Replacing the Front Handle Set
3. Loosen and remove the 6 self tapping screws from the front handle.
4. Loosen the 4 hexagon socket screws with their washers at either side of the front handle set and
remove them.
5. Separate the front half from the rear half of the handle.
6pcs Self Tapping Screw
Description
Self Tapping Screw
Hexagon Socket Screw
Washer
4 Hexagon Socket Screws
Old Part Number New Part Number
5610032004
5620446003
5620446004
5650404001
HT5100E/HT6500E Hedge Trimmer
Qty
/ 6
4
/ 4
Rear Half Handle
Front Half Handle
