ABB CP405 Quick Start Manual page 4

1. Connect CP405/CP408 (5) with AC500-eCo (3). Pinning of TK407 (8) is shown below.
3
8
2. Connect CP405/CP408 (5) with PC (1).
3. Connect AC500-eCo (3) with PC (1) with TK504 (6).
4. Connect 24VDC power supply (2) to CP405/CP408 (5) and AC500-eCo (3).
Quickstart
COM1 of AC500-eCo
5
5
7
3
6
2
5
3
1
1
3
COM1 of CP405/CP408
CP405, CP408
