IMPORTANT SAFETY INFORMATION: Always read this manual first before attempting to service this
fireplace. For your safety, always comply with all warnings and safety instructions contained in this
manual to prevent personal injury or property damage.
Service Manual
Model
UL Part Number
XLF50 6909630100
XLF60 6910000100
XLF74 6909690100
XLF100 6909700100
7400940000R08
Advertisement
Table of Contents
Related Manuals for Dimplex Ignite XLF50
Summary of Contents for Dimplex Ignite XLF50
- Page 1 Service Manual Model UL Part Number XLF50 6909630100 XLF60 6910000100 XLF74 6909690100 XLF100 6909700100 IMPORTANT SAFETY INFORMATION: Always read this manual first before attempting to service this fireplace. For your safety, always comply with all warnings and safety instructions contained in this manual to prevent personal injury or property damage.
-
Page 2: Table Of Contents
NOTE: Procedures and techniques that are considered important enough to emphasize. CAUTION: Procedures and techniques which, if not carefully followed, will result in damage to the equipment. WARNING: Procedures and techniques which, if not carefully followed, will expose the user to the risk of fire, serious injury, or death. www.dimplex.com... -
Page 3: Operation
Operation seconds. Flame Effects Figure 1 Turns the Flame Effect On and Off. → Activated by pressing the button on the remote. Heat ON/OFF Turns the heater On and Off. → Activated by pressing the button on the remote or the unit. -
Page 4: Additional Key Combinations
! NOTE: The Sleep Timer can be cancelled at any time by pressing the button repeatedly until the sleep timer displays nothing. Resetting the Temperature Cutoff Switch Should the heater overheat, an automatic cut out will turn the whole unit off and it will not come back on without being www.dimplex.com... -
Page 5: Maintenance
Maintenance W ARNING: Disconnect power and allow heater to cool before attempting any maintenance or cleaning to reduce the risk of fire, electric shock or damage to persons. NOTE: The fireplace should not be operated with an accumulation of dust or dirt on or in the unit, as this can cause a build up of heat and eventual damage. -
Page 6: Exploded Parts Diagram - Xlf50
11. 6-Light LED Flame Assembly ..3001760600RP 24. Flicker Assembly Bushing ..x-8500680100RP 12. 8-Light LED Flame Assembly ..3001760700RP www.dimplex.com... -
Page 7: Exploded Parts Diagram - Xlf60
Exploded Parts Diagram - XLF60 LED Configuration Flame LED’s (white) Flame Base (colour) Media (colour) Replacement Parts List - XLF60 1. Heater Assembly (with cutouts) ..2203720300RP 12. 6-Light LED Flame Assembly (2) ..3001760600RP 2. -
Page 8: Exploded Parts Diagram - Xlf74
12. 8-Light LED Flame Assembly (2) ..3001760700RP 13. Media Tray ..... .5902910200RP 14. 6-Light RGB Media LED Assembly ..3001570100RP www.dimplex.com... -
Page 9: Exploded Parts Diagram - Xlf100
Exploded Parts Diagram - XLF100 LED Configuration Flame LED’s (white) Flame Base (colour) Media (colour) Replacement Parts List - XLF100 1. Heater Assembly (with cutouts) ..2203720300RP 13. 6-Light RGB Media LED Assembly (5) . . . 3001570100RP 2. -
Page 10: Wiring Diagrams
Wiring Diagrams XLF60 CERAMIC ELEMENT MAIN CONTROL BOARD THERMAL CUTOUTS THERMISTOR POWER ADAPTER FLICKER MOTOR FLAME LED ASSEMBLY MEDIA LED ASSEMBLY MEDIA LED ASSEMBLY www.dimplex.com... -
Page 11: Wiring Diagrams
Wiring Diagrams... -
Page 12: Preparation For Service
5. Attach the suction cup to the partially reflective glass to assist with removal (XLF74 & XLF100.) 6. Remove the 12 screws from the glass retaining brack- et, starting on either end and working your way to the www.dimplex.com... -
Page 13: Main Control Board Replacement
middle, along the top of the opening, ensuring that Figure 6 neither the bracket nor the partially reflective glass falls XLF50/XLF60 out of the unit. (Figure 5) 7. Gently lift the partially reflective glass out of the unit and set it aside in a safe place. CAUTION: Partially Reflective Glass is not tempered. -
Page 14: Power Supply Replacement
II. Affix the lens to the new LED strip by aligning it over the LED light and pressing down on it. 10. Install the new assembly and secure the LED strip to the unit. 11. Reattach the wire connections. www.dimplex.com... -
Page 15: Flicker Assembly Replacement
12. Ensure that all wires are replaced in the same manner 8. Remove the 2 screws holding the flicker motor to the as prior to the service. mounting bracket. Gently pull the motor away from the flicker rod. 13. Reassemble in the reverse order as above. 9. -
Page 16: Heater Assembly Replacement
5. Properly orient the new heater assembly and connect all of the wiring connections. 6. Secure any excess wire using the provided cable ties. 7. Reassemble in the reverse order as above. www.dimplex.com... -
Page 17: Troubleshooting Guide
Troubleshooting Guide PROBLEM CAUSE SOLUTION General Circuit breaker trips or fuse blows Short in unit wiring. Trace wiring in unit. when unit is turned on Improper circuit current rating Additional appliances may exceed the current rating of the circuit breaker or fuse. Plug unit into another outlet or install unit on a dedicated 15 amp circuit. - Page 18 Replace if necessary. the heater off Defective flicker motor Replace flicker motor 1-888-346-7539 | www.dimplex.com In keeping with our policy of continuous product improvement, we reserve the right to make changes without notice. © 2023 Glen Dimplex Americas www.dimplex.com...
