Summary of Contents for Smithco V62-V
- Page 1 Parts & Service V62-V Turf Vac 78-500 SN:VAC101 November 2017 Product Support: Hwy SS & Poplar Ave; Cameron WI 54822 1-800-891-9435 productsupport@smithco.com...
-
Page 2: Table Of Contents
INTRODUCTION Introduction ...................1-3 Safe Practices ................2 Specifications ................3 Service ..................4-11 Maintenance ................4-6 Overloading Debris Hopper and Vacuum Housing Wear .... 7 Service Chart ................8-9 Adjustments ................10 Tailgate Adjustments ..............11 Storage ..................11 Diagrams ..................12-13 Wiring Diagram ..............12-13 Parts ...................14-31 Body and Frame ..............14-15 Engine and Guards ...............16-17... -
Page 3: Introduction
All Smithco machines have a Serial Number and Model Number. Both numbers are needed when ordering parts. Refer to engine manual for placement of engine serial number. For product and accessory information, help finding a dealer, or to register your product please contact us at www.Smithco.com. -
Page 4: Safe Practices
17. Stop engine before making repairs/adjustments or checking/adding oil to the crankcase. 18. Use parts and materials supplied by SMITHCO only. Do not modify any function or part. 19. Do not remove the radiator cap when the engine is hot. When cooled, loosen cap slightly to the stop to relieve any pressure before removing the cap completely. -
Page 5: Specifications
SPECIFICATIONS FOR TURF VAC WEIGHTS AND DIMENSIONS Length 151" (384 cm) Width 68" (172 cm) Height 87" (221 cm) Weight 1500 lb (680 kg) SOUND LEVEL At ear level ENGINE Make Briggs &Stratton Model# 386447 Type/Spec 0410-G1 Horsepower 23 Hp (17 kW) Fuel Unleaded 87 Octane Gasoline Minimum... -
Page 6: Service
MAINTENANCE Before servicing or making adjustments to machine, stop engine and remove key from ignition. Use all procedures and parts prescribed by the manufacturer's. Read the engine manual before operation. LUBRICATION Use No. 2 General Purpose Lithium Base Grease and lubricate daily. The Turf Vac has fifteen grease fittings. All bearings are sealed bearings. - Page 7 MAINTENANCE (CONTINUED) TIRE PRESSURE Caution must be used when inflating a low tire to recommended pressure. Over inflating can cause tires to explode. Tires on the machine should be 18 psi (1.3 bar), castor wheels should be 18 psi (1.3 bar). Improper inflation will reduce tire life considerably.
- Page 8 MAINTENANCE (CONTINUED) BATTERY Batteries normally produce explosive gases which can cause personal injury. Do not allow flames, sparks or any ignited object to come near the battery. When charging or working near battery, always shield your eyes and always provide proper ventilation. Battery cable should be disconnected before using “Fast Charge”.
-
Page 9: Overloading Debris Hopper And Vacuum Housing Wear
40 in. (101 cm) VACUUM HOUSING WEAR Smithco Vacs are fitted with a wear resistant liner in the vacuum housing. This will provide additional housing life. Be sure the following points are explained to the user: 1. The vacuum housing and impeller must be cleaned each time the unit is used so the housing liner is inspected daily. -
Page 10: Service Chart
SERVICE CHART Before servicing or making adjustments to the machine, stop engine, set park break, block wheels and remove key from ignition. Follow all procedures and ONLY use parts prescribed by the manufacturer. Read the engine manual before maintenance. The suggested maintenance checklist is not offered as a replacement for the manufacturer’s engine manual but as a supplement. - Page 11 SERVICE CHART DUPLICATE THIS PAGE FOR ROUTINE USE Maintenance Check Item For the week of: Tues. Wed. Thurs. Fri. Sat. Sun. Check the fuel level Check the engine oil level. Check the condition of the air filter Clean the engine cooling fins. Check for unusual engine noises Check the tire pressure (18 psi) Check the Instrumentation...
-
Page 12: Adjustments
ADJUSTMENTS ADJUSTMENT OF BELT TENSIONER The belt tensioner controls the tension on the belt from the engine to blower shaft. The proper tension of the idler should be in the second notch on the side of the tensioner. Over tightening the belt will shorten the life of the belt and the machine may not perform to the best of its ability. -
Page 13: Tailgate Adjustments
TAILGATE ADJUSTMENT VAC TAILGATE LEVELING If the tailgate is not sitting level against the hopper it can be leveled by loosening the inch Hex Bolts that hold the pivot bracket to the upper lift arms then rotate the pivot brackets until tailgate level then tighten. Once it is level it must be readjusted using steps 1, 2 and 3. -
Page 14: Diagrams
WIRING DRAWING... - Page 15 WIRING PARTS LIST REF# PART# DESCRIPTION QUANTITY 30-187 KYB Hyd/Elec Actuator 22-054 Battery Cable Black 78-325 Red Battery Cable with Boot 22-073 Battery (optional) 78-493 Briggs & Stratton 23HP Engine 13-488 Key Switch 77-261 40AMP Breaker 8977 Circuit Breaker Boot 17-527 Rocker 17-528...
-
Page 16: Parts
BODY AND FRAME DRAWING... - Page 17 BODY AND FRAME PARTS LIST REF# PART# DESCRIPTION QUANTITY 42-202 Castor Wheel 42-202-01 Tire, 9 x 3.5 x 4 42-202-02 Wheel 78-257 Vacuum Housing 78-269 Right Brush Guard HB-516-18-075 Hex Bolt, -18 x HNTL-516-18 Nylon Lock Nut, - 18 78-221 Tire and Wheel 78-221-01 Tire, 24 x 13 -12 6 Ply...
-
Page 18: Engine And Guards
ENGINE AND GUARDS DRAWING... - Page 19 ENGINE AND GUARDS PARTS LIST REF# PART# DESCRIPTION QUANTITY 78-240 Jack 77-261 40Amp Circuit Breaker 8977 Circuit Breaker Boot 18-220 Muffler Clamp 78-493 Briggs & Stratton 23HP Engine HB-516-18-125 Hex Bolt, - 18 x 1 HW-516 Flat Washer, HNTL-516-18 Nylon Lock Nut, 78-339 Left Side Guard HSD-8-50...
-
Page 20: Tensioner Pulley
TENSIONER PULLEY DRAWING... - Page 21 TENSIONER PULLEY PARTS LIST REF# PART# DESCRIPTION QUANTITY 78-493 Briggs & Stratton 23HP Engine 78-429 Hub, 1" 78-424 Pulley HB-38-16-300 Hex Bolt, -16 x 3 HWL-38 Lock Washer, 78-449 Main Frame 16-990 Spacer 16-016 Idler Pulley HB-38-16-200 Hex Bolt, - 16 x 2 HW-38 Flat Washer, HWL-38-16...
-
Page 22: Blower Housing
BLOWER HOUSING DRAWING... - Page 23 BLOWER HOUSING PARTS LIST REF# PART# DESCRIPTION QUANTITY 78-440 Door Pivot HSTP-14-20-075 Phillips Truss Head Machine Screw, - 20 x HSTP-14-20-100 Phillips Truss Head Machine Screw, - 20 x 1 HNTL-14-20 Nylon Lock Nut, - 20 HWF-14-150 Fender Washer, 78-439 Trap Door 78-403 Trap Door Lining...
-
Page 24: Gas Tank
GAS TANK DRAWING... - Page 25 GAS TANK PARTS LIST REF# PART# DESCRIPTION QUANTITY 78-269 Right Brush Guard HBFL-516-18-075 Flange Whiz-loc Bolt, - 18 x HNFL-516-18 Nylon Lock Nut, 78-458 Tank Brace HB-14-20-075 Hex Bolt, - 20 - HNTL-14-20 Nylon Lock Nut, - 20 78-455 Tank Bracket HB-516-18-100 Hex Bolt, - 18 x 1...
-
Page 26: Vacuum Head
VACUUM HEAD DRAWING... - Page 27 VACUUM HEAD PARTS LIST REF# PART# DESCRIPTION QUANTITY HB-38-16-250 Hex Bolt, - 16 x 2½ HW-38 Flat Washer, HNTL-38-16 Nylon Lock Nut, - 16 78-241 Chain Connector 8820-8 Machine Chain Straight Link HCP-34-250 Clevis Pin, HHP-18 Bridge Pin, 78-449 Main Frame HMB-58-14 Machine Bushing, x 14GA...
-
Page 28: Hopper
HOPPER DRAWING... - Page 29 HOPPER PARTS LIST REF# PART# DESCRIPTION QUANTITY HSD-8-075 Pan Head Drill Screw, #8 x 8946-42 Wear Strip, 42" 78-385 Wear Strip Bracket 78-383 Left Hopper 78-264 Left Door Arm 78-382 Screen HB-14-20-125 Hex Bolt, - 20 x 1 HNFL-14-20 Flange Whiz-loc Nut, - 20 78-386 Hopper Filter...
-
Page 30: Tailgate
TAILGATE DRAWING... - Page 31 TAILGATE PARTS LIST REF# PART# DESCRIPTION QUANTITY 78-266 Hopper Door HNFL-12-13 Flange Whiz-loc Nut, - 13 HW-12 Flat Washer, HB-12-13-250 Hex Bolt, - 13 x 2 78-319 Tailgate Adjustment 78-305 Filter Insert 78-272 Hopper Cover HBFL-516-18-075 Flange Whiz-loc Bolt, - 18 x HNFL-516-18 Flange Whiz-loc Nut, - 18...
-
Page 32: Rear Axle
REAR AXLE PARTS LIST... - Page 33 REAR AXLE PARTS LIST REF# PART# DESCRIPTION QUANTITY 80-167 Grease Cap HNAR-100-14 Slotted Jam Nut ,1 - 14 HP-18-200 Cotter Pin, HNL-12-20 Lug Nut, - 20 78-216-01 Hub Assembly (includes all * items) 78-216 Axle Complete 2000# HB-12-13-150 Hex Bolt, -13 x 1 HW-12 Flat Washer,...
-
Page 34: Accessories
78-208 FILTER SYSTEM DRAWING 78-208 FILTER SYSTEM PARTS LIST REF# PART# DESCRIPTION QUANTITY 78-288 Filter Case 78-328 Filter... -
Page 35: Decal List
DECALS REF# PART# DESCRIPTION QUANTITY 25-286 Decal, Pinch Point 25-363 Decal, Maximum Depth 78-535 Decal V62-V Turf Vac 25-372 Decal, Smithco Star 25-359 Decal, Smithco 25-298 Decal, Warning Hot 16-088 Decal, Moving Parts 25-305 Decal, Rotating Parts Serial Tag 25-355... -
Page 36: Reference
QUICK REFERENCE REPLACEMENT FILTERS 50-403 In-Line Fuel Filter 76-487 Engine Oil Filter Briggs & Stratton # 842921 REPLACEMENT BELTS 78-494 3-V Belt FLUIDS Engine Oil SAE 10W-40 API Service SJ or higher Motor Oil... -
Page 37: Warranty
30 days from discovery of the condition. If you need help locating an Authorized Smithco Distributor, or if you have questions regarding your warranty rights or responsibilities, you may contact us at: Smithco Product Support Department 200 West Poplar Ave. - Page 38 This warranty does not apply to normal “wear and tear” items. Normal “Wear and Tear” includes, but is not limited to, damage to seats due to wear or abrasion, worn painted surfaces, scratched decals or windows, etc. Smithco may require the return of failed parts or components in order to determine the validity of any warranty claim.
