- Page 1 SOLPORT Wall Pack Lights Installation Manual SOLTECH Provides Advanced LED Technology Powered With Eco-friendly, Clean, Solar Energy.
- Page 2 Important Notice & Warning Please read these instructions before installation to ensure optimum results 1. The SOLPORT will provide optimal usage where there is LED Nominal Power and longevity of your lights. The solar panel should be charged in full enough sunshine.
- Page 3 03 Installation WALL MOUNT Secure the screw into the side of the mouting plate. Drill 4 holes of ø8mm with Use screwdriver to secure the Aim the light in the desired depth 60–65mm on the wall. mounting plate on the wall direction and slide it down to with screws.
- Page 4 04 Remote Control 1. On / Off 2. Constant Lighting Mode On / Off With memory of previous mode before shut off. The light will automatically turn on at dusk and remain at 50% brightness when the motion sensor is disabled. After 5 hours or when the battery capacity is below 30%, the light will switch to Constant Mode 3.
- Page 5 05 Panel Angle 70° N 69° N 68° N 67° N The Solar charge in a battery pack won’t last forever. The off–grid system 66° N relies on stored solar energy for autonomy. Angling your solar panels 65° N properly can boost the power intake of your solar lighting system. You want to angle your solar panels at a tilt based on the area’s latitude.
- Page 6 06 Luminous Distribution 07 Warranty SOLPORT 15W SOLPORT is covered by a 3 year limited warranty. SOLPORT urban light warrants to the original purchaser that this Lamp=1 434.6 lm Type C Max=460.3 cd/klm product is free from defects in materials and workmanship Power=16 W Multiplier=1.4346...
- Page 7 1460 Park Avenue. Emeryville, CA 94608 USA www.soltechlighting.com SOLTECH LLC reserves the right to update all product data sheets at any time. Consult SOLTECH marketing specialists for publication updates at Copyright©2021–2022 SOLTECH LLC, hello@soltechlighting.com All Rights Reserved.
