Local control

Fluigent microfluidic valves can be actuated without a PC by using
the SWITCH EZ local control. Once a valve is connected to a port, its
information is displayed on the module and one can control it directly.
2-SWITCH
TM
14
When a valve is
connected, on
the screen will
be displayed the
name and current
in position 1
If no microfluidic valve is
connected to the
the operation window will be
splitted in 8 sections (6 for each
port, 2 for each button action)
but no valve information is
displayed.
position.
MANUAL USE
SWITCH
2-SWITCH in position 2
TM
EZ,
