Soltech SOLPORT Installation Manual

Wall pack lights
Hide thumbs Also See for SOLPORT:
Table of Contents

Advertisement

Quick Links

Download this manual
SOLPORT
Wall Pack Lights
15W
Installation Manual
SOLTECH Provides Advanced LED
Technology Powered With Eco-friendly,
Clean, Solar Energy.
01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SOLPORT and is the answer not in the manual?

Questions and answers

Related Manuals for Soltech SOLPORT

Summary of Contents for Soltech SOLPORT

  • Page 1 SOLPORT Wall Pack Lights Installation Manual SOLTECH Provides Advanced LED Technology Powered With Eco-friendly, Clean, Solar Energy.
  • Page 2 Important Notice & Warning Please read these instructions before installation to ensure optimum results 1. The SOLPORT will provide optimal usage where there is and longevity of your lights. The solar panel should be charged in full enough sunshine. sunlight for 8 to 9 hours before initial first use to provide optimum results.

  • Page 3: Specification

    02 Specification Specifications SOLPORT 15W LED Nominal Power Solar Panel Mono-Crystalline 10V 7.3W Lithium Ion Battery 40WH 7.4V 5.4AH 4,000K & 5,000K Lumen Output@4000K 1,500 > 70 Product Size 10.2 X 12.2 X 5.1 Inches 80° X 100° Beam Angle Solar Panel Angle 70°...

  • Page 4: Installation

    03 Installation WALL MOUNT Drill 4 holes of ø8mm with Use screwdriver to secure the depth 60–65mm on the wall. mounting plate on the wall with screws.
  • Page 5 Secure the screw into the side of the mouting plate. Aim the light in the desired direction and slide it down to lock it.

  • Page 6: Remote Control

    04 Remote Control Constant ON/OFF Lighting Mode Full Full Bright & Dim Bright & Off Please press any button on the lamp first to activate the lamp and remote control. IR Remote Control Control distance: ≤ 12 Meters...
  • Page 7 1. On / Off 2. Constant Lighting Mode On / Off With memory of previous mode before shut off. The light will automatically turn on at dusk and remain at 50% brightness when the motion sensor is disabled. After 5 hours or when the battery capacity is below 30%, the light will switch to Mode 3.
  • Page 8 70° N 69° N 68° N 67° N 66° N 65° N 64° N 63° N 62° N 60° Alaska 61° N 60° N 49° N 48° N Washington 47° N 46° N Montana 45° N North Dakota Oregon 44° N Minne Idaho 43°...
  • Page 9 05 Panel Angle The solar charge in a battery pack won’t last forever. The off–grid system relies on stored solar energy for autonomy. Angling your solar panels properly can boost the power intake of your solar lighting system. You want to angle your solar panels at a tilt based on the area’s latitude. You can increase the tilt 15°...
  • Page 10 06 Luminous Distribution SOLPORT 15W Lamp=1 434.6 lm Type C Max=460.3 cd/klm Power=16 W Multiplier=1.4346 Degrees=0 Point 0x0x0 mm A. Legotin (C) 2004 IES Viewer v2.99n...

  • Page 11: Warranty

    07 Warranty SOLPORT is covered by a 3 year limited warranty. SOLTECH urban light warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 3 years from date of purchase. To obtain warranty service please contact your local distributor or sales rep for further instruction.
  • Page 12 1460 Park Avenue. Emeryville, CA 94608 USA www.soltechlighting.com SOLTECH LLC reserves the right to update all product data sheets at any time. Consult SOLTECH marketing specialists for publication updates at Copyright©2021–2022 SOLTECH LLC, hello@soltechlighting.com All Rights Reserved.
