SOFTWARE CONTROL
Here are examples of MAT protocols to have an overview of the
specific functions of each Fluigent microfluidic valve.
In this protocol, the
1 min 30 sec, and toggle position again.
In this protocol, the
30 sec, and toggle position again.
20
2-SWITCH will toggle position, then wait for
TM
L-SWITCH will toggle position, then wait for
TM
In this protocol, the
M-SWITCH
is set to
TM
rotate with the shortest
path. The valve is set
on position 1, wait for
2 min, and will rotate
until position 7. (The
r o t a t i o n d i r e c t i o n
can be clockwise or
anticlockwise.)
