Dimplex Ignite 50 Owner's Manual page 8

Fireplace Installation
hole drilled for electrical wire
routing.
!
NOTE: It is recommended that
the bottom of the unit be mounted
between 30 in. (76.2 cm) and 40
in. (102 cm) from the ground to
maintain an optimized viewing
WARNING: Do not attempt to
wire your own new circuits. To reduce
to persons, always use a licensed
electrician.
WARNING: Ensure that the
be installed has the power cut off
at the service panel until installation
is complete.
2. The unit is provided with an
installed ¾ in. (2.0 cm) trim.
Depending on the installation,
this trim can be removed by
Figure 2
8
removing the securing screws
and the 4 trim pieces.
3.
and the handles located on the
back, and insert into opening to
the desired depth.
4. Using a bubble level (supplied)
required.
5. Drive four supplied mounting
screws through the four mounting
holes located on the inside
into wall studs (Figure 2).
Mounting Holes
Flame
Panel
