Page 1
COSMO Flood Lights 20W 50W Installation Manual SOLTECH Provides Advanced LED Technology Powered With Eco-friendly, Clean, Solar Energy.
Page 2
01 Introduction Thank you for purchasing COSMO Urban Lighting Products. Important Activation Please read these instructions before installation to ensure optimum results Press and Hold the button located in the image and longevity of your lights. The solar panel should be charged in full to the right to activate the light.
Page 3
02 Specification Specifications COSMO 20W COSMO 50W LED Nominal Power Solar Panel Mono-Crystalline Silicon 14V 5W Mono-Crystalline Silicon 14V 10W Lithium Ion Battery 28.86WH 3.7V 2.6AH 57.72WH 3.7V 2.6AH 4,000K 4,000K Lumen Output@4,000K 3,000 6,000 > 70 > 70 Solar Panel 8.0 X 7.1 Inches Solar Panel 15.0 X 7.3 Inches...
Page 4
03 Installation WALL MOUNT Package Contents 1. Lamp (with bracket) 2. Solar Panel 3. Bracket for Solar Panel 4. Remote Control 5. Expansion pillar-hinge (4pcs) 6. Small Gasket (4 pcs) 7. Screw PA4*25 (4 pcs) 8. Large Gasket (2 pcs) 9.
Page 5
OPERATING MODES 50% 5Hrs + 10% Till Dawn 50% 5Hrs + 10% Till Dawn 30% 5Hrs + 10% Till Dawn 30% 5Hrs + 10% Till Dawn 20% Till Dawn 20% Till Dawn 100% 2Hrs + 50% 5Hrs + 100% 2Hrs + 50% 5Hrs + 10% Till Dawn 10% Till Dawn 100% 2Hrs + 30% 5Hrs +...
Page 7
05 Warranty COSMO is covered by a 3 year limited warranty. SOLTECH urban light warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 3 years from date of purchase. To obtain warranty service please contact your local distributor or sales rep for further instruction.
