ..............5-12  Figure 5-16  The subrack protective earth ground cable ......... 5-13 ...
  • Page 15 Descriptions on the fan unit indicator LEDs ........3-4  Table 3-3  Fan Unit Parameter Table .............. 3-5  Table 4-1  The AN5116-06B card configuration table ........4-2  Table 4-2  The HSWA card interfaces ............. 4-3  Table 4-3  The HSWA card indicator LEDs ............. 4-3 ...
  • Page 16 Table 4-27  The HU1A card indicator LEDs ............ 4-18  Table 4-28  The HU1A card technical specification ......... 4-18  Table 4-29  The HU1A card interfaces ............4-19  Table 4-30  The HU1A card indicator LEDs ............ 4-19  Table 4-31  The HU2A card technical specification ......... 4-19  Table 4-32 ...

  • Page 17: The Cabinet

    The Cabinet This chapter introduces the AN5116-06B cabinet and includes the following contents: Appearance Size and Weight Structure Typical Layout Wiring Inside the Cabinet Ventilation Principle Version A...

  • Page 18: Appearance

    AN5116-06B Optical Line Terminal Equipment Hardware Description Appearance The appearance of the cabinet is illustrated in Figure 1-1. Figure 1-1 An illustration of the cabinet Size and Weight In terms of height, the cabinets can be classified into 4 types. Table 1-1 provides the size and weight of each type.

  • Page 19: Structure

    1 The Cabinet Structure The structure and the names of various cabinet components are illustrated in Figure 1-2. （1） （2） （3） （4） （12） （5） （11） （6） （7） （8） （9） （10） (1) Rear door (5) Channel (9) Ventilation hole at the cabinet bottom (2) Wiring hole on the cabinet top (6) ESD protective earth ground...

  • Page 20: Typical Layout

    AN5116-06B Optical Line Terminal Equipment Hardware Description Three alarm indicators are installed on the top of the cabinet. Table 1-2 describes the meaning and status of each alarm. Table 1-2 Descriptions of alarm indicators Color Meaning Status Description An emergency alarm in equipment...

  • Page 21: Wiring Inside The Cabinet

    1 The Cabinet Wiring Inside the Cabinet Depending on the location of the cable channel in the equipment room, cables inside the cabinet can be arranged in the top access wiring or floor access wiring mode. Figure 1-4 and Figure 1-5 illustrate the layouts of the wires and cables under the top access wiring mode and the floor access wiring mode respectively.

  • Page 22: Figure 1-5 The Layout Of The Wires And Cables In The Floor Access Wiring Mode

    AN5116-06B Optical Line Terminal Equipment Hardware Description Figure 1-5 The layout of the wires and cables in the floor access wiring mode Version A...

  • Page 23: Ventilation Principle

    1 The Cabinet Ventilation Principle The ventilation principle inside the cabinet is illustrated in Figure 1-6. A flow of air is forced by the air guide unit at the lower part of the subrack into the cabinet. After being blown by the fan unit on the top of the subrack, the cooling air passes upward through the subracks and is exhausted from the top of the cabinet.

  • Page 25: The Pdp

    The PDP This chapter introduces the AN5116-06B PDP and includes the following contents: Functions Structure Power Terminals Parameter Specifications Version A...

  • Page 26: Function

    AN5116-06B Optical Line Terminal Equipment Hardware Description Function The PDP provides individual -48V power feeds for each subrack and cards inside the cabinet by distributing the -48V power received from the power cabinet in the equipment room. Structure The hardware no. of PDP is 3.000.059. The PDP is small and compact. Its structural and engineering design complies with the relevant national and international standards.

  • Page 27: Power Terminals

    If the equipment room provides only the single power rail, but the AN5116-06B requires redundant power rails or 6 branch power rails, users can use shorting plugs to short circuit -48V1 and -48V2; GND1 and GND2 of the main power supply connector posts.

  • Page 28: Automatic Circuit Breakers

    AN5116-06B Optical Line Terminal Equipment Hardware Description Figure 2-3 The power supply connector posts Table 2-1 shows the association between the power supply connector posts on the PDP rear panel and the automatic circuit breakers (ACBs) on the front panel.

  • Page 29: Specifications

    2 The PDP Specifications Table 2-2 shows the relevant specifications of PDP. Table 2-2 The PDP parameter specifications Item Parameter Size 89mm×480mm×230mm (Height×Width×Depth) Voltage -48V±20% The summed current of main power is not greater than. The Current current output of branch power is 20A Ambient temperature -10℃...

  • Page 31: The Subrack

    The Subrack This chapter introduces the AN5116-06B subrack and includes the following contents: Structure Size and Weight Subrack Configuration Fan Unit Air Guide Unit Subrack Interface Version A...

  • Page 32: Structure

    AN5116-06B Optical Line Terminal Equipment Hardware Description Structure The hardware no. of the subrack is 3.061.088. The structure and the names of the various components of the subrack are illustrated in Figure 3-1. Fan Unit Mounting ear Card Air guide unit...

  • Page 33: Subrack Configuration

    The subrack configuration and slot distribution are illustrated in Figure 3-2. Figure 3-2 An illustration of subrack configuration The AN5116-06B subrack totally has 20 vertical slots. The slots 1-8 and 11-18 accommodate the following cards: the EC4B, the GC4B, the C155A, the CE1B, or the PUBA The slots 9 and 10 are slightly wider and accommodate the core switch card The slots 19 and 20 are at the rightmost side of the subrack.

  • Page 34: Fan Unit

    3.4.2 Appearance The hardware no. of the fan unit is 2.119.295. The AN5116-06B is provided with 3 fan units. Each fan unit can be installed and removed independently. Figure 3-3 illustrates the appearance of the fan unit. Figure 3-3 The appearance of the fan unit 3.4.3...

  • Page 35: Specifications

    3 The Subrack 3.4.4 Specifications Table 3-3 provides the size, weight and power consumption of the fan unit. Table 3-3 Fan Unit Parameter Table Item Parameter Single fan size (Width×Height×Depth) 146.2 mm x 54.5 mm x 236.5mm Single fan weight Single fan power consumption ≤15W Air Guide Unit...

  • Page 36: Subrack Interface

    AN5116-06B Optical Line Terminal Equipment Hardware Description Subrack Interface The air guide unit of the subrack has 4 types of interfaces. 3.6.1 Power Interface Symbol Type Quantity Purpose Connected to the PDP using the power cable PWR1, PWR2 DC –48V...

  • Page 37: The An5116-06B Cards

    The AN5116-06B Cards This chapter introduces the functions, interfaces, indicator LEDs, keys and technical specifications of all cards used in the AN5116-06B. It includes the following contents: Card Configuration Table The HSWA Card The EC4B Card C8B Card The GC4B Card...

  • Page 38: Card Configuration Table

    AN5116-06B Optical Line Terminal Equipment Hardware Description Card Configuration Table Table 4-1 The AN5116-06B card configuration table Type Slot Symbol Card No. Remarks 2.115.334 Provides EPON access function Core switch 9, 10 HSWA card 2.115.331 Provides GPON access function EC4B 2.119.318...

  • Page 39: Table 4-2 The Hswa Card Interfaces

    Supports CoS queues and processes user services on the basis of CoS; Supports environmental monitoring information and alarm information reporting of the AN5116-06B and the connected ONUs; Supports ACL functions and has a strict security protection mechanism; Supports DHCP Snooping and DHCP Option 82;...

  • Page 40: Figure 4-1 The Location Of The Key On The Hswa Card

    Caution: The reset operation may result in interruption of all services carried by the AN5116-06B. The reset operation is generally conducted in course of the card maintenance and upgrade. It is not recommended that the user directly issue a reset command using the reset key.

  • Page 41: The Ec4B Card

    Supports remote software upgrade of the card software. Interface Description Table 4-6 The EC4B card interfaces Symbol Meaning Description EPON interfaces 1-4 Connected to a remote ONU using an ODN Debugging interface Reserved for FiberHome use Version A...
  • Page 42 AN5116-06B Optical Line Terminal Equipment Hardware Description Indicator LED Description Table 4-7 The EC4B card indicator LEDs Symbol Meaning Color Status Description The card is working normally The card is initializing or the software is starting. Blink The communication link between the active...

  • Page 43: Figure 4-2 The Location Of The Keys Of The Ec4B Card

    4 The Card The panel side The mounting side Figure 4-2 The location of the keys of the EC4B card Caution: The reset operation may result in interruption of all ONU services carried by the EC4B card. The reset operation is generally conducted in course of the card maintenance and upgrade.
  • Page 44 AN5116-06B Optical Line Terminal Equipment Hardware Description The GC8B Card Main Function Provides 8 GPON interfaces; Supports multiple including data, voice, IPTV; Supports real-time DBA; Provides flexible QoS and SLA; Provides FEC; Supports local and remote loopback tests; Provides OAM;...
  • Page 45 4 The Card Indicator LED Description The GC8B card indicator LEDs Table 4-11 GC8B Symbol Meaning Color Status Description The card is working normally The card is initializing or the software is starting. Blink The communication link between the active slowly card and the standby card has not been established yet...

  • Page 46: The Gc4B Card

    AN5116-06B Optical Line Terminal Equipment Hardware Description The panel side The mounting side Figure 4-3 The location of the key of the EC8B card Caution: The reset operation may result in interruption of all ONU services carried by the GC8B card. The reset operation is generally conducted in course of the card maintenance and upgrade.

  • Page 47: Table 4-14 The Gc4B Card Interfaces

    Support pre-authorization and pre-configuration of ONUs; Supports remote software upgrade of the card software. Interface Description Table 4-14 The GC4B card interfaces Symbol Meaning Description GPON interfaces 1-4 Connected to a remote ONU using an ODN Debugging interface Reserved for FiberHome use Version A 4-11...
  • Page 48 AN5116-06B Optical Line Terminal Equipment Hardware Description Indicator LED Description Table 4-15 The GC4B card indicator LEDs Symbol Meaning Color Status Description The card is working normally The card is initializing or the software is starting. Blink The communication link between the active...

  • Page 49: The C155A Card

    4 The Card The mounting side The panel side Figure 4-4 The location of the keys of the GC4B card Caution: The reset operation may result in interruption of all ONU services carried by the GC4B card. The reset operation is generally conducted in course of the card maintenance and upgrade.

  • Page 50: Table 4-18 The C155A Card Interfaces

    AN5116-06B Optical Line Terminal Equipment Hardware Description Interface Description Table 4-18 The C155A card interfaces Symbol Meaning Description CLIK IN1 Clock input interface The first external clock input. CLIK IN2 Clock input interface The second external clock input. CLIK OUT Clock output interface The external clock output.

  • Page 51: The Ce1B Card

    4 The Card The panel side The mounting side Figure 4-5 The location of the key of the C155A card Caution: The reset operation may result in interruption of all services carried by the C155A card. The reset operation is generally conducted in course of the card maintenance and upgrade.
  • Page 52 AN5116-06B Optical Line Terminal Equipment Hardware Description Interface Description Table 4-22 The CE1B card interfaces Symbol Meaning Description Provides E1 interfaces and connects with the E1-E32 E1 interface transmission network Clock input CLIK IN For introduction of the external clock...

  • Page 53: The Hu1A Card

    Caution: The reset operation may result in interruption of all services carried by the AN5116-06B. The reset operation is generally conducted in course of the card maintenance and upgrade. It is not recommended that the user directly issue a reset command using the reset key.

  • Page 54: The Hu2A Card

    AN5116-06B Optical Line Terminal Equipment Hardware Description Interface Description Table 4-26 The HU1A card interfaces Symbol Meaning Description 10GE uplink optical Provides10GE uplink optical interface and connects with interface the IP network GE uplink optical / Provides GE uplink optical / electrical interface and...

  • Page 55: Table 4-29 The Hu1A Card Interfaces

    4 The Card Each uplink interface can be used as a cascade interface allowing multiple devices to be cascaded to the IP network via a single IP port. Interface Description Table 4-29 The HU1A card interfaces Symbol Meaning Description 10GE uplink optical Provides 10GE uplink optical interface and connects with interface the IP network...

  • Page 56: The Gu6F Card

    AN5116-06B Optical Line Terminal Equipment Hardware Description 4.10 The GU6F Card Main Function Provides six GE uplink optical / electrical interfaces. Users can replace the optical / electrical module to select the corresponding optical / electrical interface. Of these interfaces, the optical interfaces 3 and 4 are auto negotiate to rates 10/100/1000M;...

  • Page 57: The Puba Card

    The PUBA card interfaces Meaning Description Environmental DC1-DC14 monitoring Used to connect dry contact signals interface Debugging Reserved for FiberHome use interface Indicator LED Description Table 4-36 The PUBA card indicator LEDs Meaning Color Status Description The card is working normally...

  • Page 58: Table 4-38 The Puba Card Technical Specification

    AN5116-06B Optical Line Terminal Equipment Hardware Description The panel side The mounting side Caution: The reset operation may result in interruption of all services carried by the PUBA card. The reset operation is generally conducted in course of the card maintenance and upgrade. It is not recommended that the user directly issue a reset command using the reset key.

  • Page 59: Cables And Connectors

    Cables and Connectors This chapter introduces the AN5116-06B various cables and connectors and includes the following contents: Power Cable Fiber Jumper E1 CABLE Clock Cable (Coaxial) Network Cable Serial-Port Cable Dry Contact Connection Cable Subrack Ground Cable Version: A...

  • Page 60: Power Cable

    The cabinet power cable is used to input power from the equipment room to the cabinet. Appearance View The AN5116-06B cabinet power cable is composed of three cables, each with a unique color. The blue power cable is a DC -48V power cable. The hardware no. is WKE3.696.097.

  • Page 61: Subrack Power Cable

    Subrack Power Cable Purpose The subrack power cable of the AN5116-06B is used to connect the PDP and the subracks and provide both the active and standby power supplies for the subracks. The hardware no. is WKE3.696.229. The subrack power cables have already been connected in the cabinet before delivery.

  • Page 62: Fiber Jumper

    AN5116-06B Optical Line Terminal Equipment Hardware Description 0V black -48V blue Figure 5-5 The subrack power cable Terminal Definition The D type three-conductor plug’s pins are illustrated in Figure 5-6, the pins A1 and A3 short circuited and insulated before the plug manufacture.

  • Page 63: E1 Cable

    5 Cables and Connectors Appearance View The AN5116-06B uses the LC / PC and SC / PC fiber jumpers. Their connectors are illustrated in Figure 5-7 and Figure 5-8 respectively. Figure 5-7 The LC / PC optical fiber connector Figure 5-8...

  • Page 64: Figure 5-9 The 75Ω E1 Cable

    AN5116-06B Optical Line Terminal Equipment Hardware Description Figure 5-9 The 75Ω E1 cable Terminal Definition The end of the E1 cable connected with the CE1B card is DB-44P type plug, and the end connected with the MDF is composed of bare wires. Figure 5-10 illustrates the appearance of the DB-44P type plug;...

  • Page 65: Table 5-3 The E1 Interface Pins

    5 Cables and Connectors Table 5-3 The E1 interface pins E1 Interface Coaxial E1 Interface Coaxial E1 Port E1 Port Cable No. Cable No. 15, 30 E1 Rx 15, 30 E1 Rx 14, 29 E1 Tx 14, 29 E1 Tx 13, 28 E1 Rx 13, 28...

  • Page 66: Coaxial Clock Cable

    Coaxial Clock Cable Purpose The coaxial clock cable is used to transmit E1 clock signals, and connect, CLIK IN & CLIK OUT interfaces of the AN5116-06B C155A and CE1B cards with the MDF in the equipment room. Appearance View The hardware no. of the coaxial clock cable is 3.695.187. Its appearance is illustrated in Figure 5-11.

  • Page 67: Network Cable

    GU6F Connects an ANM2000 computer that implements network management monitor The AN5116-06B can automatically identify a straight-through and cross-over network cable. Users can use either of the two types. Appearance View The hardware no. of the network cable is 3.695.095. Its appearance is illustrated in Figure 5-12.
  • Page 68 AN5116-06B Optical Line Terminal Equipment Hardware Description Figure 5-13 The RJ-45 connector The wiring schemes of the straight-through network cable and the cross-over network cable are shown in Table 5-5 and Table 5-6. Table 5-5 The wiring scheme of the straight-through network cable...

  • Page 69: Serial Port Cable

    The serial port cable Terminal Definition The end of serial port cable connected with the AN5116-06B is a RJ-45 connector and the end connected with the network management computer is a DE-9 connector. The connection relationship of the corresponding pins is shown in Table 5-7.

  • Page 70: Dry Contact Cable

    Dry Contact Cable Purpose The dry contact cable is used to connect the DC1-DC14 interfaces of the AN5116-06B with the external dry contact devices that monitor infrared detection, smoke, electric supply, humidity, temperature, fan, vibration and access control. Appearance View The hardware no.

  • Page 71: Subrack Ground Cable

    5 Cables and Connectors Table 5-8 The wiring scheme of the dry contact cable Pin of the Local End Wire Color Opposite End White-orange Earthing ground Dry contact device level output Orange Dry contact device level output White-green Dry contact device level output Blue Dry contact device level output White-blue...

  • Page 73: Appendix A  Abbreviation

    Appendix A Abbreviation Access Control List DHCP Dynamic Host Configuration Protocol EPON Ethernet Passive Optical Network Fast Ethernet Gigabit Ethernet Internet Protocol Local Area Network MGCP Media Gateway Control Protocol Next Generation Network Optical Network Unit Power Distribution Panel Session Initiation Protocol Time Division Multiplex VLAN Virtual Local Area Network...
  • Page 75 Your feedback important receive questions, comments suggestions...ultimately providing you with enhanced manuals and services by FiberHome. Please give your opinions on the items listed below about this manual by the symbol “√”. Items Excellent Good Normal Expression Integrity Accuracy Structure...
