PRODUCT OVERVIEW
7
2
1 Pressure supply inlet
2 Pressure supply transmission
3
Operation window
4 Pause button
5 Interface buttons
6 Rotative dial
7 Power and data transmission
8
microfluidic valve ports
9 Unlock button
used with pressure controllers
displays connected valves and positions
used to program several orders and set them simultaneously
to set the valves positions and validate/deny orders
to navigate and to select the valve on which operate
to power and control the connected valves
press it to separate a LineUp module from another
used with pressure controllers
used for multi-channel configuration
