BRADSTONE 3 DRAWER LATERAL FILE CABINET
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this Bradstone 3
Drawer Lateral File Cabinet. We strive to continually create quality products designed to enhance your home. Visit us online to
see our full line of products available for your home improvement needs. Thank you for choosing Home Decorators Collection!
USE AND CARE GUIDE
Questions, problems, missing parts? Before returning to the store,
call Home Decorators Collection Customer Service.
HOMEDEPOT.COM/HOMEDECORATORS
1-800-986-3460
THANK YOU
Item # 1005559735
Model # JS-3419-A
Item # 1005535046
Model # JS-3419-C
Advertisement
Table of Contents
Related Manuals for Home Decorators Collection BRADSTONE JS-3419-A
Summary of Contents for Home Decorators Collection BRADSTONE JS-3419-A
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Home Decorators Collection through the purchase of this Bradstone 3 Drawer Lateral File Cabinet. We strive to continually create quality products designed to enhance your home. Visit us online to...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............... 2 Pre-assembly (continued) ..........4 Safety Information .............. 2 ............4 Package Contents Pre-assembly ............... 3 Notification ................5 ............3 Planning Assembly Assembly ................ 6-11 ..............3 Maintenance ..............12 T ools R equired Care and Cleaning ............12 ............ -
Page 3: Pre-Assembly
Pre-assembly PLANNING ASSEMBLY Keep children and pets away from build area. Make sure your area is large enough to unpack, sort and assemble the unit. TOOLS REQUIRED Small head Large head Phillips Phillips screwdriver screwdriver (Not Included) (Not Included) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. -
Page 4: Pre-Assembly (Continued)
Pre-assembly (continued) PACKAGE CONTENTS Part Description Part Description Quantity Quantity Back panel Top panel Drawer back panel Left side panel Right side panel Drawer left side panel Vertical Partition Drawer right side panel Drawer bottom panel Horizontal Partition Bottom panel Drawer front panel Metal bar Bottom apron... -
Page 5: Notification
Notification NOTE: UPON OPENING THOROUGHLY CLEAN ALL WOODS SURFACES TO REMOVE DUST AND DIRT THAT MAY HAVE SETTLED ONTO FINISH DURING SHIPMENT. IN ORDER TO PREVENT DAMAGE DURING ASSEMBLY, PLEASE ASSEMBLE THIS ITEM WITH AT LEAST TWO PEOPLE. NOTE:TURN THE CAM-BOLT SCREWS UNTIL THEY SHOULDER ARE TIGHT,THE SHOULDER SHOULD BE AGAINST THE SURFACE OF THE PART. -
Page 6: Assembly
Assembly Assemble drawers d) Insert wood dowel(CC) into panel(J&K), then rotate the cam lock(DD) tight to assemble panel(J&K) and panel(M). a) Insert wood dowel(CC) into panel(I) ,then assemble panel(I) and panel(J&K) by rotating the flat head screw(HH). e) Install the metal bar(N) b) Insert the panel(L) into the slot correctly. - Page 7 Assembly Assemble Horizontal Partition a) Screw the Big cam lock bolt (BB) into c) Fix the Partitions with Big cam lock (AA). the Horizontal Partition (E) b) Connect the Partitions (D & E). (Follow the arrow directions to assemble the Partitions) Big cam lock Big cam lock bolt Large head...
- Page 8 Assembly Assemble side panel(B/C) a) Screw the Big cam lock bolt (BB) into the c) Align and join the panel to pre-drilled holes. Side panels ( B&C ). d) Tighten all the Big cam locks and Allen screws. b) Fix the L shaped bracket (JJ) to bottom apron(G) with Allen Screw (KK).
- Page 9 Assembly Assemble top panel(A) & Back panel (H) c) Tighten all the Big cam locks (AA). a) Screw the Big cam lock bolt (BB) into the Top panel ( A ). b) Align and join the panel to pre-drilled holes. d) Insert the round head screw (II) to the back panel (H) via back panel holes.
- Page 10 Assembly lnserting the drawer lnsert the drawer into the assembled body as shown. 1.Pull out slide. Slide bearings forward. 2.Push slide back inside. 3.Insert into slide slot Repeat for every slide! correctly, push the drawer into the cabinet body with even force NOTE: Make sure the slide piece is at the front end of the glide when installing the drawer into the body.
- Page 11 Assembly Finalizing the assembly a) Install anti-tipping hardware Package(NN) as b) Connect plastic strip(4) with anti-tipping hardware. illustration below. wall Rectangle 1.97 in.Round 0.63 in.Round Plastic band Plastic anchor metal plate head screw head screw Small head (1)X4 (2)X2 (3)X2 (4)X2 (5)X2 HOMEDEPOT.COM/HOMEDECORATORS...
-
Page 12: Maintenance
Maintenance □ If your furniture is stained or otherwise damaged during use, contact a professional for repairs. Care and Cleaning □ Use a soft, clean cloth that will not scratch the surface when dusting. □ Use of furniture polishes is not necessary. Should you choose to use polishes, test the polish in an inconspicuous area before using over the entire surface of the product. - Page 13 Questions, problems, missing parts? Before returning to the store, call Home Decorators Collection Customer Service. 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS Retain this manual for future use.
