Summary of Contents for ABB CP450
- Page 1 CP450 Installation and Operation Manual English ABB, 1SBC159105M0202 2008-09...
- Page 2 Document number: ABB, 1SBC159105M0202 Please read the entire installation manual prior to installing and using this equipment. Only qualified personnel may install, operate or repair this equipment. ABB is not responsible for modified, altered or renovated equipment. Because the equipment has a wide range of applications, users must acquire the appropriate knowledge to use the equipment properly in their specific applications.
-
Page 3: Table Of Contents
System Menu ................18 Key Pad..................19 Bench and Function Tests ............20 Setting Communication Parameters ........... 20 Downloading an Application ............. 21 Uploading an Application ............22 Uploading/Downloading a Recipe ..........23 Copying an Application ............. 24 7.10 Passwords................... 25 ABB, 1SBC159105M0202... - Page 4 Contents ABB, 1SBC159105M0202...
-
Page 5: Safety Precautions
– The supplier neither guarantees that the operator terminal is suitable for your particular application, nor assumes responsibility for your product design, in- stallation or operation. ABB, 1SBC159105M0202... -
Page 6: During Use
Dismantling and Scrapping – The operator terminal or parts thereof shall be recycled according to local regulations. – The following components contain substances that might be hazardous to health and the environment: lithium battery, electrolytic capacitor and display. ABB, 1SBC159105M0202... -
Page 7: Installation
Installation Installation Package Contents The following parts are found in the box: – Operator terminal CP450 – 8 installation fasteners – Power connector (connected to the 24 V DC power input) – Installation and operation manual (1SBC159105M0202) ABB, 1SBC159105M0202... -
Page 8: Product Specifications
Product Specifications Product Specifications Parameter CP450 T CP450 T-ETH Front panel, W x H x D 297.0 x 222.0 x 9.0 mm Mounting depth 51.6 mm Cut-out dimensions 286.0 x 211.0 mm Front panel protection IP 65/NEMA 4X (indoor use only) Weight 1.9 kg... -
Page 9: Description Of Parts
Fixture mounting holes Function keys Power lamp Communication lamps Network lamp Display Back DC power input COM1: RS232/RS485 Compact Flash card connection COM2: RS232/RS422/RS485 DIP switches (1-12) USB port for printer/memory stick COM3: RS422/RS485 Network connection USB port for transmission ABB, 1SBC159105M0202... -
Page 10: External And Cut-Out Dimensions
Product Specifications External and Cut-out Dimensions Unit: mm Cutout dimension Mounting Procedure 1. Cut out the control front panel to match the dimensions (mm) below. ABB, 1SBC159105M0202... -
Page 11: Grounding
3. The operator terminal is to be installed within the angle of 0 to 135 shown below. Grounding To make sure that the operator terminal works properly and to prevent it from radiating radio frequency noise, it must be connected to the earth ground. ABB, 1SBC159105M0202... -
Page 12: Power Supply And Wiring
Product Specifications Power Supply and Wiring CP450 must use the power supply with 24 V DC and the power consumption is 30W. Warning: To avoid an electrical shock, be sure to switch off the power before connecting the communication/download cable to the operator terminal. -
Page 13: Dip Switches
For RS485, this switch has to be set ON. For RS422, this switch has to be set OFF. SW11 COM3 Port For RS485, this switch has to be set ON. For RS422, this switch has to be set OFF. SW12 Reserved ABB, 1SBC159105M0202... -
Page 14: Communication Ports
Switches. Function Function RS485+ RS422 TX+ (RS485+) RS232 RXD RS422 CTS+ RS232 TXD RS422 CTS- RS422 RX+ Signal ground Signal ground RS485- RS422 TX- (RS485-) RS232 RTS RS422 RTS+ RS232 CTS RS422 RTS- Optional; RS422 RX- +5V@100mA output ABB, 1SBC159105M0202... - Page 15 18 17 16 15 14 Function Function RS422 TX+ (RS485+) RS232 TXD RS422 TX- (RS485-) RS232 RXD RS422 RX+ RS232 RTS RS422 RX- RS232 CTS Signal ground Optional; +5V@100mA output RS422 RTS+ RS422 RTS- RS422 CTS+ RS422 CTS- ABB, 1SBC159105M0202...
-
Page 16: Touch Screen Calibration
2. Follow the route on the screen. 3. Touch the square on the center of the screen to complete the task. Note: When using the F4 - Set command all RAM data will be cleared. See also section 7.2 System Menu. ABB, 1SBC159105M0202... -
Page 17: Operation
After downloading again, all items should pass the self-test. Note: When using the operator terminal for the first time, remember to reset the real time clock (RTC). ABB, 1SBC159105M0202... -
Page 18: System Menu
+ and - to set the value of the field. F3 - Copy Copies application data to another CP450. F4 - Set Calibrates the touch screen and clears RAM data. See also section 6 Touch Screen Calibration. -
Page 19: Key Pad
Operation Key Pad The eight keys on the CP450 include one menu key and seven functional keys (F1-F7), described below. Press the menu key to slide out the innovative slide- out menu. The functional keys can also be defined in CP400Soft and used as “Quick- buttons”, for example, to set an ON/OFF value, to change a screen etc. -
Page 20: Bench And Function Tests
Bench and Function Tests Set dip switches SW3 and SW4 = OFF to be able to run the bench and function tests for the CP450. Turn on the operator terminal to display the following screen: The bench test performs an overall hardware test, and the function test lets the user select which item to be tested. -
Page 21: Downloading An Application
Operation Downloading an Application Connect the RS232 port on the PC to the COM1 port on the CP450 using a TK401 cable, or to the COM2 port using a TK402 cable. The connection can also be made according to the illustration below, where the... -
Page 22: Uploading An Application
Save As to save the application as a *.V6F file. Thus a source file can serve the purposes of maintenance and modification. Note: When uploading for the first time, make sure to first run the application once, or else the upload function will not work. ABB, 1SBC159105M0202... -
Page 23: Uploading/Downloading A Recipe
Also remember to upload the format of recipes from the operator terminal before starting to edit a new set of recipe data in the PC. For further information about creating/editing recipes, please see the corre- sponding chapter in the CP400Soft User’s Manual. ABB, 1SBC159105M0202... -
Page 24: Copying An Application
Operation Copying an Application To copy an application from one CP450 to another CP450, select F3 - Copy from the system menu. Set the dip switch SW7 = ON and connect the two op- erator terminals with a download cable. After the self-test, the system menu will be displayed on the screen. -
Page 25: 7.10 Passwords
2. User level 1 has the highest privilege and User level 9 has the lowest. Note: Only users of User Level 1 has the right of access to the password table. ABB, 1SBC159105M0202... - Page 26 When selecting F3 - Copy in the system menu or File/Upload Application in CP400Soft, the operator terminal will prompt for a password. The user will need to enter the correct password to copy an application from one CP450 to another. Note that setting this password is different from the passwords set in Scenarios 1-3.
- Page 27 ABB FRANCE ABB STOTZ-KONTAKT GmbH Division Automation Products Po Box 10 16 80 Export Department 69006 Heidelberg 10 rue Ampère Germany 69685 Chassieu Tel. : +49 (0) 6221/701-1190 France Fax. : +49 (0) 6221/701-1333 Tel. : +33 (0) 4 72 22 17 22 Fax.
