Charging Steps - Shell SBC100 User Manual

LED Indicator Light Table
LED Indicator
ERR
6V SLA
12V SLA
12V LI-ION
(LiFePO4)

Charging Steps

The charger is programmed with seven smart charging steps. It will go
through some or all steps in order to extend your battery's life and
maximize its performance.
Standby
The charger is ready to charge.
Qualification
The charger will check the battery condition, such as voltage,
state-of-charge and health, to determine whether the battery is good for
charging. If the battery is slightly sulfated, the charger will rejuvenate
and recover the battery. As a safety measure, charging process will
begin only if the battery is above 4V.
Soft Start
If the battery is at a very low state of charge, small charging voltage and
current will be applied in order to prepare the battery for the next
charging step.
Indicator Light
Red light on
Yellow light
flashes
• Green light
flashes during
charging
• Green light
turns solid when
battery is fully
charged
Explanation
Power indicator. Plug in the charger and
the indicator light will be on
Possible causes:
• The clamps are connected to the wrong
polarities
• The battery may be defective
• The battery voltage exceeds 15V
For charging 6V maintenance-free
batteries such as Wet Cell, Gel Cell,
AGM and EFB
Suitable for 2-20 Ah batteries
For charging 12V maintenance-free
batteries such as Wet Cell, Gel Cell,
AGM and EFB
Suitable for 2-20 Ah batteries
For charging 12V Li-ion batteries
Suitable for 2-20 Ah batteries
