9
Technical information
9.1
Specifications – heat pump (alternating current)
Air/water operation
1)
Power output with A -10/W35
1)
Power output with A -7/W35
1)
COP with A -7/W35
, partial load
Modulation range with A -7/W35
1)
Power output with A +2/W35
Power output with A +2/W35 , partial load
COP with A +2/W35 , partial load
Modulation range with A +2/W35
1)
Power output with A +7/W35
1)
COP with A +7/W35
, partial load
Modulation range with A +7/W35
Cooling capacity with A 35/W7
1)
EER with A 35/W7
Cooling capacity with A 35/W18
1)
EER with A 35/W18
Electrical details
Power supply
Protection index
Fuse rating for supplying the heat pump directly via the building connection
Maximum power consumption
Heat transfer medium
Minimum flow
Internal pressure reduction
Air and noise generation
Max. fan motor output (DC transformer)
Maximum air current
Sound pressure level with a clearance of 1 m, load point according to 2013/811/EU
3)
Sound Power
Max. sound power A7/W55
Max. sound power "quiet operation" A7/W55
Max. sound power A7/W35
Max. sound power "quiet operation" A7/W35
Max. sound power incl. tonality
Max. sound power incl. tonality "quiet operation"
General details
5)
Refrigerant
Refrigerant charge
CO
(e)
2
Maximum temperature of flow, heat pump only
Installation altitude above sea level
Dimensions (W x H x D)
Weight without walls and top cover
Weight with walls and top cover
1) Performance data in accordance with EN 14511
2) Fuse class gL/C
3) Sound power level in accordance with EN 12102
4) Tonality
5) GWP100 = 2088
Table 10 Specifications – heat pump (alternating current)
Compress 7400i AW – 6721833372 (2021/09)
, 100% compressor speed
, partial load
1)
, 100% compressor speed
, partial load
1)
1)
1)
Unit
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
230 V 1N AC 50 Hz
2)
A
kW
l/s
kPa
W
m³/h
dB(A)
dB(A)
dB(A)
dB(A)
dB(A)
dB(A)
dB(A)
dB(A)
kg
Tonne
°C
mm
kg
kg
Technical information
5 OR
7 OR
4.76
6.20
4.24
5.66
3.02
3.08
1.5-5.0
1.9-6.8
5.48
7.29
2.53
2.54
4.25
4.25
1.9-5.5
2.5-7.3
2.82
4.01
5.01
5.01
2.1-7.6
4.0-7.9
4.44
5.66
2.42
2.36
6.15
7.39
2.98
2.86
230 V 1N AC 50 Hz
IP X4
IP X4
16
16
3.2
3.6
0.33
0.43
7.8
10.5
240
240
3400
3400
42
42
50
50
54
55
49
51
55
55
47
48
4)
53 + 3
55 + 3
4)
49 + 0
51 + 0
R410A
R410A
1.75
2.35
3.65
4.91
62
62
up to 2000 m above sea level
940x1380x600
940x1380x600
89
96
113
120
4)
4)
19
