  • Page 1 EPTZ Educational Tracking Camera RGB3X-EPTZ-BK User Manual...

  • Page 2: Table Of Contents

    5.1 Contact us................................ 26 Chapter 5 Appendix..............................27 6.1 Specification..............................27 6.2 VISCA Protocol List............................28 6.2.1 Camera Return Command........................28 6.2.2 Camera Control Command........................28 6.2.3 Inquiry Command............................ 31 6.3 Pelco-D Protocol Command List........................33 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 3 6.4 Pelco-P Protocol Command List........................33 6.5 Terms & Definitions............................34 6.6 Revision History...............................39 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 4: Declarations

    RGBlink. If the purchaser or a third party carries out modifications or repairs on goods delivered by RGBlink, or if the goods are handled incorrectly, in particular if the systems are commissioned operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid.

  • Page 5: Installation Safety Summary

    If there is damage, notify the shipping carrier immediately for all claims adjustments. Site Preparation The environment in which you install your camera should be clean, properly lit, free from static, and have 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 6 Therefore, user should take corresponding measures. Caution If the power cord need to be extended, must only extend the cord connect to outlet 220V/110V. Do not extend the DC 12V power cord, otherwise malfunction could be caused. 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 7: Chapter 1 Your Product

    ● Multiple installation: Wall mount and in-ceiling mount for options. ● Networking control interface: Controlling via Network can meet different deployment of various scenarios. ● Wide application: Lecturer capture, remote interactive teaching etc. 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 8: Interface

    1.3 Interface 1. Camera Lens 5.SDI Interface 9. RS232/ RS485 2. Tripod Screw Hole 6. LAN Interface 10. Power Interface 3. Tripod Screw Hole 7. Reset button 11. Power Indicator 4. USB3.0 Interface 8. A-IN 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 9: Dimension

    1.4 Dimension 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 10: Chapter 2 Install Your Product

    The teaching tracking camera products provide a smart camera solution for education information field, and customers can select all or some products as needed. Different combinations of products meet the demands of customers’ in various scenarios. 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 11 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 12: Chapter 3 Use Your Product

    User can also to verify network connection as steps above mentioned after the finish of camera self-check. If IP is default, open DOS command window and input 192.168.5.163, then press Enter key, It will show the message as below, which means network connection is normal. 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 13: Browser Login

    PTZ control can be carried out, zoom, focus, video capture, sound, zoom, full screen and set the preset position, run, and delete; you can preview, playback and logout. Note: There are no configuration rights for normal user login. 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 14: Browser Configuration

    Rate (Kb/s): Set the video bit rate (close-up main stream default 4096Kb/s, 64-40960Kb/s optional; close-up sub-stream default 512Kb/s, 64-40960Kb/s optional; panoramic main stream default 4096Kb/s, 64-40960Kb/s 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 15 Brightness: Set the brightness value, active when it is a state of brightness priority (default 7, 0-23 optional). b. Color: White balance, saturation, color, white balance, sensitivity, color temperature, gain red and blue gain can be set. 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 16 Click on the "Save" button to display "Parameter saved successfully" message, set to take effect. 7) Video output Output format can be checked by on/off (default off) Output format: 1080P30, 1080P25, 1080I60, 1080I50, 720P60, 720P50 Click on the "Save" button, it will be valid when display "Save successful". 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 17: Network Configuration

    Local SIP Port: 5060 Range 0-65535 GB28181 Server Address: IP address of the computer Server SIP Port: 5060 Range 0-65535 Server ID: 34020000002000000001 Click on the "Save" button, it will be valid when display "Save successful". 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 18: System Configuration

    Choose one of the above three ways. The IP account and password of mode a are also restored to default. 5) Restore factory setting Click on pop-up "Restore Factory Defaults" button and choose “yes” or “no”, then the device will restart 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 19: Logout

    Set tracking parameters parameters Start tracking Start tracking 3.6.1 Teacher Tracking Configuration The following instructions are given in accordance with the setup flowchart. The main interface of teacher tracking configuration is shown in Figure below. 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 20 The operation interface for setting the preset position is shown in Figure below. By controlling the position and ZOOM value of the PTZ, the camera Angle and position are adjusted to the preset position and saved. The description of the preset position of the podium is as follows. 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 21 Panoramic preset: Control teacher tracking camera to allow camera to have almost a panoramic of the classroom (or any position). When tracking target disappears, it can select close-up lens to go back to panoramic position. 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 22 7. Advanced settings Target lost: This feature is to make sure that when the target lost, lens will return to the assigned preset. It has 2 modes for option: panoramic preset and close-up preset. 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 23 The higher the action sensitivity, the smaller movement of tracking target that will trigger camera’s tracking motion. Tracking speed: It means speed of tracking camera for horizontal tracking. 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 24: Description Of Recording And Broadcasting Host

    1. Configuration of recording and broadcasting host address If recording and broadcasting host uses LAN to receive action code, then it needs to configure host address by web browser. Click Advanced settings -> Server, as shown below: 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 25 2. Configuration of action code Modify action code as needed via web browser. Click Advanced settings -> action code; After modification, click save, as shown below: 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 26: Chapter 4 Ordering Code

    Chapter 4 Ordering Code 4.1 Product 981-0011-18-0 RGB3X-EPTZ-BK Educational Tracking Camera 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 27: Chapter 5 Support

    Chapter 5 Support 5.1 Contact us 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 28: Chapter 5 Appendix

    Power Adapter 0.42A(max) Input Current POE Supply 0.104A(max) Power Consumption 5W(max) Stored Temperature -10℃～+60℃ Stored Humidity 20%～95% Working Temperatur -10℃～+50℃ Working Humidity 20%～80% Dimension （WXHXD） 148.8mm×76mm×76mm Weight Around 0.53kg Application Indoor Accessory User Manual 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 29: Visca Protocol List

    8x 01 04 35 02 FF CAM_WB One Push mode 8x 01 04 35 03 FF 5000k 8x 01 04 35 04 FF Manual 8x 01 04 35 05 FF 6500k 8x 01 04 35 06 FF 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 30 4：0.63 8x 01 04 23 00 FF CAM_Flicker 50HZ 8x 01 04 23 01 FF 50HZ 60HZ 8x 01 04 23 02 FF 60HZ CAM_Aperture Reset 8x 01 04 02 00 FF Aperture Control 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 31 VV: Pan speed 0x01 (low speed) to Pan_tiltDrive Down 8x 01 06 01 VV WW 03 02 FF 0x18 (high speed) WW: Tilt speed 0x01 (low speed) to Left 8x 01 06 01 VV WW 01 03 FF 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 32: Inquiry Command

    50 00 00 00 0p FF p: WDR Strength CAM_NRLevel(2D) Inq 8x 09 04 53 FF y0 50 0p FF P: 2DNRLevel CAM_NRLevel(3D) Inq 8x 09 04 54 FF y0 50 0p FF P:3D NRLevel 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 33 P: 0~E Video format 0:1080P60 8:720P30 1:1080P50 9:720P25 2:1080i60 A： 1080P59.94 3:1080i50 B： VideoSystemInq 8x 09 06 23 FF y0 50 0p FF 1080i59.94 4:720P60 C： 720P59.94 5:720P50 D： 1080P29.97 6:1080P30 E： 720P29.97 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...

  • Page 34: Pelco-D Protocol Command List

    Pan Speed Tilt Speed 0xAF Upright 0xA0 Address 0x00 0x0A Pan Speed Tilt Speed 0xAF DownLeft 0xA0 Address 0x00 0x14 Pan Speed Tilt Speed 0xAF DownRight 0xA0 Address 0x00 0x12 Pan Speed Tilt Speed 0xAF 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 35 SMPTE ST-2081 released in 2015, 6Gbit/s bitrate and able to support 2160p@30. ●12G-SDI:standardized in SMPTE ST-2082 released in 2015, 12Gbit/s bitrate and able to support 2160p@60. ●U-SDI:Technology for transmitting large-volume 8K signals over a single cable. a signal interface called the ultra high 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 36 Telegraph and Telephone. SC is a push-pull coupling type of connector and has a 2.5mm diameter. Nowadays, it is used mostly in single mode fiber optic patch cords, analog, GBIC, and CATV. SC is one of the most popular options, as its 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 37 This includes film as well as video and television standards. ● Video Electronics Standards Association. An organization facilitating computer graphics through standards. VESA: ●HDCP: High-bandwidth Digital Content Protection (HDCP) was developed by Intel Corporation an is in wide use for 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 38 ●OSC: The principle of Open Sound Control (OSC) protocol is for networking sound synthesizers, computers, and multimedia devices for musical performance or show control. As with XML and JSON, the OSC protocol allows sharing 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 39 ●UHD: Standing for Ultra High Definition and comprising 4K and 8K television standards with a 16:9 ratio, UHD follows the 2K HDTV standard. A UHD 4K display has aphysical resolution of3840x2160 which is four times the area and twice both the width andheightofaHDTV/FullHD(1920 x1080) video signal. 厦门视诚科技有限公司 地址：厦门市火炬高新区创业园伟业楼 S601 网址：www.rgblink.com 电话：+86-0592-5771197 传真：+86-0592-5788216...
  • Page 40 All information herein is Xiamen RGBlink Science & Technology Co Ltd. excepting noted. is a registered trademark of Xiamen RGBlink Science & Technology Co Ltd.While all efforts are made for accuracy at time of print ing, we reserve the right to alter otherwise make change without notice.
