GIT G-scan3 G3 Troubleshooting Manual page 58

GIT-EZDS AFTERMARKET DISTRIBUTORSHIP MANUAL
TROUBLE SHOOTING GUIDE
② Check MIC & Speaker connection
1. Perform visual inspection in LAN socket for damage.
2. Check if the LED light at the top is illuminating after connecting LAN wire.
3. Check if G-scan3 is connected to internet.
(Check for Internet icon located at the top of the screen or go to settings-more-Ethernet)
 If internet connection cannot be made, replace the main board.
th
Feb 19 , 2019
FIRST EDITION
MIC connector
Speaker
connector
GIT-EZDS
AFTERMARKET DISTRIBUTORSHIP MANUAL
Audio Problems
58
