- Page 1 BEACON Solar Powered LED Traffic Sign Light 12" 6W (Single-head) 8" 3.6W (Single-head) 8" 7.2W (Dual-head) Installation Manual SOLTECH Provides Advanced LED Technology Powered With Eco-friendly, Clean, Solar Energy.
- Page 2 Notice & Warning results and longevity of your lights. The solar panel should be charged in full 1. The BEACON will provide optimal performance where there is sunlight for 8 to 9 hours before initial first use to provide optimum results.
- Page 3 0.7 inches 14.0 inches ø12.0 inches 14.0 inches ø8.0 inches 0.7 inches 0.7 inches 13.9 inches ø8.0 inches...
-
Page 4: Installation
02 Installation 8" and 12" Single-head Check List 1. Roll up the light cover. Use 1. Solar Panel (X1) the light cover screw kit to 2. Light (X1) secure the cover on the light. 3. Screw Kit (X1) 2. Install the light by screwing 4. - Page 5 8" Dual-head Check List 1. Roll up the light cover. Use 1. Solar Panel (X1) the light cover screw kit to 2. Light (X2) secure the cover on the light. 3. Screw Kit (X2) 2. Install the light by screwing 4.
-
Page 6: Specification
03 Specification Specifications BEACON 12” Single-head BEACON 8” Single-head BEACON 8” Dual-head LED Nominal Power 3.6W 7.2W Solar Panel Mono-Crystalline 18V 10W Mono-Crystalline 18V 10W Mono-Crystalline 18V 12W LiFePO Battery 12V 8.8Ah 12V 8.8Ah 12V 8.8Ah Light Color Yellow/Red Yellow/Red... - Page 7 04 Ordering Information Chart WORKING MODE OPERATION MODE SERIES LIGHT HEAD COLOR (For Dual-Head Only) STL-BCN=BEACON S8D=8” Single-head YL=Yellow 24=24Hours & 7Days S=Synchronous S12D=12” Single-head RD=Red 12=12Hours & 7Days A=Asynchronous D8D=8” Dual-head...
- Page 8 70° N 69° N 68° N 67° N 66° N 65° N 64° N 63° N 62° N 60° Alaska 61° N 60° N 49° N 48° N Washington 47° N 46° N Montana 45° N North Dakota Oregon 44° N Minne Idaho 43°...
- Page 9 05 Panel Angle The solar charge in a battery pack won’t last forever. The off–grid system relies on stored solar energy for autonomy. Angling your solar panels properly can boost the power intake of your solar lighting system. You want to angle your solar panels at a tilt based on the area’s latitude. You can increase the tilt 15°...
-
Page 10: Warranty
06 Warranty BEACON is covered by a 3 year limited warranty. SOLTECH urban light warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 3 years from date of purchase. To obtain warranty service please contact your local distributor or sales rep for further instruction. - Page 11 SOLTECH Provides Advanced LED Technology Powered With Eco-friendly, Clean, Solar Energy.
- Page 12 1460 Park Avenue. Emeryville, CA 94608 USA www.soltechlighting.com SOLTECH LLC reserves the right to update all product data sheets at any time. Consult SOLTECH marketing specialists for publication updates at Copyright©2021–2022 SOLTECH LLC, hello@soltechlighting.com All Rights Reserved.
