Pre-assembly

PLANNING ASSEMBLY

Keep children and pets away from build area. Make sure your area is large enough to unpack,sort and assemble the unit.

TOOLS REQUIRED

Small head
Phillips
screwdriver
(Not Included)

HARDWARE INCLUDED

NOTE: Hardware not shown to actual size.
AA
GG
(1)X4
Part Description
Cam lock
AA
BB Cam lock bolt
CC Hexagon socket bolt
DD Flat gasket
EE
Spring washer
FF
Layer shelf support
Cross round head bolt
GG
Handle
HH
Large head
Phillips
screwdriver
(Not Included)
BB CC
HH
II
(2)X2 (3)X2
Quantity
14+2
14+2
6
6
6
8
3
3
OO
DD
JJ
KK
(4)X2
Part Description
II Magnetic clamp
JJ
Flat head screw
KK
Round head screw
LL
L shaped bracket
Thread hole cover
MM
NN
Anti-tipping hardware package
OO Spanner
3
Please contact 1-800-986-3460 for further assistance.
EE FF
LL
MM
(5)X2
Quantity
3
24+2
22+2
3
2
1
1
HOMEDEPOT.COM/HOMEDECORATORS
NN
